Quick Start Guide for the
KIT33816FRDMEVM
Rev. 2.0
N o v . 1 3 . 2 0 1 4
External Use
Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off.
All other product or service names are the property of their respective owners. © 2014 Freescale Semiconductor, Inc.
TM
Advertisement
Related Manuals for NXP Semiconductors KIT33816FRDMEVM
Summary of Contents for NXP Semiconductors KIT33816FRDMEVM
- Page 1 Quick Start Guide for the KIT33816FRDMEVM Rev. 2.0 N o v . 1 3 . 2 0 1 4 External Use Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2014 Freescale Semiconductor, Inc.
- Page 2 Agenda • Getting to Know the KIT33816FRDMEVM • Getting Started Out of the Box • MC33816 Development tools • Explore Further External Use...
- Page 3 Getting to Know the KIT33816FRDMEVM VBAT External Use...
- Page 4 Getting to Know the KIT33816FRDMEVM • MC33816 direct injection pre-driver integrated circuit • USB-to-SPI dongle interface using the FRDM-KL25Z • External MOSFETs controlling 4 injectors and 2 fuel pumps • Power-conditioning circuitry • +12 V VSUPP provides the power to the MC33816 and the loads...
-
Page 5: Getting Started Out Of The Box
Getting Started Out of the Box • Installing and Running the Out of the Box Demo Download and Install SPIGEN 7.x from http://www.freescale.com/SPIGEN Plug in a USB cable from a USB host to the KL25Z_USB. The FRDM-KL25Z will be powered by this USB connection. Run SPIGEN 7.1 (or latest). - Page 6 Getting Started Out of the Box • Program MC33816 with SPIGEN 7.x Click on Open and load the configuration file KIT33816AESW_Rev2.0.spi Select Micro Code from left tab Set RSTB and DRVEN to High Click on Load Filenames and select the SPIGen33816Files.txt file from the KIT33816SW Click on Download All, a pop up Download complete window appears.
- Page 7 MC33816 Development Tools KIT33816FRDMEVM .bin MC33816 IDE Files SPIGEN KL25Z MC33816 • Edit and compile source code • Create register configurations • Generate C files arrays* •SPI software to • 4 cylinders + Fuel Pump control • control MC33816 DCDC control •...
- Page 8 Explore Further Now that you are familiar with the KIT33816FRDMEVM and SPIGEN, it’s time to explore the additional software and user guide available on www.freescale.com . Select your next path from the links in the Jump Start Your Design section.
-
Page 9: Revision History
Revision History Revision Date Description of Changes • Initial release 10/2014 • Updated the filename in step 5 on page 4 11/2014 External Use... - Page 10 www.Freescale.com © 2014 Freescale Semiconductor, Inc. | External Use...
