Phoenix Model MESSERSCHMITT BF 109 Instruction Manual

MESSERSCHMITT BF 109
SPECIFICATION
- Wingspan: 1965mm (77.4 in)
- Length: 1738mm (68.4 in)
- Flying weight: 7700 – 7900 g
- Wing area: 64 dm2
- Wing loading: 120 g/dm2
- Gear type: Electric Retract Gear (included)
with controller box (included).
- Spinner size: 115mm (included)
- Radio: 8 channel minimum (not included)
- Servo: 8 Standard servo: 2 aileron; 2 flap;
2 elevator; 1 rudder; 1 throttle (not included)
- Propeller: Suit with your engine
- Engine: 30-35cc gas engine (not included)
- Motor: brushless outrunner 1600-2200 W,
450 KV (not included)
- Gravity CG: 114 mm (4.4 in) Back from
the leading edge of the wing, at the fuselage
- Control throw Ailerons: Low: 11mm up/down,
10% expo; High: 13mm up/down, 10% expo
- Control throw Elevators: Low: 11mm up/down,
12% expo; High: 13mm up/down, 12% expo
1.97m 77.4'' W/Electric Retract ARF Size 30-35cc
- Control throw Rudder: Low: 30mm right/left,
15% expo; High: 40mm right/left, 15% expo
- Control throw flap : Mid : 15mm down;
Landing : 20mm down
- Experience level: Intermediate
- Plane type: Fighter aircraft
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: RIMFIRE 1.60 (not included)
- Lipo cell: 12 cells (not included)
- Esc: 80A (not included)
UNDER SAFETY PRECAUTIONS
This radio control model is not a toy!
It is highly recommended that first-time builders seek advice of
experienced modelers before beginning assembly.
Assemble this kit only in places out of children's reach!
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
GP EP
version version
