Great Plains
Min-Till Drill
PRE-DELIVERY MANUAL
MODELS BD7600 40 Foot 3-Section Drill
Table of Contents
Original Instructions
!
Read the operator manual entirely. When you see
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
195-614Q

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD7600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GREAT PLAINS BD7600

  • Page 1 Table of Contents Great Plains Min-Till Drill PRE-DELIVERY MANUAL MODELS BD7600 40 Foot 3-Section Drill 195-614Q Original Instructions Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Illustrations may show optional equipment not supplied with standard unit.
  • Page 2 Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press. Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo- Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
  • Page 3 Section Control Hydraulics ....18 Hydraulic Drive Hydraulics ....19 Great Plains | 195-614Q | 04/14/2020...
  • Page 4: Description Of Unit

    Table of Contents Introduction Introduction Models Covered Great Plains wants you to be satisfied with any new machine delivered. To ease assembly and produce a BD7600-40 models with 60 rows on 6-inch row properly working machine, read this entire manual spacing, 48 rows on 7.5-inch row spacing, and 36...
  • Page 5: Safety Information

    Use additional safety equipment, such as hard hats, eye and ear protection, safety boots, etc., as needed. 8. Do not modify the machine. Unauthorized modification can result in unsafe conditions that lead to machine damage or personal injury. Great Plains | 195-614Q | 04/14/2020...
  • Page 6: Maintenance

    4. Stay clear of and never step over any rotating pressures. parts. 4. When removing and installing wheels, use wheel- handling equipment adequate for weight involved. 5. Tighten wheel bolts only to the specified torque. Great Plains | 195-614Q | 04/14/2020...
  • Page 7: Shutdown And Storage

    8. When towing on a trailer, secure implement with tie downs and chains. 9. When towing on a trailer, sudden braking can cause a trailer to swerve and upset. Reduce speed if trailer is not equipped with brakes. Great Plains | 195-614Q | 04/14/2020...
  • Page 8: Before Starting

     Hoist straps with proper load rating. transport position before unloading the drill. 4. Unload the mainframe/wing assembly from the truck. Place onto level ground with enough clearance to unfold the drill. Great Plains | 195-614Q | 04/14/2020...
  • Page 9 3. Repeat with the other shipping bracket. 71804 4. While the rockshaft is jacked up, install the two end rockshaft tires (4). Torque the wheel bolts to 170 lb-ft. 5. Carefully lower the jack and remove. 71805 Great Plains | 195-614Q | 04/14/2020...
  • Page 10 5. Connect truss tubes (5) to the drill tongue and 6. Take slack out of the truss tubes by adjusting the center section as shown using clevis pins (6) and turnbuckles (7). Do not over-tighten. cotter pins. 71807 Great Plains | 195-614Q | 04/14/2020...
  • Page 11 5/16-inch x 2 1/2-inch long bolts (12), 3/4 OD bushings (13), and flange nuts (14). You should have one left and one right gas spring cover with lights, and one left and one right gas 71811 Great Plains | 195-614Q | 04/14/2020...
  • Page 12: Install Ladder

    1. Install the gas spring anchor (1) using two 5/16-inch x 1-inch long round-head square-neck 71809 bolts (2) and flange nuts (3). 6. Repeat the above steps for the other end of the center walkboard. Great Plains | 195-614Q | 04/14/2020...
  • Page 13: Install Press Wheels

    1. Check that there is enough clearance to unfold the drill. 2. Verify that the opener frames are raised and locked up (handles in ROAD position). 3. Slowly unfold the wing frames by completely extending the fold cylinders. Great Plains | 195-614Q | 04/14/2020...
  • Page 14 (page 23). long bolts (6), flat washers (7), lock washers (8), 1. Fit the transfer drive breakaway clutch to the and nuts (9). center drive breakaway clutch (1). 71813 Great Plains | 195-614Q | 04/14/2020...
  • Page 15 40 Foot 3-Section Drill Table of Contents Assembly  Electrical Harness Schematics Connect all electrical harnesses. Also refer to the parts manual for parts reference. Lighting 71368B Scale 71815 Great Plains | 195-614Q | 04/14/2020...
  • Page 16 40 Foot 3-Section Drill Table of Contents Assembly Daisy Chain Blockage System 71816 Daisy Chain Blockage System with Fertilizer 71817 Great Plains | 195-614Q | 04/14/2020...
  • Page 17 40 Foot 3-Section Drill Table of Contents Assembly Loup Blockage System 71818 Great Plains | 195-614Q | 04/14/2020...
  • Page 18 40 Foot 3-Section Drill Table of Contents Assembly Loup Blockage System with Fertilizer Great Plains | 195-614Q | 04/14/2020...
  • Page 19 40 Foot 3-Section Drill Table of Contents Assembly  Hydraulics Schematics Connect all hydraulic hoses and components. Also refer to the parts manual for parts reference. Opener Lift - Open Center Hydraulics P3 P1 71532 Great Plains | 195-614Q | 04/14/2020...
  • Page 20 40 Foot 3-Section Drill Table of Contents Assembly Opener Lift - Closed Center Hydraulics P3 P1 71533 Great Plains | 195-614Q | 04/14/2020...
  • Page 21 40 Foot 3-Section Drill Table of Contents Assembly Section Control Hydraulics 71531 Great Plains | 195-614Q | 04/14/2020...
  • Page 22 40 Foot 3-Section Drill Table of Contents Assembly Hydraulic Drive Hydraulics 71531B Great Plains | 195-614Q | 04/14/2020...
  • Page 23: Hydraulic Hose Connections

    Do not stand or place any body part between drill and moving tractor when hitching drill. Keep others away. Stop tractor engine and set parking brake before installing hitch pins, attaching harnesses and hoses. TP-71826 Great Plains | 195-614Q | 04/14/2020...
  • Page 24 Install the hitch (1) onto the tongue and secure with the bolt (2), lock washer, and nut. Assemble the safety chain (3) and washer (4), and secure with the longer bolt (5), lock washer, and nut. 71337 Great Plains | 195-614Q | 04/14/2020...
  • Page 25 Loosen the jam nut and adjust the stop bolts in or out until the outside ends of the boxes are 1 to 1-1/4 inch (2.5 cm to 3.2 cm) ahead of the inside ends. 71439 Great Plains | 195-614Q | 04/14/2020...
  • Page 26 (4) until the jaws (5) make full contact bars. without compressing the clutch spring (6). If adjustment is necessary, adjust the truss length at the front of the clevis end (2). 71341 71343 Great Plains | 195-614Q | 04/14/2020...
  • Page 27 1. Park the drill on a clean, level surface. 2. Adjust the nut (1) threaded on the adjustment bolt as necessary to level the walkboard. 71828 Great Plains | 195-614Q | 04/14/2020...
  • Page 28: Torque Chart

    For assistance or Transport 380/55R16.5 73 psi 170 lb ft information, contact your nearest authorized farm tire Gauge Wheel 340/6R16.5 73 psi 76 lb ft retailer. Manufacturer Website Firestone www.firestoneag.com www.bkt-tires.com/en Goodyear www.titan-intl.com Great Plains | 195-614Q | 04/14/2020...
  • Page 29 Table of Contents...
  • Page 30 Great Plains, Mfg. 1525 E. North St. P.O. Box 5060 Salina, KS 67402...
