Summary of Contents for DFI KS170-ADN
- Page 1 KS170-ADN & KS150-ADN 15" & 17" Industrial Touch Panel PC User’s Manual © April 02, 2025 DFI Inc.
-
Page 2: Fcc And Doc Statement On Class A
1. The changes or modifications not expressly approved by the party responsible for com- are the properties of the respective owners. pliance could void the user’s authority to operate the equipment. 2. Shielded interface cables must be used in order to comply with the emission limits. User's Manual | KS150-ADN & KS170-ADN... -
Page 3: Table Of Contents
SATA0 (J4) ........................28 Backlight CON (DPJ2) ....................28 COM1 Power Select (TSJP1) ..................29 COM2 Power Select (TSJP2) ..................29 COM1 (TSJ1) .........................30 COM2 (TSJ2) .........................30 COM1 RS232/RS422/RS485 (TSJ1) ..................30 COM3 (TSJ3) .........................30 COM4 (TSJ4) .........................30 COM5 (TSJ5) .........................30 User's Manual | KS150-ADN & KS170-ADN... -
Page 4: About This Manual
It must be returned to the purchase point, factory or authorized service agency for all such work. 4. We will not be liable for any indirect, special, incidental or consequential damages to the product that has been modified or altered. User's Manual | KS150-ADN & KS170-ADN... -
Page 5: Static Electricity Precautions
Make sure the system is placed or mounted correctly and stably to prevent the chance of dropping or falling may cause damage. • The openings on the system shall not be blocked and shall be kept in distance from User's Manual | KS150-ADN & KS170-ADN... -
Page 6: Chapter 1 - Introduction
Chapter 1 INTRODUCTION Chapter 1 - Introduction X Dimensions X I/O Overview KS150-ADN KS150-ADN 46.10 KS170-ADN KS170-ADN 403.74 59.50 HDMI Power Button Line-Out 2.5G LAN COM Ports 1~4 USB3.2 Gen2 DC-In USB2.0 DP++ User's Manual | KS150-ADN & KS170-ADN... -
Page 7: Key Features
® Processor N97, Quad core Touch Type: Projected Capacitive / 5-Wire Resistive Touch Dual Display: HDMI & DP++ Multiple Expansions: M.2 2242/3042 B Key M.2 2230 E Key Wide Voltage: Support 9 ~ 36V User's Manual | KS150-ADN & KS170-ADN... -
Page 8: Specifications
DP++: resolution up to 3840x2160 @ 60Hz DP++: resolution up to 3840x2160 @ 60Hz HDMI: resolution up to 3840x2160 @ 24Hz HDMI: resolution up to 3840x2160 @ 24Hz Dual Displays DP++ + HDMI DP++ + HDMI User's Manual | KS150-ADN & KS170-ADN... - Page 9 1 x Power Button 1 x Power Button Type DC 9-36V DC 9-36V POWER Connector DC Jack DC Jack Consumption Microsoft Windows 10 IoT Enterprise 64bit Windows 10 IoT Enterprise 64bit OS SUPPORT Linux Linux Linux User's Manual | KS150-ADN & KS170-ADN...
- Page 10 OP: Random, 1Grms @ 5~500Hz, 30min Non-OP: Sweep sine, 3Grms OP: Random, 1Grms @ 5~500Hz, 30min Non-OP: Sweep sine, 3Grms @ CERTIFICATION Vibration @ 10~500Hz, 30min 10~500Hz, 30min MIL-STD-810G Standard MIL-STD-810G Standard Certifications CE/FCC Class A CE/FCC Class A User's Manual | KS150-ADN & KS170-ADN...
-
Page 11: Chapter 2 - Hardware Installations
Step 1: The 8 screws of the system are used to secure the cover to the chassis. Remove the screws and put them in a safe place for later use. KS150-ADN KS150-ADN KS170-ADN KS170-ADN User's Manual | KS150-ADN & KS170-ADN... -
Page 12: Installing A Ssd Tray
4. Connect the SATA cable and the SATA power cable to SSD and the board connectors. Note: After the SATA SSD is correctly mounte, please attach the bottom cover back on as previously instructed User's Manual | KS150-ADN & KS170-ADN... -
Page 13: Expansion Slots
4. Make sure the notch on card is aligned to the key on the socket. 5. Make sure the standoff screw is removed from the standoff. M.2 Module M.2 Socket SO-DIMM1 Stand-off Notch M.2 E Key M.2 B-Key M.2 A-Key M.2 E-Key User's Manual | KS150-ADN & KS170-ADN... - Page 14 Screw tight the card onto the stand-off with a screw driver and a stand-off screw until the gap between the card and the stand-off closes up. The card should be lying parallel to the board when it’s correctly mounted. User's Manual | KS150-ADN & KS170-ADN...
-
Page 15: Mounting Options
Then tighten the screw to secure the assembly in place. hooks. Then tighten the screw to secure the assembly in place. Screw Screw Wall mount bracket 1 Wall mount bracket 1 Wall mount bracket 2 Wall mount bracket 2 User's Manual | KS150-ADN & KS170-ADN... -
Page 16: Panel Mount
Step 2: Cut out a shape on the panel that corresponds to the Panel PC’s rear dimensions: KS150-ADN (359mm x 283mm), KS170-ADN (390mm x 322mm) and ensure that the Panel PC can be fitted into the panel properly. The flat panel thickness is less than 10mm. Be sure to route or trim down the thick wall to 10 mm or slightly less for the clamps to recess and be compatible with your wall or enclosure. -
Page 17: Chapter 3 - System Settings
COM2 SATA Power COM3 COM4 Backlight CON SO-DIMM1 SATA Power COM5 COM6 Clear CMOS Data Front Audio SATA1 M.2 E Key SATA0 Buzzer COM1 Power Select USB2.0 Pin Header RTC Battery COM2 Power Select User's Manual | KS150-ADN & KS170-ADN... -
Page 18: Jumper Settings
9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key „ 1-2 Open: Normal (Default) „ 2-3 Short: SATA1 CONN „ 1-2 Short: M.2 B-KEY, SATA (Default) „ 1-2 Short: Clear CMOS Data User's Manual | KS150-ADN & KS170-ADN... -
Page 19: Pcie Slotx2/M.2 E-Key (Pbjp2)
9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key „ 2-3 Short: PCIEx2 Slotx2 (Optional) „ 2-3 Short: USB3-TYPE-A „ 1-2 Short: M.2 E-KEY, PCIEx1 (Default) „ 1-2 Short: M.2 B-KEY, USB3 (Default) User's Manual | KS150-ADN & KS170-ADN... -
Page 20: Panel Backlight On Level Select (Dpjp1)
9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key „ 2-3 Short: 5V „ 1-2 Short: 12V „ 3-4 Short: 5V „ 5-6 Short: 3V3 (Default) „ 1-2 Short: 3V3 (Default) User's Manual | KS150-ADN & KS170-ADN... -
Page 21: Inverter Panel Power Select (Dpjp4)
Inverter Panel Power Select (DPJP4) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key „ 2-3 Short: 5V „ 1-2 Short to 5VSB: Normal (Default) „ 2-3 Short: GND „ 1-2 Short: 12V (Default) User's Manual | KS150-ADN & KS170-ADN... -
Page 22: Dio_4~7 Power Select (Jp5)
Chapter 3 SYSTEM SETTINGS DIO_4~7 Power Select (JP5) 9 10 SO-DIMM1 M.2 E Key „ 1-2 Short to 5VSB: Normal (Default) „ 2-3 Short: GND User's Manual | KS150-ADN & KS170-ADN... -
Page 23: Pin Assignment
Chapter 3 SYSTEM SETTINGS X Pin Assignment RTC Battery (J19) Case Open (J2) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment V_BAT Case Open- User's Manual | KS150-ADN & KS170-ADN... -
Page 24: Uart Header (Debug) (Jp4)
Chapter 3 SYSTEM SETTINGS UART Header (Debug) (JP4) System Fan (J20) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment DEBUG_UART_TX DEBUG_UART_RX +12V TACH User's Manual | KS150-ADN & KS170-ADN... -
Page 25: System Fan (J10)
Chapter 3 SYSTEM SETTINGS System Fan (J10) DIO (J16) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment D_IOA7 Assignment D_IOA6 D_IOA5 +12V D_IOA4 D_IOA3 D_IOA2 TACH D_IOA1 D_IOA0 5VSB User's Manual | KS150-ADN & KS170-ADN... -
Page 26: Sata Power (Cn8)
Chapter 3 SYSTEM SETTINGS SATA POWER (CN12) SATA POWER (CN8) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment User's Manual | KS150-ADN & KS170-ADN... -
Page 27: S/Pdif (Auj2)
Chapter 3 SYSTEM SETTINGS SATA1 (J12) S/PDIF (AUJ2) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment SPDIF OUT SPDIF IN User's Manual | KS150-ADN & KS170-ADN... -
Page 28: Sata0 (J4)
Chapter 3 SYSTEM SETTINGS Backlight CON (DPJ2) SATA0 (J4) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment VCC_PANEL_PWR LVDS_3V3 BLONOFF INV_PWR INV_PWR User's Manual | KS150-ADN & KS170-ADN... -
Page 29: Com1 Power Select (Tsjp1)
SYSTEM SETTINGS COM2 Power Select (TSJP2) COM1 Power Select (TSJP1) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment Assignment Assignment MRI- MDCD- MRI- MDCD- X_MRI- X_MDCD- X_MRI- X_MDCD- User's Manual | KS150-ADN & KS170-ADN... -
Page 30: Com1 (Tsj1)
X COM1 RS232/RS422/RS485 (TSJ1) RS422 Full RS232 RS485 Duplex DCD- Data- X COM2/COM3/COM4/COM5/COM6 Data+ Assignment Assignment Assignment Assignment MIC2_L DTR- MDCD- MSIN- MIC2_R MSO- MDTR- DSR- LINE2_R MIC2_JD RTS- MDSR- CTS- MRTS- MCTS- LINE2_L LINE2_JD MRI- ---- User's Manual | KS150-ADN & KS170-ADN... -
Page 31: Usb2.0 Pin Header (J3)
USB2.0 Pin Header (J3) USB2.0 Pin Header (J21) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment Assignment Assignment USB2_1_HUB_C_N USB2_2_HUB_C_N USB2_4_C_N USB2_3_C_N USB2_1_HUB_C_P USB2_2_HUB_C_P USB2_4_C_P USB2_3_C_P ---- ---- User's Manual | KS150-ADN & KS170-ADN... -
Page 32: Espi Header(Debug) (J5)
Header(Debug) (J5) 9 10 9 10 SO-DIMM1 SO-DIMM1 M.2 E Key M.2 E Key Assignment Assignment Assignment Assignment 3V3SB ESPI_CLK 3V3SB ESPI_RESET# 3V3SB ESPI_ALT# HD_LED# SUS_LED# ESPI_D0 ESPI_D1 ESPI_CS SYS_RST0 PWR_BTN0 ESPI_D2 3V3SB ESPI_D3 3V3SB User's Manual | KS150-ADN & KS170-ADN... -
Page 33: Chapter 4 - Bios Settings
“Press DEL to run setup” will appear on the screen. If the message disappears before you respond, restart the system or press the “Reset” button. You may also restart the system by pressing the <Ctrl> <Alt> and <Del> keys simultaneously. User's Manual | KS150-ADN & KS170-ADN... -
Page 34: Main
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays min- utes from 00 to 59. Second displays seconds from 00 to 59. User's Manual | KS150-ADN & KS170-ADN... -
Page 35: Rc Acpi Settings
(G3 state). • S0 State The system automatically powers on after power failure. • S5 State The system enter soft-off state after power failure. Power-on signal input is required to power up the system. User's Manual | KS150-ADN & KS170-ADN... -
Page 36: Power & Performance
When this field is set to Disabled, ME will be put into ME Temporarily Disabled Mode. enabled. C states Enable or disable CPU Power Management. It allows CPU to enter "C states" when it’s idle and nothing is executing. User's Manual | KS150-ADN & KS170-ADN... -
Page 37: Intel(R) Time Coordinated Computing
Lock to un-cacheable memory before the bus is locked. Software SRAM Enable or Disable Software SRAM. Enable will allocate 1 way of LLC; if Cache Configuration subregion is available, it will allocate based on the subregion. User's Manual | KS150-ADN & KS170-ADN... -
Page 38: Trusted Computing
To clear the existing TPM encryption, select "TPM Clear" and restart the system. This field is Set SuperIO WatchDog Timer Timeout value. The range is from 0 (disabled) to 255. not available when "Security Device Support" is disabled. Note: The sub-menus are detailed in following sections. User's Manual | KS150-ADN & KS170-ADN... -
Page 39: Serial Port 1, 2 Configuration
IT8786 Super IO Configuration ► Serial Port 1, 2 Configuration IT8786 Super IO Configuration ► Serial Port 3, 4 Configuration Serial Port Serial Port Enable or disable serial port. Enable or disable serial port. User's Manual | KS150-ADN & KS170-ADN... -
Page 40: It8786 Super Io Configuration It8786 Super Io Configuration It8786 Super Io Configuration It8786 Hw Monitor
This section displays the system’s health information, i.e. voltage readings, CPU and system temperatures, and fan speed readings Case Open Enable or disable the case open detection function. Serial Port Enable or disable serial port. User's Manual | KS150-ADN & KS170-ADN... -
Page 41: Serial Port Console Redirection
Serial Port Console Redirection ► Console Redirection Settings Console Redirection By enabling Console Redirection of a COM port, the sub-menu of console redirection settings will become available for configuration as detailed in the following. User's Manual | KS150-ADN & KS170-ADN... -
Page 42: Serial Port Console Redirection Network Stack Configuration
Set the wait time in seconds to press ESC key to abort the PXE boot. Use either +/- or numeric keys to set the value. Media detect count Set the number of times the presence of media will be checked. Use either +/- or numeric keys to set the value. User's Manual | KS150-ADN & KS170-ADN... -
Page 43: Usb Power Control
Chapter 4 BIOS SETTINGS Advanced USB Power Control Server CA Configuration 5_Dual: Support system wake up from S3/S4 by USB KB&MS 5V: No support system wake up from S3/54 by USB KB&MS User's Manual | KS150-ADN & KS170-ADN... -
Page 44: Chipset
Chapter 4 BIOS SETTINGS X Chipset Chipset System Agent (SA) Configuration Please select a submenu and press Enter. The submenus are detailed in the following pages. Memory Configuration Memory Configuration Parameters Graphics Configuration Graphics Configuration User's Manual | KS150-ADN & KS170-ADN... -
Page 45: Pch-Io Configuration
Select one of the PCI Express channels and press enter to configure the following settings. PCI Express Configuration Settings LAN1, LAN2, PCIE1, M.2-E, M.2-B SATA And RST Configuration Control the PCI Express Root Port. SATA Device Otpions Settings HD Audio Configuration HD Audio Subsystem Configuration Settings User's Manual | KS150-ADN & KS170-ADN... -
Page 46: Configuration► Sata And Rst Configuration
The mode selection determines how the SATA controller(s) operates. • Enabled HDA will be unconditionally enabled. • AHCI This option allows the Serial ATA controller(s) to use AHCI (Advanced Host Controller Interface). Ports Enable or disable the Serial ATA port. User's Manual | KS150-ADN & KS170-ADN... -
Page 47: Security
Clear the database from the NVRAM, including all the keys and signatures installed in the Key Management menu. Press Enter and a prompt will show up for you to confirm. Key Management Enables expert users to modify Secure Boot Policy variables without full authentication. User's Manual | KS150-ADN & KS170-ADN... -
Page 48: Boot
Refer to the Advanced > CSM Configuration submenu for more information. • Restore Setting from file This field will appear only when a USB flash device is detected. Select this field to restore set-ting from the USB flash device. User's Manual | KS150-ADN & KS170-ADN... -
Page 49: Updating The Bios
When the BIOS IC needs to be replaced, you have to populate it properly onto the system board after the EEPROM programmer has been burned and follow the technical person's instructions to confirm that the MAC address should be burned or not. User's Manual | KS150-ADN & KS170-ADN...
