X-3 SERIES SPACE SAVING RACK
X3BDUP80-X3SSR12, X3BDUP80-X3SSR28, X3BDUP80-X3SSR24,
X3BDUP90-X3SSR12, X3BDUP90-X3SSR28, X3BDUP90-X3SSR24,
X3BDUP80-X3SSR12-X3SSRSB12, X3BDUP80-X3SSR18-X3SSRSB18,
X3BDUP80-X3SSR24-X3SSRSB24, X3BDUP90-X3SSR12-X3SSRSB12,
X3BDUP90-X3SSR18-X3SSRSB18, X3BDUP90-X3SSR24-X3SSRSB24
400279, 400280, 400281, 400276, 400277, 400278, 401397, 401398, 401399,
401400, 401401, 401402
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Advertisement
Related Manuals for Titan Fitness X3 Series
Summary of Contents for Titan Fitness X3 Series
- Page 1 X-3 SERIES SPACE SAVING RACK X3BDUP80-X3SSR12, X3BDUP80-X3SSR28, X3BDUP80-X3SSR24, X3BDUP90-X3SSR12, X3BDUP90-X3SSR28, X3BDUP90-X3SSR24, X3BDUP80-X3SSR12-X3SSRSB12, X3BDUP80-X3SSR18-X3SSRSB18, X3BDUP80-X3SSR24-X3SSRSB24, X3BDUP90-X3SSR12-X3SSRSB12, X3BDUP90-X3SSR18-X3SSRSB18, X3BDUP90-X3SSR24-X3SSRSB24 400279, 400280, 400281, 400276, 400277, 400278, 401397, 401398, 401399, 401400, 401401, 401402 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception.
- Page 2 PARTS DIAGRAM / EXPLODED VIEW AVAILABLE IN 12", 18", 24" DEPTHS DESCRIPTION DESCRIPTION CONNECTING FRAME SHORT PLASTIC PLATE 58*48*5 DIAGONAL BRACE (10) FLAT WASHER Φ17*Φ30*3 PULL UP BAR (11) SPRING WASHER Φ16 LEFT J-HOOK (12) NUT M16 RIGHT J-HOOK (13) HEX BOLT M16*110 LONG PLASTIC PLATE (14)
- Page 3 ASSEMBLY INSTRUCTIONS STEP 1 Assemble the Connecting Frame (1), Diagonal Brace (2) and Upright Frame (16) using Flat Washer Φ17*Φ30*3 (10), Spring Washer Φ16 (11) Nut M16 (12) and Hex Bolt M16*120 (14).
- Page 4 STEP 2 Connect Pull Up Bar (3) and Diagonal Brace (2), using Flat Washer Φ17*Φ30*3 (10), Spring Washer Φ16 (11), Nut M16 (12) and Hex Bolt M16*110 (13). PLEASE TIGHTEN ALL THE BOLTS.
- Page 5 STEP 3 Install the Left & Right J-HOOK (4 & 5) on Upright Frame (16).
- Page 6 PARTS DIAGRAM / EXPLODED VIEW BOTTOM SIDE BRACES AVAILABLE IN 12", 18", 24" DEPTHS DESCRIPTION CONNECTING FRAMES FLAT WASHER Φ17*Φ30*3 SPRING WASHER Φ16 NUT M16 HEX BOLT M16*120...
- Page 7 ASSEMBLY INSTRUCTIONS STEP 1 Install the 12”, 18”, or 24” Connecting Frame (1) on the Upright Frame (16). Use the Flat Washer Φ17*Φ30*3 (2), Spring Washer Φ16 (3), Nut M16 (4) and Hex Bolt M16*120 (5). NOTE: MOUNTING HARDWARE IS NOT INCLUDED.
- Page 8 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 9 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2024 Titan Brands...
