SPECIFICATION
- Wingspan: 2150mm (84.6in)
- Length: 1852mm (72.9 in)
- Flying weight: 11600 - 12600 gr
- Wing area: 80 dm2
- Wing loading: 145 g/dm2
- Gear type: Electric Retract Gear With CNC
Suspension Metal Struts, Electric Controller Box
(included)
- Plastic Bomb not included (purchasing
separately)
- Spinner size: 95mm (Included)
- Radio: 8 channel minimum (Not Included)
- Servo: 8 standard hi-torque servo: 2 aileron;
2 flap; 2 elevator;
1 rudder; 1 throttle (Not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: 50- 60 CC gas engine (two stroke)
(Not Included)
- Motor: brushless outrunner 2600-3000 W,
190 KV (Not Included)
- Gravity CG: 175 mm (6.9 in) Back from the
leading edge of the wing, at the fuselage
FOCKE-WULF Fw 190A
2.15m 84.6" W/Electric Retract 50-60cc ARF CARBON
- Control throw Ailerons: Low: 12mm up/down;
High: 15mm up/down
- Control throw Elevators: Low: 12mm up/down;
High: 15mm up/down
- Control throw Rudder: Low: 25mm right/left;
High: 35mm right/left
- Control throw Flaps: Mid: 20mm down;
Landing: 30mm down
- Experience level: Intermediate
- Plane type: Scale Military
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: Rimfire 50cc (not included)
- Propeller: 22x8 to 26x10 (not included)
- Lipo cell: 12 cells / 5000 – 6000mAh (not included)
- Esc: 120A (not included)
UNDER SAFETY PRECAUTIONS
This radio control model is not a toy!
It is highly recommended that first-time builders seek advice of
experienced modelers before beginning assembly.
Assemble this kit only in places out of children's reach!
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
GP
EP
version
version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOCKE-WULF Fw 190A and is the answer not in the manual?

Questions and answers

Summary of Contents for Phoenix Model FOCKE-WULF Fw 190A

  • Page 1 FOCKE-WULF Fw 190A version version 2.15m 84.6” W/Electric Retract 50-60cc ARF CARBON - Control throw Ailerons: Low: 12mm up/down; SPECIFICATION High: 15mm up/down - Wingspan: 2150mm (84.6in) - Control throw Elevators: Low: 12mm up/down; - Length: 1852mm (72.9 in) High: 15mm up/down - Flying weight: 11600 - 12600 gr - Control throw Rudder: Low: 25mm right/left;...
  • Page 2: Table Of Contents

    Thank you for purchasing Phoenix Model products. With over 20 years experience in production and fly testing, Phoenix Model is committed to bring the best quality products and good service to customers. Along with a team of creative engineers and skilled workers, we will always accompany with customers by our great experiences, fully enthusiasm...
  • Page 3: Warranty

    Vacuum the parts and the work area to assemble and use this. thoroughly after working with fiberglass parts. In that Phoenix Model has no control over the final assembly or material used for final assembly, Phoenix SUGGESTION Model is not responsible for loss of use , or other incidental or consequential damages.
  • Page 4: Flight Warnings

    FOCK-WULF Instruction Manual FLIGHT WARNINGS ADHESIVES AND REQUIRED TOOLS When ready to fly, first extend the transmitter aerial. Thin CA Switch on the transmitter. 30-minute epoxy Switch on the receiver. 6-minute epoxy Check that the wings are correctly fitted to the Threadlocker thread locking cement fuselage.
  • Page 5 FOCK-WULF Instruction Manual • Officially designated AMA Air Show Teams (AST) are authorized to use devices and practices as defined within the Team AMA Program Document. (AMA Document #718.) (j) Not operate a turbine-powered aircraft, unless in compliance with the AMA turbine regulations. (AMA Document #510-A.) 3.
  • Page 6: Important Notes

    FOCK-WULF Instruction Manual IMPORTANT NOTES Apply epoxy glue or CA glue Fiberglass plate Apply epoxy glue or CA glue PREPARATIONS Use a covering iron with a covering sock on high heat to tighten the covering if necessary. Apply pressure over sheeted areas to thoroughly bond the covering to the wood.
  • Page 7 FOCK-WULF Instruction Manual < Left Wing > < Right Wing > Cut off shaded portion Assemble left and right Apply instant glue sides the same way (CA glue, super glue).
  • Page 8: Installing The Ailerons And Flaps

    FOCK-WULF Instruction Manual INSTALLING THE AILERONS and flaps Flap 3x10mm Flap Horn Flap Flap 3x12mm Flap Please note that Epoxy glue must be apply to these holes before screw < Bottom view > the control horn to the aileron. If not, it comes off during flights, you may lose control of your airplane, resulting in an accident !
  • Page 9: Installing The Ailerons And Flaps Servos

    FOCK-WULF Instruction Manual Main Wing < Bottom view > Assemble left and right sides the same way Apply epoxy glue. Flap Aileron Cut off shaded portion Ensure smooth, non-binding movement when assembing INSTALLING THE AILERONs AND FLAPs SERVOS Cut off shaded portion Must be purchased separately! Assemble left and right...
  • Page 10: Installing The Ailerons And Flaps Linkages

    FOCK-WULF Instruction Manual Flap Servo Warning! Set all scerws securely. Must be purchased If they come off during separately! flight you will lose Assemble left and right Supplied with the servo control of your aircraft! sides the same way INSTALLING THE AILERONs AND FLAPs LINKAGES Control horn <Aileron>...
  • Page 11 FOCK-WULF Instruction Manual 3x15mm Aileron 1.5mm 3x10mm < Top view > Flap 3x15mm Horn 3x10mm Flap Flap Drill holes with the 1.5mm specified diameter. Must be purchased separately! Cut off shaded portion...
  • Page 12 FOCK-WULF Instruction Manual 2 x 10mm TP Screw Aluminum ball 3x12mm 2x10mm 2x10mm < Bottom view > 3mm Nylon nut Must be purchased separately!
  • Page 13: Installing The Main Gun And Plastic Cover

    FOCK-WULF Instruction Manual INSTALLING THE GUN And plastic cover Plastic cover Plastic cover 60mm < Main wing > Apply instant glue (CA glue, super glue). Cut off shaded portion Assemble left and right sides the same way...
  • Page 14: Installing The Main Landing Gear

    FOCK-WULF Instruction Manual INSTALLING THE MAIN LANDING GEAR 3 x 8mm Button Screw < Main Gear > 6 x 60mm Cap Screw 4x4mm Set Screw 6mm Washer < Main Gear (R) > 4x4mm 3x8mm 3x8mm 3x8mm Apply threadlocker (screw cement). Assemble left and right Apply instant glue sides the same way...
  • Page 15 FOCK-WULF Instruction Manual 4 x 30mm Cap Screw 2 x 10mm TP Screw 4mm Washer 4mm Spring Washer 10mm < Bottom view > < Right Wing > < Left Wing > Assemble left and right sides the same way...
  • Page 16: Electric Retract System

    FOCK-WULF Instruction Manual ELECTRIC RETRACT SYSTEM Main Wheel Handle Power led POWER 7.4v Front / Back Wheel Controller Box R5206 Receiver Main Wheel Shrink Plastic 2 Times Battery 7.4 Volt Controller Box HORIZONTAL STABILIZER INSTALLATION Apply epoxy glue Ensure smooth, non-binding movement when assembling...
  • Page 17: Rudder Installation

    FOCK-WULF Instruction Manual Make certain plane is aligned accurately per the diagram. Amis-aligned plane can fly erraticaliy and cause accidents. Apply epoxy glue Cut off shaded portion rudder INSTALLATION Please note that Epoxy glue must be apply to these holes before screw the control horn to the rudder.
  • Page 18: Installing The Rudder Pushrod And Rudder Servo

    FOCK-WULF Instruction Manual INSTALLING THE RUDDER PUSHROD and rudder servo 3 x 15mm Screw Aluminum ball 3mm Washer 3 x 10mm Button Screw Aluminum ball 3mm Nylon Nut Aluminum ball Aluminum ball 3 x 890mm Push rod Aluminum ball 3 x 12mm Button Screw 1.5mm Rudder Rudder...
  • Page 19 FOCK-WULF Instruction Manual 3x10mm 3x12mm Rudder servo Rudder Rod Must be purchased separately! Pay close attention Cut off shaded portion...
  • Page 20: Installing The Tail Gear And Tail Gear Servo

    FOCK-WULF Instruction Manual INSTALLing The tail gear and tail tail gear servo Aluminum ball 3mm Nylon Nut 3 x 30mm Connector 3x12mm Screw 3mm Washer Locknut 1300mm Cable rod Linkage Wire 4x4mm Close or clamp pipe to fix position.
  • Page 21 FOCK-WULF Instruction Manual Hatch Cut off excess.
  • Page 22 FOCK-WULF Instruction Manual 3x12mm 3x12mm Set all screws securely. If they come off during flight you will lose control of your aircraft! Rudder servo Tail Wheel Rudder Linkages Must be purchased separately! Pay close attention here...
  • Page 23: Installing The Elevator Pushrod

    FOCK-WULF Instruction Manual INSTALLING THE ELEVATOR PUSHROD Aluminum ball Control Horn Aluminum ball 3 x 25mm Cap Screw 3mm Washer Aluminum ball Aluminum ball Nylon Nut 3 x 970mm Push rod 3 x 15mm Screw 3x10mm Screw Elevator rod 3x15mm Elevator 1.5mm 3x10mm...
  • Page 24: Installing The Elevator Servo

    FOCK-WULF Instruction Manual INSTALLING THE ELEVATOR SERVO 3x12mm Elevator Elevator Servo Elevator Servo Must be purchased separately! Pay close attention here...
  • Page 25: Secure The Wing To The Fuselage

    FOCK-WULF Instruction Manual SECURE The Wing To The Fuselage 6mm Plastic Screw Assemble left and right sides the same way. INSTALLING THE PLASTIC SIDE LOUVERS Before After Cut off shaded portion...
  • Page 26: Installing The Plastic Bomb (Not Included)

    FOCK-WULF Instruction Manual Assemble left and right sides the same way. INSTALLING THE PLASTIC BOMB ( NOT INCLUDED WITH THE KIT, NEED TO PURCHASE SEPARATELY ) 5mm Washer Button Screw 6 x 60mm Cap Screw Bomb Rack Iron Support Hinge Bomb Apply threadlocker Must be purchased separately!
  • Page 27 FOCK-WULF Instruction Manual Apply epoxy glue. Must be purchased separately! Assemble left and right sides the same way Cut off shaded portion...
  • Page 28: Installing The Engine And Throtle

    FOCK-WULF Instruction Manual INSTALLING THE ENGINE and throttle May be you also need to trim some wood from the tri-angle wood for the installation is easy. Using plate of plywood (supplied with the kit) mark the holes onto the fire wall for installing the engine mount for DLE-61CC or DLE-55CC.
  • Page 29 FOCK-WULF Instruction Manual Metal Kwik link (M2) Silicone Silicone 1.7x300mm Push rod Silicone DLE 61 CC DLE 61 CC DLE 61 CC Throttle Lever Silicone Silicone Choke Lever DLE 61 CC Must be purchased separately!
  • Page 30: Installing The Fuel Tank

    Instruction Manual FOCK-WULF INSTALLING THE Fuel Tank Fuel Tank 700cc Plastic Zip tie Rubber washer Brass pipes Full CNC machining Clunks Tygon Fuel Tubing Rubber washer Rubber washer Fuel tank Aluminum bolt Tygon Fuel Tubing Aluminum bolt Rubber washer Must be purchased separately!
  • Page 31 FOCK-WULF Instruction Manual Rubber washer Rubber washer Rubber washer Fuel tank Aluminum bolt < Front View > Fuel Tank Tygon Fuel Tubing Zip tie Clunks Zip tie Pay close attention here Tygon Fuel Tubing Must be purchased separately!
  • Page 32: Installing The Throttle Servo

    FOCK-WULF Instruction Manual Fuel Tank Velcro Velcro Must be purchased separately! INSTALLING THE THROTTLE servo 1. Plug the throttle servo into the receiver and turn on Connector the radio system. Check to ensure that the throttle servo output shaft is moving in the correct direction.
  • Page 33: Mounting The Cowl

    FOCK-WULF Instruction Manual Connector 3 x 10mm 4x4mm Must be purchased separately! Throttle Servo Ensure smooth, non-binding Cut off shaded portion movement when assembing Apply threadlocker Apply epoxy glue. (screw cement). Throttle rod MOUNTING THE COWL 4. While holding the cowl firmly in position, drill four 1,6mm pilot holes through both the cowl 1.
  • Page 34 FOCK-WULF Instruction Manual 4 x 20mm TP Screw 4mm Washer Washer Plate of plywood Trim the cowling so it will Apply epoxy glue match your engine Pay close attention here Cut off shaded portion...
  • Page 35: Installing The Spinner

    FOCK-WULF Instruction Manual 4x20mm Drill holes with the specified diameter. 4x20mm INSTALLING THE SPINNER Install the spinner back-plate, propeller and spinner cone. The propeller should not touch any part of the spinner cone. If it dose, use a sharp modeling knife and carefully trim away the spinner cone where the propeller comes in contact with it.
  • Page 36: Installing The Receiver And Battery

    FOCK-WULF Instruction Manual 3 x 8mm Button Screw Propeller Spinner 3x8mm 3x8mm Spinner Pay close attention here Must be purchased separately! INSTALLING THE RECEIVER AND BATTERY INSTALLING THE SWITCH 1. Plug the servo leads and the switch lead into the 1.
  • Page 37: Installing The Electric Motor ( Ep Version )

    FOCK-WULF Instruction Manual Receiver Tape Foam Pad Switch Must be purchased separately! INSTALLING THE ELECTRIC MOTOR ( EP VERSION ) 5mm Washer 5 x 60mm Cap Screw 5mm Spring Washer 5mm Mount Nut 5mm Washer 12 x 35mm Aluminum RIMFIRE 50CC 12x35mm 5x60mm White glue...
  • Page 38 FOCK-WULF Instruction Manual 5mm Mount Nut RIMFIRE 50CC 12x35mm 5x60mm Velcro Battery < Check the motor rotation > Must be purchased Apply threadlocker separately! (screw cement).
  • Page 39: Installing The Gun Cover And Canobi

    FOCK-WULF Instruction Manual INSTALLING THE GUN COVER and canopy Align Center When rotating clock wise, change the connection of 2 wires. Must be purchased separately! Cut off shaded portion Apply instant glue (CA glue, super glue).
  • Page 40: Balancing

    FOCK-WULF Instruction Manual BALANCING 2. If the nose of the plane falls, the plane is nose heavy. To correct this first move the battery pack 1. It is critical that your airplane be balanced correctly. further back in the fuselage. If this is not possible Improper balance will cause your plane to lose or does not correct it, stick small amounts of lead control and crash.
  • Page 41: Lateral Balance

    FOCK-WULF Instruction Manual In order to obtain the CG specified, reposition the receiver and other equipment. Do not fly before confirming the If not obtain the CG specified, add a weight and correct location of the CG. If the adjust. CG is incorrect, you lose control of your airplane which leads to accidents.
  • Page 42: Flight Preparation Pre Flight Check

    FOCK-WULF Instruction Manual FLIGHT PREPARATION PRE FLIGHT CHECK 1. Completely charge your transmitter and receiver batteries before your first day of flying. 2. Check every bolt and every glue joint in your plane to ensure that everything is tight and well bonded.
  • Page 43: Main Gear Dimensional Detail

    FOCK-WULF Instruction Manual Main Gear Dimensional Detail tail Gear Dimensional Detail 47mm...
  • Page 44: Exploded View

    3x10mm 3x10mm 3x15mm(TP) 4x4mm 2x10mm 3x10mm(TP)
  • Page 45: Exploded View

    12x35mm 5mm Mount Nut 12x35mm 5x60mm 5x60mm Mount Nut 2x10mm(TP) 4x25mm 3x8mm 6x45mm 100mm 4x25mm 2x10mm(TP) 3x8mm 6x45 mm 100mm...
  • Page 46: Exploded View

    3x10mm 3x15mm 3x15mm 3x15mm 3x12mm 3x10mm 3x10mm 3x12mm 3x15mm 3x12mm 3x10mm 3x12mm 3x15mm 2x10mm(TP) 3x10mm 2x10mm(TP) 3x12mm 4x20mm 4x4mm 4.5mm 47mm 3x12mm 3x15mm 3x10mm 3x15mm 3x12mm 3x10mm 3x12mm 2x10mm(TP) 2x10mm(TP)
  • Page 47 I/C FLIGHT WARNINGS Always operate in open areas, away Keep all onlookers (especially small from factories, hospitals, schools, THE PROPELLER IS DANGEROUS children and animals) well back from buildings and houses etc. NEVER fly Keep fingers, clothing (ties, shirt the area of operation. This is a flying your aircraft close to people or built sleeves, scarves) or any other loose aircraft, which will cause serious...
  • Page 48 I/C FLIGHT GUIDELINES Operate the control sticks on the When ready to fly, first extend the transmitter and check that the control transmitter aerial. surfaces move freely and in the ALWAYS land the model INTO the CORRECT directions. wind, this ensures that the model lands at the slowest possible speed.
