F – Electrode wire diameter selection button
Button active only during MIG/MAG welding in S-MIG and SPOOL GUN modes. Used to select the electrode wire
diameter.
G – Welding method selection button
The button is used to select the welding method. Selection of the appropriate mode is confirmed by lighting up the
control diode.
7. PARAMETER SETTINGS
7.1 MMA method
After selecting the MMA method, it is possible to adjust the welding current, the HOT START and ARC FORCE functions
and to enable/disable the /VRD function.
MIG welding with manual selection of settings.
MIG/MAG welding using synergistic settings. The device selects welding parameters depending
on the selected type and thickness of material.
These parameters can be changed by the user.
MIG/MAG welding using the SPOOL GUN holder (optional).
Welding with coated electrode
TIG Lift welding (non-consumable electrode)
