RH850 Evaluation Platform
RH850/F1x-176pin
32
Y-RH850-F1X-176PIN-PB-T1-V4
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
The newest version of this document can be obtained from the following web location
http://www.renesas.eu/updates?oc=Y-RH850-F1X-176PIN-PB-T1-V4
www.renesas.com
User's Manual: Piggyback Board V4
Rev. 1.20
August 12, 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RH850 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Renesas RH850

Summary of Contents for Renesas RH850

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ..........................5 ............................6 ACKAGE OMPONENTS CHAPTER 2 OVERVIEW ............................7 ................................7 VERVIEW ............................. 7 OUNTING OF THE DEVICE CHAPTER 3 JUMPER CONFIGURATION ......................9 CHAPTER 4 POWER SUPPLY ..........................11 ..........................11 OARD POWER CONNECTION ............................

  • Page 5: Chapter 1 Introduction

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 1 Introduction The RH850/F1x Application Board is part of the RH850 Evaluation Platform and serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/F1x microcontrollers. The piggyback board (Y-RH850-F1X-176PIN-PB-T1-V4) can be used as a standalone board, or can be mated with a mainboard (e.g.

  • Page 6: Package Components

    Always use the original packing box when transporting the Y- RH850-F1X-176PIN-PB-T1-V4. If packing of your product is not complete, it may be damaged during transportation. R20UT4148ED0120 Rev. 1.20...

  • Page 7: Chapter 2 Overview

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 2 Overview 2.1 Overview Figures 1 and 2 provide the views of the piggyback board. Device pin #1 Figure 1 – Piggyback board top view Figure 2 – Piggyback board bottom view 2.2 Mounting of the device...
  • Page 8 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 • RH850/F1L • RH850/F1M • RH850/F1H • RH850/F1K • RH850/F1KM-S2 • RH850/F1KM-S4 • RH850/F1KH-D8 The device must be placed inside the socket IC1. To insert the device, press down the lid, align the #1 pin of the device to the #1pin of the socket, insert the device inside the socket and release the lid.

  • Page 9: Chapter 3 Jumper Configuration

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 3 Jumper Configuration The function of the board can be configured via jumpers. This chapter describes the standard configuration, i.e. jumper setting for the intended devices. For the supported function of the used device, please refer to the corresponding HW user’s manual.
  • Page 10 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 JP33 2-3 Either P10_0 or P0_1 The jumper setting also are shown in this picture: Figure 3 – Jumper setting overview • green jumper JP25 for FLMDO0 always must be closed for a ‘normal’ (user mode and debug) operation of the device.

  • Page 11: Chapter 4 Power Supply

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 4 Power supply 4.1 Board power connection For operation of the device, a supply voltage must be connected to the board. Though a single supply voltage is sufficient for the operation of the device, two (different) voltages can be supplied to the board.

  • Page 12: Voltage Distribution

    Voltage1 (typ. 5.0V) or Voltage2 (typ. 3.3V) by the jumpers JP12-JP16, JP18, JP29, respectively the jumpers JP11 and JP20. Error! Not a valid link. Note: • The RH850/F1KH-D8 device requires a supply voltage of 3.3V on its REG1VCC pin. •...

  • Page 13: Chapter 5 Clock Sources

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 5 Clock sources Four external crystal oscillators for the device clock supply are provided with the board. 5.1 MainOsc A crystal or ceramic resonator can be mounted on socket X1. The applicable frequency range can be found is the devices electrical specification.

  • Page 14: Chapter 6 Debug And Programming Interface

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 6 Debug and Programming interface For connection of the microcontroller debug and flash programming tools, the connector CN19 is provided. The signal connection of the connector CN19 is shown in the picture below: CN19 pin...

  • Page 15: Chapter 7 Connectors For Ports Of Device

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 7 Connectors for ports of device Connection to each pin of the device is possible via the connectors CN5 to CN8. Note: The pin headers are directly connected to the pins of the device, therefore special care must be taken to avoid any electrostatic or other damage to the device.

  • Page 16: Chapter 8 Connectors To Mainboard

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 8 Connectors to Mainboard Three connectors (CN1 to CN3) are available to connect the piggyback board to a mainboard. The function and port assignment of each connector pin is described in this chapter. Note: Not each function may be available on the assigned device port for each of the supported devices of this piggyback board.
  • Page 17 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Function Device Port Function Device Port FLX1RX P10_9 FX1CLK P10_10 P12_4 P12_5 ETH0MDIO ETH0MDC P10_1 P18_1 ETH0RXD0 EH0TXD0 P10_2 P18_2 ETH0RXD1 EH0TXD1 P10_4 P18_3 ETH0RXD2 EH0TXD2 P10_5 P18_4 ETH0RXD3 EH0TXD3 ETH0RXDCLK P10_0 P18_7 ETH0TXCLK P11_14 or...

  • Page 18: Connector Cn2

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 8.2 Connector CN2 Function Device Port Function Device Port CAN2Tx P0_4 CAN3Tx P1_3 CAN2Rx P0_5 CAN3Rx P1_2 CAN4Tx P1_13 CAN5Tx P0_14 CAN4Rx P1_12 CAN5Rx P0_13 LIN2Tx P0_10 LIN3Tx P1_15 LIN2Rx P0_9 LIN3Rx P1_14 LIN4Tx P1_11...
  • Page 19 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Function Device Port Function Device Port R20UT4148ED0120 Rev. 1.20 August 12, 2021...

  • Page 20: Connector Cn3

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 8.3 Connector CN3 Function Device Port Function Device Port PWM00 P10_0 PWM01 P10_1 PWM02 P10_2 PWM03 P10_3 PWM04 P10_7 PWM05 P10_8 PWM06 P10_9 PWM07 P10_10 PWM08 P9_0 PWM09 P9_1 PWM10 P0_4 PWM11 P0_1 PWM12 P0_2...
  • Page 21 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Function Device Port Function Device Port PWMADC02 AP0_10 PWMADC03 AP0_11 PWMADC04 AP0_12 PWMADC05 AP0_13 PWMADC06 AP0_14 PWMADC07 AP0_15 PWMADC08 AP1_0 PWMADC09 AP1_1 PWMADC10 AP1_2 PWMADC11 AP1_3 PWMADC12 AP1_4 PWMADC13 AP1_5 PWMADC14 AP1_6 PWMADC15 AP1_7 R20UT4148ED0120 Rev. 1.20...

  • Page 22: Chapter 9 Other Circuitry

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 9 Other circuitry 9.1 Push button for RESET In order to issue a RESET to the device, the push-button SW1 is available. 9.2 Mode Selection The piggyback board gives the possibility to configure the following mode pins •...

  • Page 23: Signalling Leds

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 9.3 Signalling LEDs Eight LEDs are provided to allow visual observation of the output state of device port pins. Device pins P8_0 to P8_7 are connected to the even pins 2 to 16 of the pin header CN24, while the LEDs 1 to 8 are connected to the odd pins 1 to 15, respectively.

  • Page 24: Chapter 10 Differences To The -T1-V3 Board

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 10 Differences to the -T1-V3 board This table shows the differences on CN1 between the -T1-V3 and the -T1-V4 board version: -T1-V3 -T1-V4 Function Port Function Port UART0TX P10_10 UART0TX P10_10 or P0_2 UART0RX...
  • Page 25 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 This table shows the differences on the jumper usage between the -T1-V3 and the -T1-V4 board version: -T1-V3 -T1-V4 Description Function Port Selection of Pin 114: P9_6, VSS or REGVCC No change between V3 and V4...

  • Page 26: Chapter 11 Mechanical Dimensions

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 11 Mechanical dimensions R20UT4148ED0120 Rev. 1.20 August 12, 2021...

  • Page 27: Chapter 12 Schematic

    RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 Chapter 12 Schematic R20UT4148ED0120 Rev. 1.20 August 12, 2021...
  • Page 28 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 PUSH BUTTON 4 PIN SMD R20UT4148ED0120 Rev. 1.20 August 12, 2021...
  • Page 29 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 R20UT4148ED0120 Rev. 1.20 August 12, 2021...
  • Page 30 RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4 R20UT4148ED0120 Rev. 1.20 August 12, 2021...

  • Page 31: Chapter 13 Revision History

    • Corrected jumper naming in chapter 4.2 ‘Voltage distribution’ • Updated jumper settings in chapter 3 ‘Jumper Configuration’ 2017-11-08 1.10 • Added Note in chapter 8 • Added chapter 10 • Added RH850/F1KM-S2 to the list of supported devices 2021-08-12 1.20 R20UT4148ED0120 Rev. 1.20 August 12, 2021...
  • Page 32 RH850/F1x, R1x 176pin Piggyback Board T1-V4 User’s Manual: Piggyback Board T1-V4 Publication Date: Rev.1.20 August 12, 2021 Published by: Renesas Electronics Corporation...
  • Page 34 RH850/F1x, R1x 176PIN R20UT4148ED0120...
