Charge Amps Dawn Professional DE Installation Manual

Hide thumbs Also See for Dawn Professional DE:
Table of Contents

Advertisement

Quick Links

Download this manual
Charge Amps Dawn Professional DE
Installation
English
Manual
Charge Amps Dawn Professional DE 131626
www.chargeamps.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dawn Professional DE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charge Amps Dawn Professional DE

Summary of Contents for Charge Amps Dawn Professional DE

  • Page 1 Charge Amps Dawn Professional DE Installation English Manual Charge Amps Dawn Professional DE 131626 www.chargeamps.com...

  • Page 2: Table Of Contents

    English Table of content Safety Technical data Product overview Package contents Before installation Recommended tools Materials provided by installer Mounting requirements Electric requirements 4.4.1 Short circuit safety - internal MCB installation 4.4.2 Short circuit safety - external MCB installation 4.4.3 Residual current safety Internet access 4.5.1...
  • Page 3 English Configuration Direct connection 6.1.1 Create a Cloud backend account 6.1.2 Configure the charger using Charge Amps Installer app 6.1.3 Finish the configuration in the selected Cloud backend CEaaS connection 6.2.1 Create a Cloud backend account 6.2.2 Create a Charge Amps Partner Account 6.2.3...
  • Page 4 Neglecting to follow and carry out the directions, instructions and safety precautions in this Installation Manual implies that any warranty provisions will be cancelled and that Charge Amps AB can reject any and all claims for compensation in connection with any injuries/damage or incidents – direct or indirect –...
  • Page 5 English Measurement device EU Declaration of Conformity...
  • Page 6 English MessEV Declaration of Conformity...

  • Page 7: Safety

    English Safety WARNING: Read all instructions before installation! • The product must only be installed by a qualified electrician in accordance with the Installation Manual. • Make sure to switch the power off at the main switch before installation or service. •...

  • Page 8: Technical Data

    English 2 Technical data Charging mode Mode 3 EV power supply identifier Metering MID 3-phase certified active electrical energy meter Eichrecht certified Socket Type 2, 22 kW Rated voltage (U 230/400 V Rated insulation voltage (U 250/400 V Rated impulse withstand voltage 4 kV Rated frequency (f 50 Hz...
  • Page 9 English Electromagnetic environment E2 according to MID Directive, classification Annex I, 1.3.3 Operating temperature -35°C to +45°C Altitude 0 m to 2000 m IP code IP54 IK code IK10 Mechanical resistance High Mechanical environment M2 according to MID Directive, classification Annex I, 1.3.2 Dimensions (W x D x H) 250 x 145 x 380 mm...
  • Page 10 English RFID Type: ISO/IEC 14443 Typ A 13.56 MHz Mifare Range: 13.553 – 13.567 MHz Max output: 24 dBm Bluetooth Type: Class 2 Version: v4.2 Range: 2400 – 2500 MHz Max output: 4 dBm Wi-Fi Type: 802.11 b/g/n Range: 2400 – 2500 MHz Max output: 17.5/14/12.5 dBm@802.11 b/g/n LAN (Ethernet 10Base-T/100Base-TX) Cat5e &...
  • Page 11 English The charging power is subject to external conditions, such as outside temperature, car battery state of charge, or if there’s a load balancing function or charging schedule applied. Output current derating factor in relation to ambient temperature in below diagram. For daisy chaining, the incoming current can be up to 63 A.

  • Page 12: Product Overview

    English 3 Product overview Back plate EV socket MID display Socket lights RFID reader EV socket lid RFID light Front cover lock screw Front cover...

  • Page 13: Package Contents

    English 3.1 Package contents Charge Amps Dawn Professional DE (hereafter referred to as Charge Amps Dawn) comes with an MCB, cable connection block, and terminal block for daisy chaining pre-installed. See next page for a detailed list of included package content.
  • Page 14 English Front cover Charging unit Accessories: • 2x M32 Cable glands • 2x M32 plugs • 1x M12 Cable gland • 2x M12 plugs • 2x M32 insert only • 8x M4 screws Back plate Following items comes pre-installed on the Back plate: 1x Connection block 1x Terminal block for Daisy 1x MCB...

  • Page 15: Before Installation

    English 4 Before installation 4.1 Recommended tools • Screwdriver Torx T20 + T25 • Screwdriver PH2 • Step drill (∅12 mm for LAN cable and ∅32 mm for power cable) (NOTE: only applicable for top cable entry holes) • Drill •...

  • Page 16: Materials Provided By Installer

    • RJ45 plug, max. 30 mm (only applicable when connecting Charge Amps Dawn to the internet via LAN connection). 4.3 Mounting requirements • If possible, do not mount the Charge Amps Dawn in direct sunlight. • Make sure the wall can support a weight of 3.5 kg and the tractive force from the inserted cabling.

  • Page 17: Electric Requirements

    N.B: Local regulations might add additional requirements for the electrical installation. • Charge Amps Dawn must be earthed through permanent electrical installation. • Only insert the electrical cable through the specified cable entry. • If installing one Charge Amps Dawn, follow instructions for Single installation. Single installation...

  • Page 18: Short Circuit Safety - Internal Mcb Installation

    English • If daisy chaining several Charge Amps Dawn, follow instructions for Daisy chain installation. • The incoming current of the daisy chain installation can be up to 63 A. Daisy chain installation 4.4.1 Short circuit safety - internal MCB installation...

  • Page 19: Residual Current Safety

    If an upstream RCD is required, it is recommended to be selected as follows: • If selectivity in relation to the built-in RCD in Charge Amps Dawn is required: RCD Type A Type S, 100mA or 300mA. • If selectivity in relation to the built-in RCD in Charge Amps...

  • Page 20: Internet Access

    Charge Amps Dawn. When chosing the type of internet connection, consider following: • Charge Amps Dawn with LAN connection provides a speed of up to 100 Mbps. • Charge Amps Dawn IEEE 802.1b/g/n Wi-Fi has a maximal speed of ~65 Mbps during ideal conditions •...

  • Page 21: Wi-Fi Connection

    IMPORTANT! Small adjustments of the location of Charge Amps Dawn might have significant effect on the Wi-Fi signal. Wi-Fi connection is available and the placement of Charge Amps Dawn is key to solid Wi-Fi connectivity. Before installing Charge Amps Dawn: 1.

  • Page 22: Lte-M Connection

    (LPWA), connection is available and requires public land mobile network (PLMN) coverage with reliable signal strength and quality. The first time the Charge Amps Dawn attach to the PLMN it will require some additional time (up to ten minutes) due to the LTE-M network attachment procedure.

  • Page 23: Lan Connection

    Make the measurement as close to the real installation as possible, e.g. with the garage door closed. 2. If you can’t find a good location for Charge Amps Dawn, you might need to use Wi-Fi or LAN connectivity. 4.5.3 LAN connection It is possible to connect Charge Amps Dawn via LAN connection, which is the most reliable option for internet connectivity.

  • Page 24: Installation

    N.B: Make sure to place front cover and charging unit in a place where they will not be damaged. 1. Unpack Charge Amps Dawn and make sure that Charge Amps Dawn is in good condition. 2. Carefully lift the charging unit and place it in a place where it won’t be damaged.
  • Page 25 English 3. Make sure the mounting surface is flat. Max. deviation for the four mounting holes is 3 mm. No other part of the surface should be in contact with the charger. The surface must also cover the area within the rim on the back side of the Charge Amps Dawn.

  • Page 26: Connection

    English 5.2 Connection WARNING! Make sure that the power is turned off at the main switch and that the feed cable is isolated! N.B: Installation shall only be performed by a qualified electrician. 5.2.1 Cable connection N.B: Local regulations for the electrical installation should always be followed! There are are three options for cable entry, via the bottom, top or back side.
  • Page 27 English Example of three phase connection: TN/TT TN/TT - daisy chain Example of single phase connection: TN/TT TN/TT - daisy chain...

  • Page 28: Bottom Cable Entry

    English 5.2.2 Bottom cable entry 1. Insert and connect the cables. Single installation Daisy chain installation...
  • Page 29 English N.B: Make sure the cables are straight after the cable gland to avoid strain on the cable glands and plastic parts. Important! Make sure to cover non used cable entries with suitable plugs found in the Accessories kit.

  • Page 30: Top Cable Entry

    English 5.2.3 Top cable entry 1. Drill hole(s) according to the markings on the top using a step drill (Power cable: ∅32 mm). 2. Insert and connect the cables. N.B: Make sure the cables are straight after the cable gland to avoid strain on the cable glands and plastic parts.
  • Page 31 English Single installation Daisy chain installation...
  • Page 32 English Important! Make sure to cover non used cable entries with suitable plugs found in the Accessories kit.

  • Page 33: Back Side Cable Entry

    English 5.2.4 Back side cable entry 1. Make appropriate sized holes in the membrane using a suitable tool. Ø 7mm Ø 12mm Ø 16mm Ø 21mm...
  • Page 34 English 2. Insert and connect the cables. Single installation Daisy chain installation...
  • Page 35 English Important! Make sure to cover non used cable entries with suitable plugs found in the Accessories kit.

  • Page 36: Connect The Lan Cable

    1. Thread the LAN cable through your designated cable entry: IMPORTANT! It is not possible to daisy chain the power supply for Charge Amps Dawn if pulling the LAN cable from the top or back side of Charge Amps Dawn.
  • Page 37 English Top LAN cable entry: Back side LAN cable entry:...
  • Page 38 English 2. Remove the rubber grommet from the LAN module. 3. Make a hole in the rubber grommmet using a screwdriver or similar.
  • Page 39 5. Secure the LAN cable in the cable clips and make sure the LAN cable is seated properly to avoid squeezing. 6. Connect the LAN cable to the LAN module and proceed to chapter 5.5 to reassemble Charge Amps Dawn.

  • Page 40: Reassemble

    English 5.3 Reassemble 1. Insert the charger unit back on to the back plate and secure in place by tightening the 8 screws. IMPORTANT: If using LAN connection, make sure to not squeeze the LAN cable. 2. IMPORTANT: Remove the peel off label located on the lid of the charging socket.
  • Page 41 English 6. Perform functionality tests using an EVSE tester 7. Test the internal RCD according to the Charge Amps Dawn Professional DE User Manual instructions 8. Insert the front cover bottom flange and rotate the cover in place. Secure in place by tightening the front cover lock screw using Torx 25.

  • Page 42: Configuration

    For more information on these options and how to configure them, please contact a Charge Amps sales representative. Before you can register Charge Amps Dawn in the selected Cloud backend, Charge Amps Dawn needs to be connected to the internet and configured using the Charge Amps Installer app or the Installation Wizard in Charge Amps Cloud.

  • Page 43: Direct Connection

    20 minutes, a restart of Charge Amps Dawn is required to re-activate the Bluetooth interface. 1. Download the Charge Amps Installer App via Google Play or App Store (see chapter 8. for links to the Installer App).

  • Page 44: Finish The Configuration In The Selected Cloud Backend

    English 3. Select the Charge Amps Dawn you wish to configure and enter the PIN code. (The PIN code can be found on the peel-off label located on the lid of the charging socket). 4. Follow the instructions given in the Installer App to enter details about the electrical settings and to configure the internet connectivity for Charge Amps Dawn.

  • Page 45: Ceaas Connection

    Charge Amps Dawn. 1. Create a Cloud backend account (see chapter 6.2.1) 2. Create a Charge Amps Partner account (see chapter 6.2.2) 3. Configure the settings of the charger using either: • Charge Amps Installer App (see chapter 6.2.3) •...

  • Page 46: Create A Charge Amps Partner Account

    If you already have a Charge Amps Partner Portal account, use your login credentials to log in. If you don’t have a Charge Amps Partner account, follow the steps below to create an account: 1. Click on the link below and navigate to the top right corner of the webpage to set your language preference: https://my.charge.space/partner/...

  • Page 47: Configure The Charger Via The Installation Wizard

    English 3. Select the Charge Amps Dawn you wish to configure and enter the PIN code. (The PIN code can be found on the peel-off label located on the lid of the charging socket). 4. Follow the instructions given in the Installer App to enter details about the installation and to configure the internet connectivity for Charge Amps Dawn.

  • Page 48: Activate Ceaas And Set Cloud Backend

    English 6.2.5 Activate CEaaS and set Cloud backend To connect Charge Amps Dawn via CEaaS you need to set the selected Cloud backend as CEaaS backend. 1. Log in to Charge Amps Partner portal 2. Use the menu in the top right corner to navigate to the Charger-page 3.

  • Page 49: Finalize The Installation

    English 7 Finalize the installation IMPORTANT! In accordance with German Measurement and Calibration Law, the operator and e-mobility service provider of Charge Amps Dawn must comply to the requirements stated in this chapter! Charging station operator requirements Measurement accuracy notes in accordance with the type...
  • Page 50 English 5. The user of this product must ensure that the calibration validity periods for the components in the charging device and for the charging device itself are not exceeded. 6. The user must permanently store the signed data packets read from the loading device - in accordance with the pagination - on hardware in his possession dedicated for this purpose (‘dedicated memory’), - keep them available for authorised...

  • Page 51: Charging Station Service Provider Requirements

    English 7.2 Charging station service provider requirements || Requirements for the user of the measured values from the charging device (EMSP) The user of the measured values must comply with § 33 of the MessEG: § 33 MessEG (quote) § 33 Requirements for the use of measured values (1) Values for measured quantities may only be stated or used in commercial or official dealings or in measurements in the public interest if a measuring instrument has been used as intended to...
  • Page 52 English For the user of the measured values, the following specific obligations arise from this regulation regarding the use of measured values in compliance with calibration law: 1. The contract between EMSP and the customer must clearly state that only the supply of electrical energy and not the duration of the charging service is the subject of the contract.
  • Page 53 English 7. The EMSP may only use values for billing purposes that are available in any existing dedicated storage in the charging facility and or the storage at the operator of the charging facility. Substitute values may not be created for billing purposes.

  • Page 54: Additional Information

    Please download Charge Amps Installer App, available in App store and in Google Play. Charge Amps Partner Portal Please create an account in the Charge Amps Partner Portal to configure, control and manage your charger via our web interface. Partner Portal https://my.charge.space/partner/...

  • Page 55: Dismounting

    • Do not use detergent to clean any of the product’s components. • Test the internal RCD (twice a year). See the instructions for how to test and reset the internal RCD in Charge Amps Dawn Professional DE User Manual.

  • Page 56: Product Support And Service

    2. If you need service or repair, start by contacting the supplier from whom you purchased the product. 3. For additional information, visit Charge Amps Help Center at: www.chargeamps.com/support. 12 Warranty Warranty terms may differ from market to market. Contact your...
  • Page 57 Charge Amps AB (publ) Frösundaleden 2B, 8th floor SE–169 75 Solna, Sweden Doc. Nr: 131650 © Copyright Charge Amps AB. Rev: 04 All rights reserved...
