Before starting each build-stage check that you have the right quantity and size of items for the build-stage. To assist you with assembling your A800RR car, we have included full-size images of all the small hardware components. You can place each part directly on the images to easily verify their size and length..
Page 3
Note these items at assembling of the car. Note the shoulder ST112 screws - used for fastening only B106RS dampers (STEP 4) and bulkheads (STEP 11) ball bearing to the lower deck! 5,9 mm 5,8 mm 5,2 mm 10 mm ST122-1 ST019 ball bearing...
Page 4
STEP 1 - Assembling of the D4 Dampers D4 dampers feature external switching between linear, progressive and semi-progressive damping modes without the need for disassembly. See page 28 for setup technique. Insert OR2010V o-ring into the upper cavity of AM242R/L-D4 case. Lubricate ST143 with a small amount of silicon oil. Note that one OR1010V o-ring is already factory installed on each ST143.
Page 5
Either attach P67-D4 stand to three P14-2 posts (cut to ~43mm length) or directly replace one of the original plate by P67-D4. SB3X6 x2 SB3X6 x3 P67-D4 P67-D4 TIP / Recommended items: MAX-02-003 - MXLR Awesomatix A800R ShockVac P14-2 x3 MAX-01-003 - MXLR O-Ring grease (for P63 & OR52V)
Page 6
Install the dampers on the air remover stand and keep them vertically. We recommend 300 cst silicone oil as a base. Fill up the dampers with the desired silicone oil. The oil level should reach the top face of AT243-D4 and AT241 at this stage. Make sure to also fill up the cavity over P63-R piston.
Page 7
Install ST102F (longer part) onto the front dampers and ST102R (shorter part) onto the rear dampers. Tighten SC2X8 screw until contact, then add ¼ of a turn (ensuring coupling between ST102 and AT241 is done by friction, and not by the screw acting as a pin). Keep the damper vertically and swing AT241 rotor a few times in both directions.
Page 8
STEP 2 AT21ST-A x4 Note: C01B-RC Carbon Lower Deck is included in the A800RR kit. SH1.0 x4 C01B-RAF Alloy Lower Deck is included in the A800RRA kit. FRONT AT21ST-A x4 SH0.5 x4 SH1.0 x4 SF3X6 x4 SF3X8 x4 Combinations of SH0.5, SH1.0 and SH1.75 spacers under AT21ST-A balls are used to REAR adjust the car’s roll center.
Page 9
STEP 5 Note: P12X Up-travel limter extension tips are trimmable to access extended up-travel range. Use side cutters or sharp hobby knife to trim the end tip.Highly recommended P12X for high roll centre settings (above 3 mm under AT21ST-A) see fig #1. P12X P12X SF3X8...
Page 10
STEP 8 Optional OR14V rubber o-rings can be used instead of P07 clips. snap OR14V snap Snap P07 clips. Double check once more for free movement of the lower arms! STEP 9 Slide ST205 shaft through SPR01 eylet and ST102 hole. ST205 Prepare 2 sets with this layout ST205...
Page 11
STEP 11 ST112 x4 ⚠Attention: Use ST112 centering screws for AM278 bulkheads mounting. ST112 x4 ST24 x2 AM278-EVO x2 ⚠Note: Install ST24 ballstuds into AM278-EVO bulkheads before bolting AM278-EVO onto the chassis! AM278-EVO STEP SS3X3 AM278-EVO x2 Insert SS3X3 set screw into AM278-EVO bulkhead as shown (protruding 1mm).
Page 12
TIP / Recommended items: Thread Lock for MAX-01-003 - MXLR O-Ring grease (for OR05V) these screws. B106RS MAX-02-002 - MXLR Awesomatix TC Multi Tool STEP 15 STEP 16 TIP / Recommended items: MAX-01-001 - MXLR Ball Bearing oil Fill up with the desired silicone oil (not included).
Page 13
STEP 17 AT03R Spool Axle ⚠ Attention: note P138A orientation and the holes for SC2X4 screws! SF3X8 Thread Lock ST37X B106RS AT03R B106RS ST37X P138A TIP / Recommended items: SC2X4 x3 MAX-01-001 - MXLR Ball Bearing oil SF3X8 Note the correct orientation of AT03 R Axle in relation to Attention! P138 A Pulley.
Page 14
STEP 19 SB3X5 x4 AM19-R x2 ⚠ Attention: This recess on AM19-R should be oriented downward. BEL351B SB3X5 x4 AM19-R x2 BEL351B Note the correct layout of belts, differential and spool! front belt rear belt Initial position of rear P110 Initial position of front P110 Note this Note this...
Page 15
STEP 20 ST59 SH1.0 B73SS B73SS SH0.5 ST59 STEP 21 Note: SWB-R-1.3 - three strips Note: Do not tighten SS3X3 set screws at this stage. SWB-R-1.2 - two strips SWB-R-1.1 - one strip SS3X3 SWB-R-1.0 - no strips B63SS SS3X3 AT142 AT142 SWB-R-1.2...
Page 16
Optional BSSX steering SB3X5 x2 system can be used with optional AM24-8 servo BSSX set holder and AT52A posts. AT52A x2 SH1.75 x4 AM24-8 SH1.0 x2 SF3X10 x2 Awesomatix A700L/A701L can be used with optional AM152 steering stand. AM152 SF3X5 x2...
Page 17
These bridges can be cut on ST019 both top decks recess to increase torsional flex. Note: C127 top decks are included in A800RR kit. REAR C127S top decks are included in A800RRA kit. STEP 28 FRONT ST24 x4 ST24 x4 SH1.0 x4...
Page 18
STEP 29 Front left steering knuckle Rear right steering knuckle ST03 ST03 AT21ST-A SB3X5 SH1.0 SH1.0 SH1.0 AM23-1 SB3X5 SH1.0 SH1.0 AM14LS SB3X6 SH1.75 ST24 AM06WL SH0.5 AM06WL ST24 ST03 ST03 Attention: The last turns of the lower ST03 Ball Studs and SB3X5 screws can be tight. Screw them on with force! ST03 Note: Other combinations of SH0.5, SH1.0 and SH1.75 spacers can be installed under...
Page 19
Tighten ST38US nuts with fingers. ST38US ST01 ST16 PIN01 ST17-1US ST16 PIN01 ST38US ST113 TIP / Recommended items: MAX-01-002 - MXLR Driveshaft & Gears oil MAX-02-002 - MXLR Awesomatix TC Multi Tool Build two front drive shafts Front drive shafts for US-spec kits...
Page 20
2. Take out/insert ST16 u-joint cross SPR07 from/into unclamped ST02 rear axle. Tip: Insert a 2.5mm flat screwdriver (or tail end of Awesomatix T01 wrench) into ST02 slot then rotate 90° to open it up. Build two rear drive shafts...
Page 21
STEP 32 B106RS B106RS SH0.1 AT13 SC2X6 Note: We recommend installing SC2X6 screws only at high traction conditions. B106RS B106RS SH0.1 AT13 SC2X6 Note: Rear universal joints may be a bit tight at this stage. They will settle into their true position once the wheels are fully tightened.
Page 22
STEP 33 SC2X15 snap SC2X15 Servo link: P01X AT14 P13X P13X Build two for front Rear toe link: Build two for rear P13X AT25 P13X Build two! AT25-44 AT25-44 P13X P13X P13X P13X Front left steering link Front right steering link P13X P13X Front right...
Page 23
STEP 34 Unscrew SB25X8 screws on ~3 turns and shift P04 up to create ~1.5mm gap between P04 and the lower arm. Insert P03 ball into the spherical cavity of the lower arm and tighten SB25X8 SB25X8 screws. Insert the driveshaft inner joint into the outdrive of diff/spool. ⚠...
Page 24
STEP 36 SB3X12 SB3X12 SH0.5...SH1.0 P23-R SH0.5...SH1.75 P23-R SF3X8 x2 Note: Use an appropriate combination of SH spacers under P25 clamps SF3X8 x2 to allow ~0,3 mm vertical free play of the battery. STEP 37 SH1.75 SH1.75 SH1.0 SH0.5 SB3X8 SH1.75 SH1.75 Note: Use an appropriate combination of SH spacers...
Page 25
STEP 39 OR06 OR06 SPR05 SPR05 SB3X6 x2 AT12 SB3X8 x2 P14-2 P14-2 P14-5-R P15L P14-1-R SF3X8 SB3X10 SB3X10 STEP 40 SB3X8 x2 SH0.5...SH1.75 Note: SH0.5...SH1.75 spacers under P64 holder can be installed to adjust the bodyshell rake angle. STEP 41 snap AT55M OR06...
Page 26
19T - 55T 64dp, 14T - 41T 48dp STEP 42 pinion gears can be installed Note: This orientation of the hex driver should be used to tighten the pinion gear set screw. SS3X3 Pinion Gear (not included) Motor (not included) SH0.5 x2 SB3X8 x2 Install: speed controller (not included),...
Page 27
1mm wheelbase change. (H1-H2)*1.5 for front (H1-H2)*1.7 for rear TIP / Recommended items: MAX-02-001 - MXLR Awesomatix Caster Tool Body shell front end downtravel adjustment: Rear suspension toe-in adjustment: Use SC2X15 screws to adjust bodyshell down Rear rod 0.5mm elongation reduces the toe-in by 1.0°...
Page 28
Spring preload and the ride height of the car is adjusted by the RHS (Ride Height Screw). In A800RR kit ST69-00-R screw is provided as RHS screw. Turn IN (CW) RHS screw to increase spring preload. Turn OUT (CCW) RHS screw to decrease spring preload.
Page 29
Optional parts and sets C07-R carbon bumper plate C07-R B73SS SB3X5 Front belt anti-skipping ball bearing BW27 27 g stiffener BW27 SB3X8 SB25X8 SB25X8 BW10 SB3X8 SB25X8 x2 SF3X5 BW7 7 g , BW8 8 g weights BW10 10 g weight C26 top stiffener AT139 fan holder SH1.75 x3...
Page 30
Optional parts and sets BW22R and AT144 BW52R and AT144 SB3X8 holes for SB3X6 93mm batteries AT144 AT144 SB3X6 SB3X8 SH0.5 ... SH0.5...SH1.75 BW52R AT144 AT144 SH1.75 SH0.5...SH1.75 SH0.5...SH1.75 BW52R BW52R BW22R SF3X6 x2 SF3X6 x2 BW22R SF3X6 x2 SF3X6 x2 AT143 anti-roll bar stiffener AT143 stiffener increases stiffness of the anti-roll bar up to one step.
Page 31
Optional parts and sets C07-RF Carbon Bumper Plate FSS Forward Shifted Servoholder set SC2X4 C07-RF carbon bumper plate increases the flex of the car’s front end. AM180R-F Two ST019 screws must be used! ST231 FSS moves the servo forward and C07-R AM24R-F allows the ESC to be mounted in front...
Page 32
FINAL DRIVE RATIO CHART DRIVE TRAIN RATIO IS 1,9 64dp SPUR GEAR SIZE 48dp SPUR GEAR...
SETUP SHEET A800RR ° DATE NAME TEMP. C AIR / TRACK TRACK SURFACE CARPET COUNTRY ASPHALT TRACK LAYOUT TECHNICAL MIXED FAST RACE TRACTION MEDIUM HIGH TRACK FRONT REAR AT13W AT13W AT15 AT15 AM19-R AM19-R SC2X6 SC2X6 AM06WL AM06WL GF/MM 111.6 GF/MM 137.8...
SF3X8 M3x8 Flat Head Screw SH0.25 6x3x0.25mm Spacer Arm Clip 351mm Bando Belt Damper SH5.9X0.4 5.9x0.4mm Spacer BEL351 P12X Sway Bar Holder Gauge Set A800RR Progressive Spring DG1XM SPR-P1 P13X Ball End STS-A800RR Stickers Sheet Progressive Spring SPR-P2 P14-1-R Bumper 5.5/4 mm Wrench...
Page 36
