TROUBLESHOOTING GUIDE

In case of problems before all you must check for the correct installation of the unit
and for the correct connection of the accessories.
Problems
The equipment doesn't
switch on.
Alarm OC always active Interruption or lack of
The unit doesn't
respond to the
command of activation
Error Code 001
Error Code 002
Error Code 003
Error Code 004
Error Code 005
Error Code 009
Error Code 010
Probable Cause
Interruption or absence of
the main feeding.
contact on the neutral
electrode circuit.
Breakdown of the
handpiece or of the pedal.
Wrong connection of the
handpiece or of the pedal.
Alarm OVT activated.
Current delivery control
activated during switching
on.
Error in the management
board.
Error in the management
board.
Error in the data
conversion circuit.
Error of the reference
voltage value.
Error in the output power
activation circuit.
Error in the output power
activation circuit.
Solution
Verify the connection of the main
cable.
Verify the fuses and replace them,
where necessary, with new ones of
the proprie type.
Check the connection of the cable
to the neutral electrode.
Replace the cable of connection of
the neutral electrode.
Replace the handpiece or the pedal.
Verify the connection
handpiece or of the pedal.
Wait for the OVT warning signal
getting out.
Disconnect the handpiece or the
pedal and switch on the unit again.
Call for Service.
Call for Service.
Call for Service.
Verify the main voltage.
Call for Service.
Call for Service.
Call for Service.
of the
