Aries 15912 Installation Manual

INSTALLATION MANUAL
Parts List
1 Driver / left, mounting bracket
1 Passenger / right,
mounting bracket
4 Spacers, M8 x 19mm
4 Flat washer, M8
4 Lock washer, M8
4 Button head cap screw,
M8 x 1.25 x 45mm
Tools Required
Rachet Socket, 7mm
Allen wrench, Allen wrench,
2.5mm 5mm
Torx bit, T-50 Utility knife
Torque Specifications
M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.
Level of Difficulty
Easy
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To protect the product, wax after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may
contain abrasives that could damage the finish.
For stainless steel and aluminum, polish may be used to clear small scratches
and scuffs on the finish. Mild soap may be used also to clean the product.
For black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
15912
