- Page 1 User Manual IDK-1110R-50XGB1 10.4” XGA Industrial Display Kit with Projected Capacitive Touch Solution...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
-
Page 3: Product Warranty (2 Years)
Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation. -
Page 4: A Message To The Customer
Whether your new Advantech equipment is destined for the labo- ratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known. -
Page 5: Table Of Contents
Pin Assignment and Description ............. 29 4.4.1 Connector and LED Location............29 4.4.2 Combo Interface Connector, JP1, Pins and Signal Descriptions 29 Figure 4.1 Board Mounted Header ..........30 4.4.3 touchscreen Connector, JP2, Pins and Signal Descriptions..30 IDK-1110R-50XGB1 User Manual... - Page 6 Appendix A LCD Optical Characteristics .... 31 Test Conditions ..................32 Optical Specifications................32 Appendix B Safety Precautions......35 Assembly and Handling Precautions ............36 Storage Precautions ................36 Other Precautions ................... 37 IDK-1110R-50XGB1 User Manual...
-
Page 7: Chapter 1 Overview
Chapter Overview... -
Page 8: General Description
General Description The Advantech IDK-1110R-50XGB1 features a 10.4" industrial grade LCD display with 4-wires resistive touchscreen and low power consumption. This display is ideal for embedded applications that necessitate maximum flexibility for mechanical design. Specifications 1.2.1 LCD Panel Display Size: 10.4", 4:3 ... -
Page 9: Environment
°F) under Vcc=5.0V, fr =60Hz, typical LED string current, 25 ºC (77 °F) ambient temperature, and no humidity control. Any condition of ambient operating temperature, the surface of active area should be keeping not higher than 85 ºC(185 °F). Relative Humidity (%RH) of LCD only IDK-1110R-50XGB1 User Manual... -
Page 10: Mechanical Characteristics
Mechanical Characteristics Front View Unit: mm Rear View Note: Tolerances unless marked are ± 0.5 mm IDK-1110R-50XGB1 User Manual... - Page 11 Touch Controller IDK-1110R-50XGB1 User Manual...
- Page 12 IDK-1110R-50XGB1 User Manual...
-
Page 13: Chapter 2 Lcd Display
Chapter LCD Display... -
Page 14: Functional Block Diagram
[Volt] Note (1) Permanent damage to the device may occur if maximum values are exceeded. Operation should be restricted to the conditions described under Normal Operating Conditions. Note (2) Specified values are for the LED light bar. IDK-1110R-50XGB1 User Manual... -
Page 15: Lcd Electronics Specification
Power Consumption 1.67 LVDS Differential Input Voltage LVDS Common Input Voltage Logic High Input Voltage Logic Low Input Voltage LVDS terminating resistor Note (1) The assembly should always be operated within the above ranges. Note (2) Measurement conditions: IDK-1110R-50XGB1 User Manual... - Page 16 Note (3) The specified power supply current is under the conditions at Vcc = 3.3V, Ta = 25 ± 2 °C (77 ± 3.6 °F), fv = 60 Hz, whereas a power dissipa- tion check pattern below is displayed. IDK-1110R-50XGB1 User Manual...
-
Page 17: Backlight Unit
20% to 100%. If PWM control frequency is applied in the range from 1KHz to 20KHZ, The "non-linear" phenomenon on the Backlight Unit may be found. So It's a suggestion that PWM control frequency should be less than 1KHz. IDK-1110R-50XGB1 User Manual... - Page 18 Ta = 25 ± 2 ºC (77 ± 3.6 °F) - and Duty 100% until the brightness becomes ≤ 50% of its original value. Operating LED at high temperature condition will reduce life time and lead to color shift. IDK-1110R-50XGB1 User Manual...
-
Page 19: Input Terminal Pin Assignment
Negative transmission data of pixel 3 RX3+ Positive transmission data of pixel 3 Ground No Connection ( 4 ) Note (1) Connector Part No.: P-TWO 187106-30091 or STM, MSCK2407P30.D or equivalent. Note (2) User's connector Part No.: JAE FI-X30H(L) or equivalent. IDK-1110R-50XGB1 User Manual... - Page 20 Converter Ground Ground VGND Converter Ground Ground VGND Converter Ground Ground Enable Pin 3.3 V, Note (3) PWM Dimming (190-210Hz, Hi: 3.3V Backlight Adjustment Lo: 0V ), Note (3) Note (1) Connector Part No.: ACES,91208-01001-H01 or equivalent IDK-1110R-50XGB1 User Manual...
- Page 21 Note (2) User's connector Part No.: ACES,91209-01011 or equivalent Note (3) EN(BLON), ADJ(E_PWM) as shown below: IDK-1110R-50XGB1 User Manual...
-
Page 22: Color Data Input Assignment
Scale Red(61) Red(62) Red(63) Green(0)/ Dark Green(1) Green(2) Gray Scale Green Green (61) Green (62) Green (63) Blue(0)/ Dark Blue(1) Blue(2) Gray Scale Blue Blue(61) Blue(62) Blue(63) Note (1) 0: Low Level Voltage, 1: High Level Voltage IDK-1110R-50XGB1 User Manual... - Page 23 Red(255) 1 Green(0) /Dark Green(1) Green(2) Gray Scale Green Green (253) Green (254) Green (255) Blue(0)/ Dark Blue(1) Blue(2) Gray Scale Blue Blue(253) 0 Blue(254) 0 Blue(255) 0 Note (1) 0: Low Level Voltage, 1: High Level Voltage IDK-1110R-50XGB1 User Manual...
-
Page 24: Interface Timing
Note (1) Because this module is operated by DE only mode, Hsync and Vsync input signals should be set to low logic level or ground. Otherwise, this module will operate abnormally. Note (2) The Tv(Tvd+Tvb) must be integer, otherwise, the module will operate abnormally. IDK-1110R-50XGB1 User Manual... - Page 25 Input Signal Timing Diagram LVDS Timing Diagram Note (b) The Tv(Tvd+Tvb) must be integer, otherwise, the module will operate abnormally. IDK-1110R-50XGB1 User Manual...
- Page 26 Note (c) The Tv(Tvd+Tvb) must be integer, otherwise, the module will operate abnormally. IDK-1110R-50XGB1 User Manual...
-
Page 27: Power On/Off Sequence
(7)There might be slight electronic noise when LCD is turned off (even backlight unit is also off). To avoid this symptom, we suggest "Vcc falling timing" to follow "T7 spec". Table 2.8: Timing Specifications: Value Parameter Units IDK-1110R-50XGB1 User Manual... -
Page 28: The Input Data Format
The Input Data Format Note (1) R/G/B data 7: MSB, R/G/B data 0: LSB Note (2) Please follow PSWG IDK-1110R-50XGB1 User Manual... -
Page 29: Scanning Direction
The following figures show the image seen from the front view. The arrow indicates the direction of the scan. Fig.1 Normal Scan Fig.2 Reverse Scan Fig. 1 Normal scan (pin 7, RPFI = Low or NC) Fig. 2 Reverse scan (pin 7, RPFI = High) IDK-1110R-50XGB1 User Manual... - Page 30 IDK-1110R-50XGB1 User Manual...
-
Page 31: Chapter 3 Touchscreen
Chapter Touchscreen... -
Page 32: Touch Characteristics
Y axis: 200 ~ 800 (Film side) 1.5% max (initial value) Linearity Reference: 250gf 2.0% max (after environmental & life test) 20ms Max Chattering At connector pin Insulation Resistance min (DC 25V) IDK-1110R-50XGB1 User Manual... -
Page 33: Chapter 4 Touch Controller
Chapter Touch Controller... -
Page 34: Touch Controller Characteristics
Touch Controller Characteristics Advantech ETM-RES05C Touch Control Board is the ultimate combo board. This touch panel controller provides optimum performance for your analog resistive touch 4-wire model panels. It communicates with the PC directly through USB and RS-232 connectors. You can see how superior the design is through its sensitivity accuracy and friendly operation. -
Page 35: Environmental Features
5+5 pins header. The pins are numbered as shown in the table below. Signal Signal Function RS-232 Signal Signal Function Pin# Name Pin# Name Ground Ground USB Power Power Ground Ground USB D+ Serial Port USB D- Serial Port IDK-1110R-50XGB1 User Manual... -
Page 36: Combo Interface Connector, Jp1, Pins And Signal Descriptions 29 Figure 4.1 Board Mounted Header
The touchscreen connector, JP2, is a FFC/FPC SMD 1.0mm 4-pins 90°, Female type connector. The pins are numbered as shown in the table below. TS4 Pin # Signal Name Signal Description Bottom Left Right 4-Wire touchscreen ZIF connector 4-Wire Screen viewed from cover sheet side IDK-1110R-50XGB1 User Manual... -
Page 37: Appendix Alcd Optical Characteristics
Appendix LCD Optical Characteristics... -
Page 38: Test Conditions
ɵX- Viewing Angle ɵY+ Vertical ɵY- Definition: Grayscale Maximum: Grayscale 255 (10 bits: grayscale 1023; 8 bits: grayscale 255; 6 bits: grayscale 63) White: Luminance of grayscale Maximum (All R,G,B) Black: Luminance of grayscale 0 (All R,G,B) IDK-1110R-50XGB1 User Manual... - Page 39 The contrast ratio can be calculated by the following expression at cen- ter point. Contrast Ratio (CR) = White/Black Note Note (3) Definition of Response Time (T Note (4) Definition of Luminance of White (L Measure the luminance of White at center point. IDK-1110R-50XGB1 User Manual...
- Page 40 40 minutes in a windless room. The measurement placement of module should be in accordance with module drawing. Note (6) Definition of White Variation ( Measure the luminance of White at 5 points. Luminance of White: L(X), where X is from 1 to 5. IDK-1110R-50XGB1 User Manual...
-
Page 41: Appendix B Safety Precautions
Appendix Safety Precautions... -
Page 42: Assembly And Handling Precautions
Allowing moisture to enter or contact the LCD module is dangerous as moisture may damage the LCD module during operation. Ambient temperatures lower than 10 °C (50 °F) may affect performance. For example, the response time will slow, and the lamp starting voltage will be higher than room temperature. IDK-1110R-50XGB1 User Manual... -
Page 43: Other Precautions
Static information display recommended to use with moving image. Cycling display between 5 minutes of information for static displays and 10 sec- onds for moving images Abnormal condition means conditions not defined in normal conditions IDK-1110R-50XGB1 User Manual... - Page 44 IDK-1110R-50XGB1 User Manual...
- Page 45 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd.
