Aries 1110313 Installation Manual

INSTALLATION MANUAL
Level of Difficulty
Easy

Parts List

1 Driver / left bracket
1 Passenger / right bracket
2 Spacer, 5/8"
4 Spacer, 1/2"
4 Button head screw, M6
4 Flat washer, M6
4 Lock washer, M6
2 Button head screw, M8
2 Flat washer, M8
4 Lock washer, M8
4 Carriage bolt, 1/4"
4 Flat washer, 1/4"
4 Nylock nut, 1/4"

Tools Required

Torque wrench --

Torque Specifications

M6 bolt 3 ft-lbs.
M8 bolt 7 ft-lbs.
M10 bolt 16 ft-lbs.
M12 bolt 28 ft-lbs.
1/4" bolt 3 ft-lbs.
5/16" bolt 7 ft-lbs.
3/8" bolt 16 ft-lbs.
7/16" bolt 20 ft-lbs.
1/2" bolt 28 ft-lbs.
Use above torque setting unless otherwise noted
ARIESAUTOMOTIVE.COM
Product Photo
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.

Maintenance

To protect the product, wax after installing. Regular waxing is recommended
to add a protective layer over the finish. Do not use any type of polish or wax
that may contain abrasives that could damage the finish.
For polished, gloss and other smooth finishes,
polish may be used to clear small scratches and scuffs on the finish.
Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive
cleaners, abrasive pads, wire brushes or other similar products that may damage the finish.

Product Registration and Warranty

CURT Group stands behind our products with industry-leading warranties.
Provide feedback and help us to improve our products by registering your purchase at:
warranty.curtgroup.com/surveys
• NEED ASSISTANCE? • 877.287.8634 • 1110313-INS-RA • PAGE 1
