3. GENERAL DESCRIPTION
The DIGIMIG 202 M-POWER synergic welding machine is used for manual welding of steel and non-ferrous metals.
It allows welding using the MMA (covered electrode), TIG Lift, and MIG/MAG methods. The MIG/MAG method can be used in
manual and synergistic mode. Thanks to the change of polarity, the device allows welding using the MIG/MAG method using both
standard wires in a protective gas shield and self-shielding flux-cored wires.
The welder allows for the connection of a Spool Gun (SG) with a mini wire feeder and a D100 spool of steel or colored wire.
The device allows you to remember 10 sets of welding parameters and is equipped with a Fan Stop function that turns off the fan at
low welding load, which reduces noise and improves user comfort.
The welding machine is intended for use in closed or roofed rooms, not directly exposed to atmospheric influences.
4. TECHNICAL PARAMETERS
4.1 Welding machine
Supply voltage:
Maximum power consumption:
Rated welding current:/ duty cycle
No-load rated voltage Wire spool diameters:
Maximum current consumption:
Network security
Weight (without accessories):
Dimensions [mm]:
Degree of protection:
4.1.1 Parameter adjustment ranges
Welding current:
Welding voltage:
Wire feed speed:
Inductance:
Spot welding time
ARC FORCE (MMA):
HOT START (MMA)
VRD
AC 230V 50Hz
MIGÿ8.2kVA
MMAÿ8.4kVA
TIGÿ6.2kVA
MIG: 200A / 60%; MMA: 180A / 60%; TIG: 200A / 60%
59 V
100mm, 200mm
MIG: 35.7 A; MMA: 36.4 A; TIG: 26.8 A 25 A
10.1 kg
450x220x350
MIG: 30 – 200 A; MMA: 20 – 180 A; TIG:10 – 200 A
MIG: 15.5 - 24V
2 – 14 m/min
-10 - +10
0.1 - 20 sec
0-100
0-50
on – off
IP21
