Summary of Contents for AJAX FireProtect 2

  • Page 1 Translated from Spanish to English - www.onlinedoctranslator.com English user Manual...
  • Page 3 10 years, and with replaceable batteries (it has RB in the name) with a duration of up to 7 years. The detector works as part of the Ajax security system, communicating with the hub via the secure Jeweler radio protocol. The communication range with the hub is up to...

  • Page 4: Functional Elements

    functional elements...
  • Page 5 2. Panel mounting SmartBracket. To remove the panel, rotate it to the left. 3. QR code and ID (serial number) of the device. It is used to connect the detector to the Ajax security system. 4. Tamper switch. It is activated by any attempt to pry the detector off the surface or remove it from the mounting panel.

  • Page 6: Operating Principle

    SmartBracket mounting panel: the detector reacts with the LED indication and sends notifications to the Ajax apps of the users and to the central monitoring station. The second tamper switch informs about the removal of the smoke chamber cover, located below the front panel of the detector.
  • Page 7 FireProtect 2 detectors can be used without connecting to an Ajax hub. Simply install the detector according to this manual and turn it on. When operating autonomously, the detector only notifies about fire with a built-in siren and LED indication and does not send notifications to the user's smartphone, Ajax Translator, or PRO Desktop.

  • Page 8: Temperature Sensor

    Temperature sensor Two built-in class A1 thermistors detect a rapid rise and exceeded temperature threshold of the FireProtect 2. These thermistors report alarms when a rapid rise in temperature or static temperature in the range of +54°C to +65°C is detected.
  • Page 9 LED indication for 12 hours. Interconnected alarm of fire detectors All fire detectors in the FireProtect 2 product line support the interconnected alarm function. This function activates the built-in sounders of all fire detectors in the system as soon as at least one of the fire detectors detects an alarm. The FireProtect 2 detectors' sirens sound for 20 seconds after the alarm is detected.
  • Page 10 To connect to the hub, the detector must be within the coverage area of the hub's radio network. To work through a radio signal repeater, first connect the detector to the hub and then to the repeater. You can do it in the signal repeater settings in Ajax apps.
  • Page 11 The FireProtect 2 only works with a hub. After connecting to a new hub, the detector stops transmitting data to the old hub. Once added to a new hub, the FireProtect 2 is not removed from the device list of the old hub. This must be done manually in Ajax...
  • Page 12 The siren emits Test/Silence or in the Red LED flashes 3 beeps to CO dangerous Ajax app. The alarm times every 3 same time as the cannot be silenced if the (monoxide of seconds. CO level exceeds 300 carbon).
  • Page 13 Sound plays after pressing the button Ban on Test/Silence. The Short, low beep muting the alarm cannot be tone. alarm. silenced if the CO level exceeds 300 ppm. The detector stops alerting the alarm as The red LED flashes Silenced alarm. soon as its every 8 seconds.
  • Page 14 All malfunctions show in The siren emits listener states in Ajax apps. beeps every Fields with malfunctions will The yellow LED failure of be highlighted in red. blinks 2 times...
  • Page 15 Silence button or in the more but longer self test. settings of the 3 times more but more slow. beeps. detector in the Ajax app. The device has worked during The siren emits 3 The device has The yellow LED more than 10 years.
  • Page 16 The test allows you to check the status of the detector's sensors. You can start it in two ways: by pressing the Test/Silence button on the detector and in Ajax apps. To initiate the test using the Test/Silence button, press the center of the front panel for 1.5 seconds.
  • Page 17 The Ajax security system provides various tests to select the proper installation location for the devices. For FireProtect 2 the Jeweler Signal Strength Test is available. The test allows to determine the intensity and stability of the signal in the place planned to install the device.
  • Page 18 The icons show some of the states of the device. You can see them in Ajax apps, on the Devices tab. Icon Meaning Jeweler signal strength between the detector and the hub (or radio signal repeater). The recommended value is 2 or 3 bars.
  • Page 19 Malfunction detected. The list of malfunctions is available in the detector states. Detector tamper switch activation events are temporarily disabled.
  • Page 20 The states include information about the device and its operating parameters. FireProtect 2 states (Heat/Smoke/CO) are available in Ajax apps. To access these: 1. Open the Ajax app. 2. Select a hub if you have several or if you use the PRO app.
  • Page 21 If rapid temperature rise has been detected, the text field will highlight red. CO (carbon monoxide) level in the room where FireProtect 2 is installed: No: normal CO level. Alarm: The detector has detected a dangerous high CO level level of CO. If the detector has detected a dangerous level of CO, the text field will highlight red.
  • Page 22 FireProtect 2 identifier (serial number). Also available on the detector housing (below the device ID mounting panel) under the QR code and on its box. Loop number (zone) of the FireProtect 2. This device № number is used to send the events to the ARC.
  • Page 23 Setting To change the FireProtect 2 settings (Heat/Smoke/CO), in the Ajax app: 1. Open the Ajax app. 2. Select a hub if you have several or if you use the PRO app. 3. Go to the Devices tab. 4. Select the device in the list.
  • Page 24 Jeweler wireless data transmission protocol. The recommended value is 2 or 3 bars. device self test Starts the automatic test of the detector. Opens the FireProtect 2 User Manual in the Ajax User's guide app. Allows you to temporarily disable the device without removing it from the system.
  • Page 25 Select the place of installation The coverage area of a FireProtect 2 (Heat/Smoke/CO) is 50 to 60 m², depending on the type of installation. The detector must be installed in each room. The detector is placed in the center of the ceiling at a distance of 30 cm from lighting fixtures, lamps, or any other decorative object that may interfere with alarm detection.

  • Page 26: Signal Strength

    Presence of obstacles between devices for the passage of the radio signal: walls, mezzanines, large objects located inside the room. When designing your facility's Ajax security system, follow device placement recommendations. The security system must be designed and installed by professionals.
  • Page 27 For example, in garages, where there is a possibility of the detector alarming due to vehicle exhaust gases. For such locations, we recommend using a detector without a smoke sensor: FireProtect 2 (Heat/CO). • In places with a lot of dust or insects. Insects, dust and other types of dirt can settle on the smoke chamber lid and prevent fire detection.
  • Page 28 Facility 1. Remove the SmartBracket mounting panel from the detector. To remove the panel, rotate it to the left. 2. Secure the SmartBracket panel to the surface using double-sided tape or other temporary fasteners. The mounting panel has an up sign (UP), which indicates the correct position of the panel.
  • Page 29 If a FireProtect 2 malfunction is detected (for example, no connection to the hub), the malfunction counter is displayed in the device field in Ajax apps. Malfunctions are displayed in the Detector States. Fields with malfunctions will be highlighted in red.

  • Page 30: Maintenance

    FireProtect2 Malfunctions (Heat/Smoke/CO) • The connection with the hub (or radio signal repeater) has been lost. • The detector cover is open. • Low battery charge level. • The device has reached the end of its useful life. • Hardware malfunction (one or more detector sensors are defective). Maintenance The detector has a self-test system and does not require the participation of the user or installer.
  • Page 31 Full kit 1. FireProtect 2 RB (Heat/Smoke/CO) Jeweler 2. Panel mounting SmartBracket 3. Installation kit 4. 2 CR123A batteries (pre-installed) 5. Quick guide...
