- Page 1 KVM switch and rackmount screen technology User Manual 17” / 19” High Brightness LCD 1000 cd/m² H117 / H119 1U LCD Console Drawer Options : - AV / DVI-D / HDMI / Audio - DC power Designed and manufactured by Austin Hughes UM-CV-751-H117-Q414V1 www.austin-hughes.com...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. UM-CV-751-H117-Q414V1 www.austin-hughes.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > H117 / H119 Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 5 Connection < Part. 2 > Specifi cations / OSD Product Specifi cations P.7 - 8 Keyboard / Mouse Specifi cations On-screen Display Operation ( OSD ) P.10 - 11... - Page 4 DB-15 KVM -IP802 -IP1602 -802 -1602 -S801 -S1601 www.austin-hughes.com/support/usermanual/cyberview/UM-CV-DVIKVM-KIT.pdf Local Remote 12-port DVI-D -1201D www.austin-hughes.com/support/usermanual/cyberview/UM-CV-USBKVM-KIT.pdf Local Remote 8-port 16-port 32-port USB Hub DB-15 KVM -IP802H -IP1602H -802H -1602H -801H -1601H www.austin-hughes.com/support/usermanual/cyberview/UM-CV-PS2KVM-KIT.pdf Local Remote 8-port PS/2 DB-15 KVM -801 UM-CV-751-H117-Q414V1 www.austin-hughes.com...
-
Page 5: Before Installation
fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-H117-Q414V1 www.austin-hughes.com... -
Page 6: Package Content
< Part 1 > < 1.1 > Package Content H117 or H119 unit X 1 - CE-6 6ft Combo KVM cable X 1 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 7 < 1.2 > Dimension H117 / 119 Front View UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 480 x 44 mm 590 x 808 x 140 mm 12.5 kg...
-
Page 8: Installation
Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. Step Complete the installation ■ Fix the LCD console drawer into the rack. M6 screw, cage nut & cup washer x 8 are provided. UM-CV-751-H117-Q414V1 www.austin-hughes.com... - Page 9 < 1.3 > Installation - How to install 2 post rack brackets H117 / 119 Step ■ Release front mounting ears before applying 2 post rack brackets. ■ Insert rear mounting brackets into the LCD console drawer. Option Model : MB-751-12 Step ■...
- Page 10 < 1.3 > Installation- How to use the drawer ■ Hold the handle and slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-H117-Q414V1 www.austin-hughes.com...
-
Page 11: Connection
< 1.4 > Connection to PS/2 or USB Server H117 / 119 LCD console drawer LCD console drawer CE-6 Combo CE-6 Combo KVM cable KVM cable PS/2 server USB server < 1.4 > Connection to external KVM LCD console drawer... -
Page 12: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations H117 H119 Panel Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024 Brightness ( typ. ) - Page 13 H117 / 119 Operating Temperature 0 to 50°C degree Environmental Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical H117 H119 Specifi cation Product ( W x D x H ) 441.6 x 480 x 44 mm...
-
Page 14: Keyboard / Mouse Specifi Cations
MS Windows 7 / 2008 / 2003 / 2000 / XP / ME / 98 / DOC Software support Linux / Mac Supporting layouts America United States United Kingdom Germany France Spain Norway EMEA Italy Russia Switzerland Netherlands Portugal Asia China Japan Korea Arabia Turkey UM-CV-751-H117-Q414V1 www.austin-hughes.com... -
Page 15: On-Screen Display Operation ( Osd )
< 2.3 > On-screen Display Operation ( OSD ) H117 / 119 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust... - Page 16 H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc: for the language, OSD position, graphic mode, ratio, reset and timer P.11 UM-CV-751-H117-Q414V1 www.austin-hughes.com...
- Page 17 ( 1 ) Either HDMI or DVI-D can be selected. ( 2 ) For the above options, H117 depth will be extended from 480mm ( 18.9” ) to 530mm ( 20.9” ) and H119 depth will be extended from 520mm ( 20.5” ) to 570mm ( 22.4” )
- Page 18 ( 1 ) Option excludes 1 x power cord and 1 x AC power adapter. ( 2 ) H117 depth will be extended from 480mm ( 18.9” ) to 530mm ( 20.9” ) ( 3 ) H119 depth will be extended from 520mm ( 20.5” ) to 570mm ( 22.4” ) P.13...
- Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2014 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-H117-Q414V1 www.austin-hughes.com...
