Great Plains
BD7410 Marker
INSTALLATION MANUAL
MODEL BD7410-13
Table of Contents
Original Instructions
!
Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
TP-80371
193-081M
Advertisement
Table of Contents
Related Manuals for GREAT PLAINS BD7410
Summary of Contents for GREAT PLAINS BD7410
- Page 1 Table of Contents Great Plains BD7410 Marker INSTALLATION MANUAL MODEL BD7410-13 TP-80371 193-081M Original Instructions Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Illustrations may show optional equipment not supplied with standard unit.
-
Page 2: Machine Identification
Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine. - Page 3 Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press. Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
- Page 4 Printed 09/05/2024 | English Great Plains reserves the right to revise and improve its products at any time. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future. The content of this publication may be...
- Page 5 Hydraulic Hookup) ..... . . 22 Torque Value Chart ..... . 23 Great Plains | 193-081M | 09/05/2024...
-
Page 6: Kit Description
193-064A BD7410 13’ Direct Hydraulic Hookup Assembly 193-073A BD7410 13’ Selector Valve Hydraulic Hookup Assembly One kit outfits one drill. Tools Required: • Lift or hoist with a capacity of no less than 600 pounds (227 kg) with an empty seed box •... -
Page 7: Safety Information
Non-Great Plains components on this machine may machine and advises on how to avoid it. contain additional safety information not found in this The notice symbol indicates a potential for manual. -
Page 8: Machine Use
Avoid contacting overhead obstructions such as low bridges, overpasses, and power lines. Do not operate near ditches, holes, steep slopes, embankments, or other surfaces which may collapse under the machine’s weight or tip the machine over. Great Plains | 193-081M | 09/05/2024... -
Page 9: Machine Maintenance
Detach the tractor. Secure the implement using Stay clear of and never step over any rotating parts. blocks. Great Plains | 193-081M | 09/05/2024... -
Page 10: Installation
5. Ensure that no materials are in the seed box. If there are, remove them. For Single Marker Installation, see “Single Marker Installation” on page 5. TP-80786 For Dual Marker Installation, see “Dual Marker Installation” on page 11. Great Plains | 193-081M | 09/05/2024... - Page 11 The loosened bolts will prevent the box so the nuts are at the end of the bolts. from lifting too high. This is to prevent damage to the drill. 4. On the LH side, remove the loosened bolts. TP-80785 TP-80787 Great Plains | 193-081M | 09/05/2024...
- Page 12 15. Tighten all 6 box mounting bolts (3 on each side). The loosened bolts will prevent the box Refer to “Torque Value Chart” on page 23. from lifting too high. This is to prevent damage to the drill. Great Plains | 193-081M | 09/05/2024...
- Page 13 17. Install cylinder as shown. The elbow hydraulic fitting (1), which is orificed, must attach at the rod-end of the hydraulic cylinder. The straight fitting (2) attaches at the base-end. Refer to “Single Marker Assembly” on page 20. TP-82034 Great Plains | 193-081M | 09/05/2024...
- Page 14 TP-80797 preexisting hose clamps. (3) will be mounted directly onto the frame. Longer screws will be TP-80797 available in the marker kit to replace previous screws for hose clamps (1) and (2). TP-80943 TP-80799 Great Plains | 193-081M | 09/05/2024...
- Page 15 (6). 6” hoses (851-920C) (7) are then used to connect one set of outlet ports on the Selector Valve (8) to the pressure relief valve T fittings that the lift/fold hoses were removed from (9). The marker hoses (10) Great Plains | 193-081M | 09/05/2024...
- Page 16 3. Lift the seed box 1 inch from the frame. The loosened bolts will prevent the box from lifting too high. This is to prevent damage to the drill. 4. On the LH side, remove the loosened bolts. TP-80764 TP-80787 TP-80786 Great Plains | 193-081M | 09/05/2024...
- Page 17 TP-80785 TP-80767 10. Lift the seed box 1 inch from the frame. The loosened bolts will prevent the box from lifting too high. This is to prevent damage to the drill. Great Plains | 193-081M | 09/05/2024...
- Page 18 14. Install 1/2 inch bolts to marker base. To tighten, see “Torque Value Chart” on page 23. TP-80790 TP-80808 15. Lower the RH side. 16. Tighten all 6 box mounting bolts (3 on each side). Refer to “Torque Value Chart” on page 23. Great Plains | 193-081M | 09/05/2024...
- Page 19 18. On the LH side, install cylinder as shown. The elbow hydraulic fitting (1), which is orificed, must attach at the rod-end of the hydraulic cylinder. The straight fitting (2) attaches at the base-end. Refer to “Single Marker Assembly” on page 20. TP-82034 Great Plains | 193-081M | 09/05/2024...
- Page 20 22. On the RH side, install marker arm to marker base. Refer to “Dual Marker Assembly” on page 21. TP-80797 TP-80797 TP-80802 TP-80799 21. On the LH side, attach hydraulic hoses to cylinder. There are two fittings on the cylinder Great Plains | 193-081M | 09/05/2024...
- Page 21 21. base-end. Refer to “Dual Marker Assembly” on page 21. TP-80801 24. On the RH side, assemble outer marker and marker disc. Refer to “Dual Marker Assembly” TP-80803 on page 21. TP-80805 TP-80804 Great Plains | 193-081M | 09/05/2024...
- Page 22 (3), (4), and (5) will be mounted directly onto the frame. Longer screws will be available in the marker kit to replace previous screws for hose clamps (1) and (2). TP-82001 TP-80943 TP-80958 Great Plains | 193-081M | 09/05/2024...
- Page 23 (851-920C) (5) are then used to connect one set of outlet ports on the Selector Valve (6) to the pressure relief valve T fittings that the lift/fold hoses were removed from (7). The marker hoses (8) are Great Plains | 193-081M | 09/05/2024...
- Page 24 For Selector Valve Hydraulic Hookup: B1 connects to the upper outlet port on the Selector Valve (10). A1 connects to the lower outlet port on the Selector Valve (11). TP-82007 32. Cycle marker. Refill tractor hydraulic reservoir as needed. Great Plains | 193-081M | 09/05/2024...
- Page 25 BD7410-13 Table of Contents Installation Single Marker Assembly Great Plains | 193-081M | 09/05/2024...
- Page 26 BD7410-13 Table of Contents Installation Dual Marker Assembly Great Plains | 193-081M | 09/05/2024...
- Page 27 BD7410-13 Table of Contents Installation Marker Hydraulics with Selector Valve Marker Hydraulics without Selector Valve (Direct Hydraulic Hookup) Great Plains | 193-081M | 09/05/2024...
-
Page 28: Torque Value Chart
1180 2640 1950 4290 3160 d. ft-lb = foot pounds ⁄ 1330 2970 2190 4820 3560 25199m 25199 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. Great Plains | 193-081M | 09/05/2024... - Page 29 Table of Contents...
- Page 30 Great Plains, Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402...
