DA2 HD 8K AE and DA2 HD 8K AI • Setup Guide
IMPORTANT NOTE:
Go to www.extron.com
the product to the power source.
The Extron DA2 HD 8K AE and DA2 HD 8K AI distribution amplifiers distribute one HDMI input signal to two outputs simultaneously at
resolutions up to 8K @ 30 Hz 4:4:4 or 8K @ 60 Hz 4:2:0, and comply with HDMI 2.1 and HDCP 2.2. The DA2s also features EDID Minder
Plus and remote control and monitoring via USB.
The DA2 HD 8K AE extracts LPCM 2-channel audio from the HDMI signal, converts it to analog, and outputs it as balanced or unbalanced
analog audio. The DA2 HD 8K AI accepts stereo balanced or unbalanced analog audio, convert it to 2-Channel 16-bit LPCM audio at
48 KHz, and embed it onto the HDMI signal.
This setup guide provides basic instructions for installation by an experienced installer. For complete instructions, see the
DA2 HD 8K AE and DA2 HD 8K AI User Guide at www.extron.com.
Mounting
The DA2 HD 8K AE and DA2 HD 8K AI distribution amplifiers can be placed on a desktop or tabletop using the included rubber feet, or
mounted to a rack or furniture (see the DA2 HD 8K AE and DA2 HD 8K AI User Guide at www.extron.com, for mounting options and
instructions).
Rear Panel Cabling
DA2 HD 8K AE
POWER
12V
--A MAX
_ _
+ +
INPUT
A A A B B B
Figure 1. DA2 HD 8K AE and DA2 HD 8K AI Rear Panels
Power input — Connect the provided 12 VDC, 1.5 A power supply to this 2-pole 3.5 mm captive screw port.
A
SECTION A–A
Figure 2. Wiring the Power Connector
HDMI input — Connect a source device to this female
B
HDMI type A input.
HDMI outputs — Connect up to two display devices to these female HDMI type A outputs.
C
NOTE: Use the provided LockIt
on page 2).
Analog audio output (DA2 HD 8K AE model only) —
D
Connect an audio output device to this 5-pole, 3.5 mm
captive screw port. This port outputs 2-channel LPCM audio
(converted to analog) that is extracted from the HDMI input
signal.
Analog audio input (DA2 HD 8K AI model only) — Connect
E
an analog audio device to this 5-pole 3.5 mm captive
screw port. This port accepts 2-channel stereo balanced or
unbalanced audio.
NOTE: By default, the DA2 HD 8K AI is configured to
always embed analog audio. This can be configured
using Extron PCS software or SIS commands.
for the complete user guide, installation instructions, and specifications before connecting
1 2
OUTPUTS
C C C
A
Smooth
Ridges
3/16"
A
(5 mm) Max.
® HDMI cable lacing brackets to secure the HDMI connectors (see
DA2 HD 8K AI
POWER
ANALOG OUT
12V
L R
--A MAX
_ _
+ +
AUDIO
D D D
A A A
POWER
ATTENTION:
12V
--A MAX
•
Do not connect the power supply before reading
the Attention in the Power Supply section of the
DA2 HD 8K AE and DA2 HD 8K AI User Guide.
•
Ne branchez pas la source d'alimentation externes avant
d'avoir lu les mises en garde dans la section « Power Supply »
du DA2 HD 8K AE and DA2 HD 8K AI User Guide.
Tip
Sleeve
Tip
Sleeve
Unbalanced Stereo Input
No Ground Here
Tip
Sleeves
Tip
No Ground Here
Unbalanced Stereo Output
Figure 3.
Tip
Sleeve
Tip
Sleeve
Unbalanced Stereo Input
Figure 4.
No Ground Here
Tip
Sleeves
Tip
No Ground Here
1 2
INPUT OUTPUTS
B B B C C C
Tip
Ring
Sleeves
Installing the LockIt Bracket
Tip
Ring
Balanced Stereo Input
Tip
Ring
Sleeves
Tip
Ring
Balanced Stereo Output
Wiring the Audio Output Connector
Tip
Ring
Sleeves
Tip
Ring
Balanced Stereo Input
Wiring the Audio Input Connector
Tip
Ring
Sleeves
Tip
Ring
DA2 HD 8K AE / DA2 8K AI
ANALOG IN
L R
AUDIO
E E E
Do not tin the wires!
