INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in your machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save you the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 368218
SYNOPSIS / PROBLEM:
This kit contains the parts needed to install an 8" gate valve on the model ATLV 4300.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 1 hours)
PREPARATION:
(Refer to FIG. 1 thru 4)
FOR SAFETY: Before leaving or servicing machine, stop on level surface and set parking
brake. Then turn off machine and remove key.
INSTALLATION:
(Refer to FIG. 1 thru 4)
1. Assemble the gate valve. Refer to the bill of material for parts.
2. Remove and discard the connector tube (367703). Set the two hose clamps (367713) and
mounting hardware aside.
3. Mount the slide gate assembly in place of the tube weldment using existing mounting
hardware. Check that the slide gate handle faces the right hand outside of the machine.
(Refer to FIG. 1, 2 and 3)
4. Connect the two 8" hoses using the existing set aside hose clamps.
5. Start the machine. Turn the vacuum fan on.
6. Check the gate valve for proper operation. Adjust the air flow by sliding the gate in and out.
IB 340313 (12-99) LITHO IN U.S.A.
(Refer to FIG. 1)
No. 340313
Machine: ATLV 4300
Published: 12-99/01
System: SWEEPING
(Refer to FIG. 2)
1
