7. OPERATING MODE
The Gateway operates in the following mode:
MODBUS SERIAL-ETHERNET MASTER/CLIENT TO CLOUD
MODBUS MASTER / CLIENT TO CLOUD
This operating mode allows you to load data from Modbus RTU/ASCII Slave and/or remote TCP Server I/Os to
a cloud (and vice versa).
Below are some examples of possible connections:
