The meaning of the advanced diagnostics byte is:
BYTE VALUE
0
1
2
3
4
For example:
49033 0x0000
49034 0x0002
It means that:
TAGs 1 and 2 are OK (0x00 and 0x00)
TAG 03 is in a delayed state (0x02)
TAG 4 is OK (0x00)
LAST_LOOP_TIME_COMx is a register that contains the last interrogation time of all serial tags (in how many
of 10 ms) so, for example:
49283 25
49284 42
It means that the serial 1 loop was 250ms, the serial 2 loop was 420ms.
