- Page 1 Quick Installation Guide KS156P-TGU & KS215P-TGU 15.6" & 21.5" Industrial Touch Panel PC www.dfi.com Package Contents 1 x Touch Panel PC 1 x Quick Installation Guide 1 x Poron Foam © May 08, 2024 DFI Inc.
- Page 2 I/O Overview KS156P-TGU KS215P-TGU USB 3.2 Gen2 DC-In Line-Out DP++ COM Ports 2~4 HDMI COM1 Power Button 2.5G LAN USB Type-C Quick Installation Guide | KS156P-TGU & KS215P-TGU...
-
Page 3: Removing The Chassis Cover
The 8 screws of the system are used to secure the cover to the chassis. Remove the screws and put them in a safe place for later use. Step 2: Lift the cover to open the system. Quick Installation Guide | KS156P-TGU & KS215P-TGU... -
Page 4: Mounting Options
Slide the Panel PC to wall mount bracket 1 and attach the two brackets together with the hooks. Then tighten the screw to secure the assembly in place. VESA Mount- KS156P-TGU VESA Mount- KS215P-TGU Quick Installation Guide | KS156P-TGU & KS215P-TGU... -
Page 5: Panel Mount
Tighten the clamp’s screw using an electric screwdriver by pressing the white plastic cap onto the back of the panel. The illustration below shows that all clamps are properly mounted. Quick Installation Guide | KS156P-TGU & KS215P-TGU... -
Page 6: Installing An Antenna
Cable Antenna Connector Washer DFI reserves the right to change the specifications at any time prior to the product's release. This QR may be based on the product’s revision. For more documentation and drivers, please visit the download page at www.dfi.com/...
