INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in your machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save you the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 368106
SYNOPSIS / PROBLEM:
This kit contains the parts needed to install a dust bag kit on the model ATLV 4300.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: None
(Estimated time to complete: 1 hour)
INSTALLATION:
(Refer to FIG. 1 thru 3)
FOR SAFETY: Before leaving or servicing machine, stop on level surface and set parking
brake. Then turn off machine and remove key.
NOTE: Before this kit can be installed, Kit # 368107 Filter bag update kit may need to be
installed.
1. Remove the old filter bag assembly from the back of the debris hopper, and set the black
filter bag and mounting hardware aside.
2. Remove the mounting hardware from the outside, upper corner of the machine taillights.
3. Install the angle brackets (3) with the removed hardware. The larger hole in the angle
bracket should be facing down when mounted correctly.
4. Install the new vacuum exhaust plate (4) to the back of the debris hopper with the vacuum
plate gasket (5).
5. Mount the old black filter bag over the new vacuum exhaust plate (4).
6. Install the new white dust bag (1) over the existing black filter bag and vacuum exhaust
plate (4).
(Refer to FIG. 2)
7. Secure the black filter bag, and the new dust bag (1) over the new vacuum exhaust
plate (4) with the new retaining clamp (2).
8. Clip the ends of the new white dust bag (1) onto the new angle brackets (3).
(Refer to FIG. 2 and 3)
IB 340207 (6-00) LITHO IN U.S.A.
(Refer to FIG. 2)
(Refer to FIG. 1)
(Refer to FIG. 2 and 3)
(Refer to FIG. 2)
No. 340207
Machine: ATLV 4300
Published: 6-00/02
System: OPTIONS
(Refer to FIG. 2)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATLV 4300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tennant ATLV 4300

  • Page 1 NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials. Installation instructions for kit number 368106 SYNOPSIS / PROBLEM: This kit contains the parts needed to install a dust bag kit on the model ATLV 4300. Please follow step-by-step instructions. SPECIAL TOOLS / CONSIDERATIONS: None...
  • Page 2 Set the black filter bag aside FIG. 1 - - REMOVE OLD FILTER BAG ASSEMBLY IB 340207 (6-00) LITHO IN U.S.A.
  • Page 3 Secure both filter bags around the new vacuum exhaust bracket with the new retaining clamp Mount the black filter bag inside of the white filter bag FIG. 2 - - NEW FILTER BAG ASSEMBLY INSTALLATION IB 340207 (6-00) LITHO IN U.S.A.
  • Page 4 TENNANT Ref. Part No. Description Qty. 368329 Filter dust bag 368333 Clamp, retaining 368133 Angle, mtg. 368382 Bracket assy, vacuum exhaust 368224 Gasket, vacuum plate TENNANT COMPANY P. O. Box 1452 Minneapolis, MN 55440-1452 IB 340207 (6-00) LITHO IN U.S.A.
