Discovery Benches and Racks
DBR412 Olympic Spotter Bench | Assembly and Use Guide
Assembly Requirements
Precor recommends at least two (2) people for this installation. DO NOT
attempt assembly by yourself.
When assembling the equipment, we recommend you:
Follow the assembly instructions in order.
Unpack the box and assemble the equipment close to where you plan to use it.
Locate the equipment at least 40 inches (1 meter) away from walls or furniture on
either side of the equipment, and 40 inches (1 meter) away from objects behind or
in front of the equipment.
Assemble the equipment on a solid, flat surface so it remains level and stable.
DO NOT move equipment without assistance.
Required Tools
Metric hex wrench set
Metric hex bit set
Torque wrench 75 ft-lb (100 N-m)
Open-end wrench set (metric)
Required to remove foot caps:
5 mm hex key (or long 5 mm hex bit), 13 mm open-end wrench
Hardware Kit
Name
Qty
1
1
Foot frame
2
2
2
Upright frame
2
3
3
Lower cross frame
1
4
4
Rear support frame
2
5
5
Bench frame
1
6 6
Bench pad
1
7 7
Weight storage horn
4
8 8
Bumper
8
Assembly Instructions
1. Foot frames to upright frames
1.
Set the two
foot frames on the ground approximately 43 inches (110 cm) apart.
1 1
2.
There are numbers on 2 sides of each upright frame. Have your assistant set
and hold an
2 2
upright frame towards the front of a foot frame. Ensure that the
numbers face the inside and outside of the frame (Figure 2). Align the holes and
secure with 2
11
11
M12 x 35 mm SHCS and 2
2). Repeat for the other foot frame and upright frame (ensure numbers on both
uprights face each other). Hand-tighten only.
1 1
©2024 Precor Incorporated | Discovery Benches and Racks
Name
9 9
M12 x 100 mm socket head cap screw (SHCS)
10
10
M12 x 50 mm
socket head cap screw (SHCS)
11
11
M12 x 35 mm socket head cap screw (SHCS)
12
12
M10 x 35 hex head cap screw (HHS)
13
13
Flat washer, 13 mm ID x 26 mm OD
14
14
Flat washer, 13 mm ID x 30 mm OD (horns)
15
15
Flat washer, 11 mm
16
16
M12 nut
13
13
13 mm x 26 mm flat washers (Figure
2 2
11
11
13
13
Figure 2.
Upright frame
J-hook
Safety arm
Qty
Bench pad
4
4
14
6
20
Bench frame
4
6
4
2. Lower cross frame to upright frames
1.
Set the
3 3
lower cross frame between the 2
frame and the Precor badge should face towards the front (Figure 3).
2.
Move the foot frames if necessary to align the holes of the lower cross frame with
the upright frames. Secure each side with 2
26 mm flat washers, and 2
3. Rear support frames to upright and foot frames
1.
Have your assistant hold a
back of an
upright frame and on the rear of the
2
2
M12 x 35 mm SHCS and 4
only. Repeat for other rear support frame.
Square unit and torque all M12 fasteners to 65 ft-lb (88 N-m).
2.
13
13
11
11
11
11
13
13
DBR412 Olympic Spotter Bench | Assembly Guide | P/N CWB288801-101B | 2024 12 13 | Page 1 of 2
Rear support frame
Weight storage horn
Lower cross frame
Figure 1. DBR6802 Olympic Spotter Bench
2 2
upright frames. The bend in the
9 9
M12 x 100 mm SHCS, 4
M12 nuts (Figure 3). Hand-tighten only.
16
16
2 2
13
13
16
16
3 3
Figure 3.
4
4
rear support frame and align to the holes on the
1
1
foot frame. Secure with 4
13 mm x 26 mm flat washers (Figure 4). Hand-tighten
13
13
2
2
4
4
1
1
Figure 4.
Foot frame
13
13
13 mm x
13
13
9 9
11
11
