TARGET MODBUS START REGISTER ADDRESS
Defines the starting register of the TAG to be acquired by the Modbus RTU slave.
TARGET MODBUS REQUEST TYPE
Select the type of Modbus register:
Coil
Discrete Input
Holding Register
Input Register
TARGET REGISTER DATA
Select the type of TAG variable:
16 BIT UNSIGNED: 1 Modbus register, from 0 to 65535
16 BIT SIGNED: 1 Modbus register, from -32768 to +32767
32 BIT UNSIGNED MSW: 2 Modbus registers, whose Modbus register with the lower address contains the most
significant word, can assume values from 0 to 4294967295
32 BIT UNSIGNED LSW: 2 Modbus registers, whose Modbus register with the lower address contains the least
significant word, can assume values from 0 to 4294967295
32 BIT SIGNED MSW: 2 Modbus registers, whose Modbus register with the lower address contains the most
significant word, can assume values from -2147483648 to +2147483647
32 BIT SIGNED LSW: 2 Modbus registers whose Modbus, register with the lower address contains the least
significant word, can assume values from -2147483648 to +2147483647
FLOAT MSW: 2 Modbus registers, whose Modbus register with the lower address contains the most significant
word, single precision floating point value (IEEE 758-2008)
FLOAT LSW: 2 Modbus registers, whose Modbus register with the lower address contains the least significant
word, single precision floating point value (IEEE 758-2008)
BIT: 1 Boolean Coil or Discrete Input, value true or false.
N.B. This field is automatically filled in if a Seneca slave device has been selected in the "TARGET MODBUS
DEVICE" field.
All 32-bit values are stored in 2 consecutive registers, for example:
The 32-bit unsigned MSW TAG 1 Totalizer is stored in the addresses 40016 and 40017:
The most significant word is 40016, the least significant is 40017.
So the 32bit value is obtained from the following relationship:
Tag setup can be imported/exported from/to a ".cgi" file:
Note that a .cgi file can also be imported/exported from/to the Excel template.
It is also possible to add, modify, delete or move a tag.
ALL RIGHTS RESERVED. NO PART OF THIS PUBLICATION MAY
BE REPRODUCED WITHOUT PRIOR PERMISSION.
User Manual
ATTENTION!
1 = (40017) + ( (40016) × 65536)
www.seneca.it
MODBUS TO CLOUD
"KEY-C" GATEWAYS
MI00725-1-EN
Page 25
