Great Plains
BD7410
PRE-DELIVERY MANUAL
MODELS BD7410-13
TP-80371
Table of Contents
Original Instructions
!
Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
175-600q

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD7410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GREAT PLAINS BD7410

Summary of Contents for GREAT PLAINS BD7410

  • Page 1 Table of Contents Great Plains BD7410 PRE-DELIVERY MANUAL MODELS BD7410-13 TP-80371 175-600q Original Instructions Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Illustrations may show optional equipment not supplied with standard unit.
  • Page 2 Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press. Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
  • Page 3 Hitch ........10 Assembly Overview ....10 Great Plains | 175-600q | 03/07/2024...

  • Page 5: Intended Use Statement

    BD7410 Box Drill Table of Contents Introduction Introduction The BD7410-13 is a towed seeding implement. This Prohibited Use drill has a working width of 13 feet (3.9m) and folds Do not use this machine for any purpose or in any to a width of 9.5 feet (2.9m) for transport.

  • Page 6: Safety Information

     Non-Great Plains components on this machine may machine and advises on how to avoid it. contain additional safety information not found in this The notice symbol indicates a potential for manual.

  • Page 7: Machine Use

    Avoid contacting overhead obstructions such as low bridges, overpasses, and power lines.  Do not operate near ditches, holes, steep slopes, embankments, or other surfaces which may collapse under the machine’s weight or tip the machine over. Great Plains | 175-600q | 03/07/2024...

  • Page 8: Machine Maintenance

     Detach the tractor. Secure the implement using  Stay clear of and never step over any rotating parts. blocks. Great Plains | 175-600q | 03/07/2024...

  • Page 9: Location Requirements

    Hoist drill from above. Do not fork-lift beneath on the ground fully. drill. There are no suitable lift points. If machine was shipped without rockshaft tire assemblies installed, refer to “Install Hubs & Tires” on page 9. Great Plains | 175-600q | 03/07/2024...
  • Page 10 Assembly Overview Parts List Ref. Part No. Description 175-523H WALKBOARD, SINGLE STEP-1300EW 802-214C RHSNB 1/2-13X1 1/4 GR5 803-169C NUT HEX FLG. LOCK 1/2-13 PLT 151-295S LADDER ASSEMBLY 803-193C NUT HEX FLANGE 1/2-13 GR G PLT Great Plains | 175-600q | 03/07/2024...

  • Page 11: Transport Lights

    3. Connect the transport light connectors to the light harness. 1. Raise ladder assembly into position. 2. Secure ladder to walkboard using six sets of bolts and nuts. Great Plains | 175-600q | 03/07/2024...
  • Page 12 HUB 8-BLT SPNDL 2.75X15.63 608 802-044C HHCS 1/2-13X4 GR5 803-019C NUT LOCK 1/2-13 PLT 814-537C WHEEL 15X10 8 BOLT BUCKSKIN 802-182C HUB STUD 5/8-18X2 1/4 GR5 803-219C NUT LUG 5/8-18 X 90 DEG PLT Great Plains | 175-600q | 03/07/2024...
  • Page 13 Torque bolts to 265lb-ft. 3. Attach the hydraulic cylinder arm to the rockshaft as shown using pin (4) and washers (5). Secure each end of pin using cotter pins (6). Great Plains | 175-600q | 03/07/2024...
  • Page 14 1. Locate the hitch assembly (1) and align it with the end of the tongue. 2. Attach the hitch assembly to the tongue using bolts (2), flat washers (3), lock washers (4), and hex nuts (5). Great Plains | 175-600q | 03/07/2024...

  • Page 15: Pre-Setup Checklist

    Transport Lift / Fold  lighting connector to tractor outlet Opener Lift any optional or after-market electrical connectors.  These connections can be made in any order, and Green Marker must be made before moving the drill. Great Plains | 175-600q | 03/07/2024...

  • Page 16: Hydraulic System

    Great Plains dealer for service. Great Plains | 175-600q | 03/07/2024...

  • Page 17: Specifications

    32.8 bu (1156 liters) 17.7 bu (624 liters) front compartment rear compartment w/ offset to front divider 27.8 bu (980 liters) 22.7 bu (800 liters) Small Seeds Box 6.3 bu (222 liters) Great Plains | 175-600q | 03/07/2024...

  • Page 18: Torque Chart

    For assistance or Transport 320/70R15 73 psi 170 lb ft information, contact your nearest authorized farm tire retailer. 255/70R22.5 93 psi 170 lb ft Wheel Manufacturer Website Firestone www.firestoneag.com www.bkt-tires.com/en Goodyear www.titan-intl.com Great Plains | 175-600q | 03/07/2024...
  • Page 19 Table of Contents...
  • Page 20 Great Plains, Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402...
