- Page 1 Quick Installation Guide KS156P-EHL & KS215P-EHL 15.6" & 21.5" Industrial Touch Panel PC www.dfi.com Package Contents 1 x Touch Panel PC 1 Quick Installation Guide © September 08, 2023 DFI Inc.
- Page 2 Product Overview I/O Views USB 3.2 Gen1 DC-In Line-Out DP++ COM Ports 1~4 HDMI Power Button 2.5G LAN USB 3.2 Gen2 Quick Installation Guide | KS156P-EHL & KS215P-EHL...
- Page 3 The 8 screws of the system are used to secure the cover to the chassis. Remove the screws and put them in a safe place for later use. Step 2: Lift the cover to open the system. Quick Installation Guide | KS156P-EHL & KS215P-EHL...
- Page 4 Slide the Panel PC to wall mount bracket 1 and attach the two brackets together with the hooks. Then tighten the screw to secure the assembly in place. Screw Wall mount bracket 1 Wall mount bracket 2 Quick Installation Guide | KS156P-EHL & KS215P-EHL...
- Page 5 Tighten the clamp’s screw using an electric screwdriver by pressing the white plastic cap onto the back of the panel. The illustration below shows that all clamps are properly mounted. Quick Installation Guide | KS156P-EHL & KS215P-EHL...
- Page 6 Tighten the clamp’s screw using an electric screwdriver by pressing the white plastic cap onto the back of the panel. The illustration below shows that all clamps are properly mounted. Quick Installation Guide | KS156P-EHL & KS215P-EHL...
- Page 7 Cable Antenna Connector Washer DFI reserves the right to change the specifications at any time prior to the product's release. This QR may be based on the product’s revision. For more documentation and drivers, please visit the download page at www.dfi.com/...
