  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support RETRACTABLE RV AWNING MODEL: B1 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS WARNING: Read and understand this entire manual before operating or servicing this product. Failure to follow these warnings and instructions can cause personal injury or damage to valuable property. It is best to complete the process of assembling the awning with an ...

  • Page 4: Technical Parameter

    Thank you very much for choosing this RV Awning. Please read all the instructions before using it. The information will help you achieve the best possible results. TECHNICAL PARAMETER Product name Retractable RV Awning Model Material Aluminium Fabric Color White&Black Suitable vehicle PACKAGE LIST Name...
  • Page 5 Fabric ploy-cord loop belt Support rod component Aluminum plate Pull wand Ground nail Platen Center Cradle base Center Cradle support Door Support Screw A - 4 -...
  • Page 6 Please keep the user manual properly for future reference. B1 Manual Roll Out RV Awning Full Diagram Figure C1 The B1 awning is installed on the side of the vehicle and fixed with upper and lower mounting brackets (Figure C2). The precautions and installation methods are as follows:...

  • Page 7: Installation Method

    1. The awning must be installed by 2 or more people. 2. Before installation, please check whether there are reinforcing ribs at the position of the vehicle body used to fix the installation bracket, and whether there are obstacles such as water, electricity, and other lines at the drilling position (Figure C3).
  • Page 8 3.2 Take the support arm, use it mark the hole position at a suitable position on the outside of the vehicle (Figure C6), and drill a Φ5 installation hole on the vehicle body (Figure C7). Figure C6 Figure C7 3.3 Take the bottom brackets from the arms, put them to the bottom install position with aluminium plates, fix them with Screw C and Screw D(Figure C8), Next assembly the arm to the bracket, fix the upper brackets with Screw C and Screw D too.
  • Page 9 Figure C10 Figure C11 3.5 Open the fabric, insert the fabric into the slot of the roll tube, then insert the front end of the fabric into another slot on the roll tube, and then fix the Screw B to prevent the fabric from moving, next insert the fabric strip into the slot.Last insert the loop belt to the strip.
  • Page 10 Figure C15 Figure C16 3.7 Remove the safety pins on both sides of the end caps of the roller (Figure C17) to tighten the fabric roll under stress. Figure C17 ※ Attention: There is a winding spring inside the scroll, which have been preset with an upward force.
  • Page 11 Figure C18 3.9 Door support install Find the correct position fro the door support, the door support need to higher 0.4inch than the door, then fix the door support with Screw B (Figure C19, Figure C20) 0.4inch higher than the door Figure C19 Figure C20 3.10 Center cradle install...
  • Page 12 Figure C21 Figure C22 3.11 Install the Storage clip for Pull handle rod Choose the suitable position for the storage clip, and fix it with Screw B (Figure C23) Figure C2 SCAN THEOR CODE TO VIEW THE INSTALLATION VIDEO - 11 -...

  • Page 13: Usage Method

    4. Usage method: After the above installation of the awning is completed, check the appearance and ensure that the screws in the above parts are securely fastened. 4.1Open the awning 4.1.1 Open the safety lock located in the middle of the support rods on both sides (press and pull, Figure D1), and loosen the tension rod screw (Figure D2).
  • Page 14 Figure D4 4.1.4 Push out the inner rod along the support rod, slide it and clip it into the buckle located at the head of the support arm (Figure D5), then tighten the black lock knob to fix the inner rod. Figure D5 4.1.5 There are two types of support for awning, namely body support and ground support:...
  • Page 15 a. Lift the arm latch and press down the lock head then slide out of the support arm to the appropriate height (Figure D7), and release the lock head to lock the support arm. Figure D7 ※ Attention: When the inner rod of the support arm slides to the red warning position, it reaches the maximum support height.
  • Page 16 the ground. (Figure D10) Figure D10 b. Loosen the black lock knob to extend the awning to the max, then tighten it. c. Press down arm latch and adjust the support rod to appropriate height. The awning has been opened. (Figure D11). And you can inset the ground nail to the bottom brackets, to make the awning more stable.
  • Page 17 4.2Closing Awning Ground support Closing: (sequential operation starting from 4.2.1), vehicle support closing (sequential operation starting from 4.2.2): 4.2.1 Recovery of Ground Support Status First, rotate the support rod inward and swing it back, then clamp the fixed shaft on the foot of the support arm into the slot of the lower installation bracket, and switch it to the vehicle support state.
  • Page 18 Figure D15 4.2.5 Hold the loop belt and gently push the ratchet lever on the end cover of the roller in the direction of the arrow with your hand, switching the direction of the pawl to "off". (Figure D16) Figure D16 4.2.6 Slowly release the recycling reel until it is fully retracted.
  • Page 19 4.2.7 Press down on the travel lock in the middle of the support arm and tighten the screw of the inner rod. The awning has been closed. (Figure D18) Figure D18 4.2.8 We recommend that the awning be used only for the purpose of sun protection.

  • Page 20: Troubleshooting

    TROUBLE SHOOTING Every awning undergoes are strictly debugged and tested before leaving the factory to achieve the best condition. However, after a period of use, there may be some abnormalities. Please handle them according to the following situations. 1. Weak winding of the awning scroll: Check if the torsion spring of the scroll is releasing force.
  • Page 21 4. Difficulty in pressing the lock head: Add an appropriate amount of lubricating oil to the lock head and tongue area Figure E3 - 20 -...

  • Page 22: Product Structure Diagram

    PRODUCT STRUCTURE DIAGRAM some products may have adjustments and will not be listed (Figure - 21 -...
  • Page 23 Figure G1 B1 Manual Roll Out RV Awning Awning Awning color Size (mm) (mm) (mm) (mm) (mm) (support) 14’ 4303 4013 2348 4373 1700 Black 15’ 4608 4318 2348 4678 1700 Black 16’ 4913 4623 2348 4983 1700 Black 17’...
