ADDAC814 Assembly Guide
STEP 3:
Place the front panel and tighten the 6 nuts as shown below.
STEP 4:
Proceed by soldering all pots.
Finish it by placing all the knobs.
Proceed to the User's Guide to get info about connections.
https://www.addacsystem.com/contents/productdownload/ADDAC814_MatrixMixer_UsersGuide_6302.pdf
ADDAC SYSTEM
page 16
