- Page 1 User Manual IDK-1108R-50SVB1 8.4" SVGA Industrial Display Kit with 4-Wire Resistive Touch Solution...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
-
Page 3: Product Warranty (2 Years)
Product Warranty (2 Years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation. - Page 4 IDK-1108R-50SVB1 User Manual...
-
Page 5: Table Of Contents
Table 3.2: Interface..............22 Chapter Touch Controller........23 4-Wire USB & RS232 Touch Panel Controller ........24 Table 4.1: Supported OS............24 4.1.1 Controller ..................24 4.1.2 Specifications................25 Table 4.2: 4-Wire Type Controller ..........25 4.1.3 Product Package................. 25 IDK-1108R-50SVB1 User Manual... - Page 6 Appendix A Safety Precautions......29 Handling Precautions................30 Installation Precautions................30 Storage Precautions ................30 Operating Precautions ................31 Others ..................... 31 IDK-1108R-50SVB1 User Manual...
-
Page 7: Chapter 1 Overview
Chapter Overview... -
Page 8: General Description
General Description The Advantech IDK-1108 series features an 8.4" industrial-grade LCD display with 4- wire resistive touch technology. This series offers flexible options for LCD screens, including enhancements like anti-reflection surface treatment and optical bonding. With low power consumption of up to 3.24 W, the IDK-1108 series is ideal for embed- ded applications, providing customers with maximum flexibility in mechanical design. -
Page 9: Mechanical Characteristics
188.98±0.4 (T/P) (11.36) 172.21±0.3 (A,A) T/P (97.8±0.5) 2-Ø3.0 1811024629 Capton Tape (85.0x25.0) Tape (7.0x15.5) 2-R1.5 8.0±0.3 181.4±0.3 (Mylar) 14.1 (12.6) 170.4±0.5 (A,A) Tape 9.56±0.3 (10.55) 174.15±0.3 (V,A) (41.58±0.5) 203.0±0.5 (7.0x15.5) (2.5) 198.5±0.5 203.0±0.5 (41.58±0.5) Touch Control Board IDK-1108R-50SVB1 User Manual... - Page 10 IDK-1108R-50SVB1 User Manual...
-
Page 11: Chapter 2 Lcd Display
Chapter LCD Display... -
Page 12: Absolute Maximum Ratings
0.310 White 0.330 Θ=Φ=0° 0.603 IF=150mA 0.336 Color Typ. Typ. Ta=25°C (1),(2),(6) Chromaticity -0.05 +0.05 0.326 Green 0.546 0.159 Blue 0.110 Measuring Conditions: Measurement surroundings: dark room, LED current IF Ambient temperature: 25±2°C Warm-up time: 15 min. IDK-1108R-50SVB1 User Manual... - Page 13 15 minutes to avoid abrupt temperature change during measure- ment. In order to stabilize the luminance, the measurement should be executed after keeping the backlight lit for 15 minutes in a windless room. Note2! LED input parameter setting: PWM: duty 100% IDK-1108R-50SVB1 User Manual...
- Page 14 “White” state and “Black” state. Rise time (Tr) is the time between photo detector output intensity from 10% to 90%. And fall time (Tf) is the time between photo detector output intensity from 90% to 10%. IDK-1108R-50SVB1 User Manual...
-
Page 15: Electrical Characteristics
: The measured minimum luminance of all measurement positions Electrical Characteristics 2.3.1 Power Specifications Table 2.3: Power Specifications Item Symbol Min. Typ. Max. Unit Note Logic / LCD Drive Voltage VCC Current 180. Note! fV =60Hz, Ta=25°C, Display pattern: All Black IDK-1108R-50SVB1 User Manual... -
Page 16: Lvds Electrical Specifications
States =0V, Output Short Circuit Current RL=100Ω /PDWN=0V, Output TRI-STATE Current ±10 ųA =0V to Vcc LVDS Receiver DC Specifications Differential Input High Threshold =1.2V Differential Input Low ∆V Threshold VIN=+2.4V/0V Input Current 1.25 1.25 1.375 Vcc=3.6V IDK-1108R-50SVB1 User Manual... -
Page 17: Backlight Unit
If the module is driven by high current or at high ambient tempera- ture & humidity, operating lifetime will be reduced. Operating life means brightness goes down to 50% minimum brightness. LED lifetime is based on estimated data. The structure of the LED B/L is as shown below. IDK-1108R-50SVB1 User Manual... -
Page 18: Pwm Dimming Control
No connection LVDS 6-bit mode: No connection (default) LVDS 8-bit mode: (RXIN4-) Transmission Data of Pixels 4 LVDS 6-bit mode: No connection (default) LVDS 8-bit mode: (RXIN4+) Transmission Data of Pixels 4 Note! Connector Part No.: MPHTJ-12001AP20 (Kingfont) IDK-1108R-50SVB1 User Manual... - Page 19 Each blue pixel's brightness data con- Blue Data 3 sists of these 8 bits of pixel data. Blue Data 2 Blue Data 1 Blue Data 0 (LSB) RxCLKIN+ LVDS Clock Input RxCLKIN- Display Enable Vertical Sync Horizontal Sync IDK-1108R-50SVB1 User Manual...
- Page 20 Blue Data 3 Each blue pixel's brightness data con- Blue Data 2 sists of these 6 bits of pixel data. Blue Data 1 Blue Data 0 (LSB) RxCLKIN+ LVDS Clock Input RxCLKIN- Display Enable Vertical Sync Horizontal Sync IDK-1108R-50SVB1 User Manual...
- Page 21 Up to Down, Right to Left Down to Up, Left to Right 2.5.1.4 CN2: LED Driver Connector Table 2.10: CN2: LED Driver Connector Pin no Symbol Function VLED 12V input Display_ON/OFF +3.3V:ON, 0V:OFF Dimming Note! Connector Part No:3808K-F04N-03R(E&T) IDK-1108R-50SVB1 User Manual...
-
Page 22: Block Diagram
3T/7+0.4 ns RIP5 Input Data Position 4 (T=11.76ns) 4T/7-0.4 4T/7 4T/7+0.4 ns RIP4 Input Data Position 5(T=11.76ns) 5T/7-0.4 5T/7 5T/7+0.4 ns RIP3 Input Data Position 6(T=11.76ns) 6T/7-0.4 6T/7 6T/7+0.4 ns RIP2 Phase Lock Loop Set 10.0 RPLL IDK-1108R-50SVB1 User Manual... - Page 23 Receiver Device Receiver Device Transmission Times Phase Clock Loop Set Time IDK-1108R-50SVB1 User Manual...
-
Page 24: Ac Timing Characteristics Of The Panel
Horizontal display area HSD period time 1000 HSD pulse width thpw HSD back porch HSD front porch thfp Vertical display area VsD period time vsD pulse width tvpw VsD back porch VsD front porch tvfp Sample Clock Timing IDK-1108R-50SVB1 User Manual... -
Page 25: Power On/Off Sequence
Horizontal Display Timing Range Vertical Timing 2.6.3 Power ON/OFF Sequence IDK-1108R-50SVB1 User Manual... - Page 26 2.6.3.1 Power ON/OFF Sequence Timing Table 2.13: Power ON/OFF Sequence Timing Value Symbol Unit Min. Typ. Max. 1000 IDK-1108R-50SVB1 User Manual...
-
Page 27: Chapter 3 Touch Screen
Chapter Touch Screen... -
Page 28: Touch Panel Electrical Specifications
Load: 200 g Frequency: 5 Hz Table 3.2: Interface Symbol Function Touch Panel Bottom Signal on Y Axis Touch Panel Left Signal on X Axis Touch Panel Top Signal on Y Axis Touch Panel Right Signal on X Axis IDK-1108R-50SVB1 User Manual... -
Page 29: Chapter 4 Touch Controller
Chapter Touch Controller... -
Page 30: 4-Wire Usb & Rs232 Touch Panel Controller
Including: CentOS, Debian, Fedora, Gentoo, Man- drake (Mandriva), Moblin (Meego), Red Hat, Ubuntu, Slackware, SuSE (openSUSE), etc. Android (up to 4.x) RS232/USB DOS 6.22 RS232 Mac OS9, Mac OS (Power PC, Intel CPU) QNX RTOS v6.3 RS232/USB 4.1.1 Controller IDK-1108R-50SVB1 User Manual... -
Page 31: Specifications
Unaffected by environmental EMI 4-wire resistive model: 200 ~ 900 ohms Panel Resistance (Pin to pin on same layer, Touch Resistance under 3k ohms) Green Product RoHS Compliant MTBF 200,000 hrs 4.1.3 Product Package ETP-MB-MER4040CFBG-ADV (4-wire control board) IDK-1108R-50SVB1 User Manual... - Page 32 4.1.3.1 Controller Panel Pin Assignment For 4-Wire Resistive Touch Panel 4.1.3.2 Controller Wafer Pin Assignment IDK-1108R-50SVB1 User Manual...
- Page 33 4.1.3.3 Advantech Logo and Shipping Label IDK-1108R-50SVB1 User Manual...
- Page 34 IDK-1108R-50SVB1 User Manual...
-
Page 35: Appendix A Safety Precautions
Appendix Safety Precautions... -
Page 36: Handling Precautions
Store the product in a cool, dry area with a temperature between 0°C and 35°C and humidity below 60%. Select a dark location, ensuring the product is not exposed to direct sunlight or fluorescent light. Keep the products in their original packaging or under the recommended stor- age conditions. IDK-1108R-50SVB1 User Manual... -
Page 37: Operating Precautions
Avoid leaving the LCD on a static display for extended periods, as this can cause residual images and damage the screen. Use a screen saver to prevent this issue. AMIPRE will provide one year warranty for all products and three months war- rantee for all repaired products. IDK-1108R-50SVB1 User Manual... - Page 38 IDK-1108R-50SVB1 User Manual...
- Page 39 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2025...
