- Page 1 KVM switch and rackmount screen technology User Manual 17” / 19” High Brightness LED-backlit LCD 1000 cd/m² H117 / H119 1U LED-backlit LCD Console Drawer Options : - AV / DVI-D / HDMI - DC power Designed and manufactured by Austin Hughes UM-CV-751-H117-Q225V1 www.austin-hughes.com...
-
Page 2: Legal Information
■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-H117-Q225V1 www.austin-hughes.com... -
Page 3: Table Of Contents
Contents < Part. 1 > H117 / H119 Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations Keyboard / Mouse Specifi cations On-screen Display Operation ( OSD ) P.10 < Part. 3 >... -
Page 4: Before Installation
fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-H117-Q225V1 www.austin-hughes.com... -
Page 5: Package Content
< Part 1 > < 1.1 > Package Content H117 / 119 H117 or H119 unit X 1 - CB-6A 6ft VGA console cable X 1 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. -
Page 6: Front View
Weight 441.6 x 480 x 44 mm 590 x 808 x 140 mm 12.5 kg 17.5 kg H117 17.4 x 18.9 x 1.73 inch 23.2 x 31.8 x 5.5 inch 27.5 lb 38.5 lb 441.6 x 520 x 44 mm 590 x 808 x 140 mm 13.2 kg... -
Page 7: Installation
< 1.3 > Installation - Installation Slides H117 / 119 Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. - Page 8 Basically, user can push in the drawer back to park position by releasing the left & right slide lock arrow (as long as the drawer starts moving, he/she can release their finger right away, holding the arrow is not necessary). Keep Your Fingers Away From The Slide Stop UM-CV-751-H117-Q225V1 www.austin-hughes.com...
-
Page 9: Connection
< 1.4 > Connection to USB Server via CB-6A cable H117 / 119 LCD Console Drawer POWER AC Input 100~240V CB-6A VGA console cable USB server < 1.4 > Connection to external KVM via CB-6A cable LCD Console Drawer POWER... -
Page 10: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations LED-backlit LCD Panel H117 H119 Panel Size ( diagonal ) 17-inch TFT color 19-inch TFT color LED-backlit LCD LED-backlit LCD Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024 Brightness ( typ. - Page 11 H117 / 119 Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 10~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random...
-
Page 12: Keyboard / Mouse Specifi Cations
Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts America United States EMEA United Kingdom Germany France Russia Spain Italy Asia Japan Korea UM-CV-751-H117-Q225V1 www.austin-hughes.com... -
Page 13: How To Use "S" Keyboard
< 2.2 > SUN Keyboard / Mouse Options H117 / 119 S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■... -
Page 14: On-Screen Display Operation ( Osd )
( a ) Press the button to call up the on-screen video mode on top right corner. ( b ) Use up/down arrow to the select the video input ( c ) Press the button to confi rm the selection UM-CV-751-H117-Q225V1 P.10 www.austin-hughes.com... - Page 15 < 2.3 > On-screen Display Operation ( OSD ) H117 / 119 OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video:...
- Page 16 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
-
Page 17: Options
Audio AC Input 100~240V For the above options, H117 depth will be extended from 480mm ( 18.9” ) to 530mm ( 20.9” ) and H119 depth will be extended from 520mm ( 20.5” ) to 570mm ( 22.4” ) UM-CV-751-H117-Q225V1 P.13... - Page 18 USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc ■ For detailed information, please refer to the attached CD disc ■ As the touchscreen unit is not made of toughened glass, please handle it carefully UM-CV-751-H117-Q225V1 P.14 www.austin-hughes.com...
- Page 19 < 3.3 > Options : Touchscreen & driver H117 / 119 USB Touchscreen Power AC Input 100~240V TPC-10 Driver Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports easy Plug-and-Play operations. There is no need to install additional drivers on the computer.
- Page 20 ( 2 ) DC option excludes AC power adapter and power cord. ( 3 ) H117 depth will be extended from 480mm ( 18.9” ) to 530mm ( 20.9” ) ( 4 ) H119 depth will be extended from 520mm ( 20.5” ) to 570mm ( 22.4” ) UM-CV-751-H117-Q225V1 P.16...
-
Page 21: Orb-2.1 2-Post Rack Mounting Brackets
< 3.5 > ORB-2.1 2-Post Rack Mounting Brackets H117 / 119 Step Right bracket ■ Before apply 2-post rack brackets, please release front mounting ears and rear mounting wheels. fl at head screw 6#32*4.5mm x 3 ■ Attach left and right mounting brackets to the... -
Page 22: Kvm Integration
(W x D x H) 441.6 x 580 x 44 mm 590 x 808 x 140 mm 13.8 kg 19.7 kg H117 with KVM 17.4 x 22.8 x 1.73 inch 23.2 x 31.8 x 5.5 inch 30.4 lb 43.3 lb 441.6 x 620 x 44 mm... - Page 23 Intentionally Left Blank UM-CV-751-H117-Q225V1 www.austin-hughes.com...
- Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2025 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-H117-Q225V1 www.austin-hughes.com...
