- Page 1 JN-RM-2080 K32W module development reference manual Rev. 1.0 — 27 Mar 2020 Reference manual Document information Info Content Keywords K32W061/041, module Abstract Reference Manual for K32W061/041 modules and platform design. SECURITY STATUS...
- Page 2 STATUS Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 2 of 30...
-
Page 3: Introduction
K32W061/041 characteristics are available in the “K32W061/041 IEEE802.15.4 and BLE 5.0 Wireless Microcontroller” datasheet. The K32W-001-M10 module has been fitted to a mezzanine board (OM15077) for use on the IOTZTB evaluation kit. The module is known as K32W -001-T10. -
Page 4: Reference Design
−40 ºC to +125 ºC. Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 4 of 30... -
Page 5: Fig 1. K32W061-001-M10 & M13 Block Diagrams
K32W061 device and all necessary I/O connections. Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 5 of 30... -
Page 6: K32W061-001-M10 & M13
If the recommended footprint and Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 6 of 30... -
Page 7: Fig 5. Critical Layout Of Die Flag Area
• RF output and ground traces Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 7 of 30... -
Page 8: Fig 6. Pcb Stack-Up
PCB stack-up. Any small change in the Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 8 of 30... -
Page 9: Rf Circuit Topology And Matching
Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 9 of 30... -
Page 10: Transmission Lines
Keep the RF trace as short as possible. Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 10 of 30... -
Page 11: Fig 7. Rf Matching Network
Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 11 of 30... -
Page 12: Fig 8. Rf Plots For 3Pf Ceramic Capacitor Murata Grm1555 Type
Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 12 of 30... -
Page 13: Fig 9. Gnd Path Between C10/C12 And C19
GND path between C10/C12 and C19 Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 13 of 30... -
Page 14: Reference Oscillator
Ensure that each decoupling capacitor has its own via connection to ground. When Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 14 of 30... -
Page 15: Fig 10. Gnd Vias Placement
Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 15 of 30... -
Page 16: Fig 12. Vdd(Radio) Decoupling
Fig 14. VDDE decoupling Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 16 of 30... -
Page 17: Fig 15. Vbat Decoupling
Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 17 of 30... -
Page 18: Fig 16. Pcb Placement Of A K32W061 Module With A Printed Antenna
Fig 16. PCB placement of a K32W061 module with a printed antenna Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 18 of 30... -
Page 19: Fig 17. Recommended Pcb Decal For Hvqfn40 40-Pin Qfn
Fig 18. Extra test pin Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 19 of 30... -
Page 20: Solder Paste Mask For Hvqfn40 40-Pin Qfn
RF performance. Contact information For more information, please visit: http://www.nxp.com JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 20 of 30... -
Page 21: Regulations
EUROPEAN DECLARATION OF CONFORMITY (Simplified DoC per Article 10.9 of the Radio Equipment Directive 2014/53/EU) This apparatus, namely K32W-001-T10 module, conforms to the Radio Equipment Directive 2014/53/EU. The full EU Declaration of Conformity for this apparatus can be found at this location: www.nxp.com/K32W-001-T10... -
Page 22: Check List Schematic
Check list schematic Table 2. Schematic design-in check list SCHEMATICS Check Customer comments and/or Check done NXP Feedback number actions DESIGN-IN REVIEW CHECK-LIST GENERAL Have the schematics been checked versus NXP reference schematics & Application Notes? Have the schematics been reviewed by several people? Does the application use non standard components? (e.g. - Page 23 In case the XTAL model has not been recommended by NXP have all the parameters been checked in order they fulfill NXP, standard and application requirements (load capacitance,pulling sensitivity, equivalent resistance, frequency tolerance, temperature range, frequency drift versus temperature, ageing) ? 32 kHz crystal Oscillator Has the need of a 32 kHz XTAL been discussed ? ( Zigbee specifications can be met without an external...
- Page 24 Programming and Debug Has the flash programming connector been connected to the correct I/O on the microcontroller? Has a connector for debug been added that allows the microcontroller to be put into programming mode? (RSTN & PIO5/ISP pins) Is the reset pin RSTN properly connected? Add a test point at an unused DIO in order a trigger signal can be output from the pin for sensitivity measurements...
-
Page 25: Check List Layout
Check list layout Table 3. Layout design-in check list LAYOUT Check Customer comments and/or Check done NXP feedback number DESIGN-IN REVIEW CHECK-LIST actions GENERAL Has the number of layers been clearly discussed? Has the layout been checked versus NXP reference board? (i.e OM15069- 2_K32W061/041_ANTENNA_MODULE) - Page 26 For low supply voltage application – close to 2.0V, please ensure that the supply track is well dimensioned so as to avoid IR drop and hence falsely trigger the brown-out. (IR drop is the voltage drop due to the supply current flowing into the supply track resistance).
-
Page 27: Abbreviations
JN-RM-2080 NXP Semiconductors K32W module development reference manual 10. Abbreviations Table 4. Abbreviations Acronym Description Electro Magnetic Compatibility ETSI European Telecommunications Standards Institute Federal Communications Commission Personal Area Network Printed Circuit Board Radio Frequency SPI-bus Serial Peripheral Interface-bus TQFN Thin Quad Flat No-lead... -
Page 28: Table Of Contents
Vias on the paddle of the HVQFN40 40-pin QFN ................ 20 JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 28 of 30... -
Page 29: List Of Tables
Layout design-in check list ......25 Table 4. Abbreviations ..........27 SECURITY STATUS JN-RM-2080 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2020. All rights reserved. Rev. 1.0 — 27 Mar 2020 Reference manual 29 of 30... -
Page 30: Contents
JN-RM-2080 NXP Semiconductors K32W module development reference manual 14. Contents Introduction ............3 Audience ............3 Regulatory approvals ......... 3 Reference Design ..........4 Block diagram ............5 Design considerations ........5 K32W061/041 device footprint ......7 PCB Stack-Up ............ 8 RF circuit topology and matching .......
