DoorKing 2100 Series Product Reference Manual

Telephone / video entry & access control systems

Hide thumbs

page of 42

/ 42
Bookmarks

Quick Links

Download this manual

JUNE 2025

Product Reference Guide – June 2025.

Telephone / Video Entry & Access Control Systems

Date

Page

6-1-25

All

Specifications subject to change without notice.

Comment

Reference guide published.

PRODUCT REFERENCE GUIDE

Telephone Entry & Access Control Systems

Section A2

Page 1

Need help?

Do you have a question about the 2100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DoorKing 2100 Series

Page 1 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Section A2 Product Reference Guide – June 2025. Telephone / Video Entry & Access Control Systems Date Page Comment 6-1-25 Reference guide published. Specifications subject to change without notice. Page 1...
Page 2 Using the DoorKing Cloud, you can program and manage your access system from any device (laptop, tablet, smartphone) with an internet connection – a dedicated PC is no longer needed. The DoorKing Cloud is included with Cellular, VoIP, DoIP and IM Server subscriptions.
Page 3 Model 1835 ................................22 Model 1837 ................................24 Model 1838 ................................26 Model 1838 Access Plus ............................28 Model 2100 Series Video Entry Systems ......................30 Accessories Connection Options .............................. 32 Elevator Control ..............................33 Tracker Expansion Boards ............................ 34 Wireless Kits for Tracker Expansion Boards ......................
Page 4 1802 AP uses a standard RS-485 data input. Six (6) additional entry points can be controlled via RS-485 card readers, AVID tag readers, RF receivers or digital keypads. AP Programming software available for free download at doorking.com. Single line 16 character 5/16 LCD display.
Page 5 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1802 Telephone Entry System Residential, Commercial 1802 Telephone Entry Systems 1802 AP (ACCESS PLUS ONLY) Expansion Options 1802-082 Surface Mount 2354-010 Conversion Board 1802-089 Flush Mount 1815-235 Conversion Board w/Enclosure 1802-090 Surface Mount EPD Converts 26-bit Wiegand to RS-485.
Page 6 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 1803 Telephone Entry System Residential, Commercial 1803 • Hands free full duplex voice communication • Stainless steel faceplate • Programmable Directory Codes (1-4 digits) • Galvanized steel sub-plate 16-digit dialing Metal keypads and buttons •...
Page 7 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1803 Telephone Entry System Residential, Commercial 1803 Telephone Entry Systems Mounting Accessories 1803-080 Surface Mount 1803-150 Surface Mount Recess Kit 1803-084 Flush Mount 1814-165 Flush Mount Kit Stainless Steel 1803 Lobby Panels Accessories 1803-090 Surface Mount...
Page 8 RS-485 data input. Six (6) additional entry points can be controlled via RS-485 card readers, AVID tag readers, RF receivers or digital keypads. AP Programming software available for free download at doorking.com. Paper directory. Directory can be printed from Access Plus programming software.
Page 9 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1808 Telephone Entry System Residential, Commercial 1808 Telephone Entry Systems 1808 AP (ACCESS PLUS ONLY) Expansion Options 1808-082 Surface Mount w/Directory 2354-010 Conversion Board 1808-084 Surface Mount 1815-235 Conversion Board w/Enclosure 1808-085 Surface Mount AP (Access Plus) Converts 26-bit Wiegand to RS-485.
Page 10 RS-485 data input. Six (6) additional entry points can be controlled via RS-485 card readers, AVID tag readers, RF receivers or digital keypads. AP Programming software available for free download at doorking.com. Paper directory. Access Plus model does not have any programming display. Directory can be printed from Access Plus programming software.
Page 11 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1810 Telephone Entry System Residential, Commercial 1810 Telephone Entry Systems 1810 AP (ACCESS PLUS ONLY) Expansion Options 1810-080 Surface Mount 2354-010 Conversion Board 1810-084 Flush Mount 1815-235 Conversion Board w/Enclosure 1810-095 Surface Mount AP (Access Plus) Converts 26-bit Wiegand to RS-485.
Page 12 Six (6) additional entry points can be controlled via RS-485 card readers, AVID tag readers, RF receivers or digital keypads. Access Plus Programming software available for free download at doorking.com. Each relay can be programmed with 25 entry codes with specific functions (see the installation manual 1812-065 for detailed information).
Page 13 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1812 Telephone Entry Systems Residential 1812 Classic Systems 1812 Access Plus Systems 1812-081 Surface Mount 1812-096 Surface Mount Curved 1812-097 Surface Mount w/Camera 1812-090 Surface Mount 1812-087 Flush Mount 1812-099 Surface Mount w/Camera 1812-092 Flush Mount...
Page 14 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 1816 Telephone Intercom Systems Commercial 1816 • Full duplex voice communication • Lobby panel / Doorman caller ID • Interfaces with up to 1200 phone lines •...
Page 15 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1816 Telephone Intercom Systems Commercial 1816 Systems Step 1: Main Control Cabinet Step 5: Phone Blocks and Cables 1816-080 Houses 13 Relay Boards (156 lines) 2370-010 RJ71C Phone Block One (1) RJ71C is required for each relay board in the system.
Page 16 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 1819 Information Telephone System Commercial 1819 • Full duplex voice communication • Stores a single phone number 10 and 11 digit dialing • • Call button 6.50 5.00 165.10 mm...
Page 17 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1819 Information Telephone System Commercial 1819 Telephone Entry System 1819-080 Surface Mount Service Connection Options 1800-080 Cellular Voice + Data 1815-578 VoIP Adapter 1 - Cellular service plan required. See Section D1. 2 - DKS VoIP subscription required.
Page 18 This is reduced to 24 if using wireless expansion. DKS Cloud is included with connection service subscription plans. Programming with a dedicated PC is available using the Remote Account Manager software - available for free download at doorking.com. Page 18...
Page 19 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1833 Telephone Entry / Access Control System Residential, Commercial 1833 Telephone Entry / Access Control System Expansion Options 2358-010 Tracker Expansion Board 1833-080 80 Series Surface Mount 1833-084 80 Series Flush Mount 2351-080 Sgl Box (1 board max)
Page 20 1834 does not have any 26-bit wiegand inputs. DKS Cloud is included with connection service subscription plans. Programming with a dedicated PC is available using the Remote Account Manager software - available for free download at doorking.com. Page 20 Specifications subject to change without notice.
Page 21 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1834 Telephone Entry / Access Control System Residential, Commercial 1834 Telephone Entry / Access Control System 1834-080 80 Series Surface Mount 1834-084 80 Series Flush Mount 1834-090 90 Series Surface, Flush or Wall Mount Service Connection Options 1800-080 Cellular Voice + Data...
Page 22 This is reduced to 24 if using wireless expansion. DKS Cloud is included with connection service subscription plans. Programming with a dedicated PC is available using the Remote Account Manager software - available for free download at doorking.com. Page 22...
Page 23 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1835 Telephone Entry / Access Control System Residential, Commercial 1835 Telephone Entry / Access Control System Expansion Options 1835-080 80 Series Surface Mount 2358-010 Tracker Expansion Board 1835-084 80 Series Flush Mount 2351-080 Sgl Box (1 board max)
Page 24 This is reduced to 24 if using wireless expansion. DKS Cloud is included with connection service subscription plans. Programming with a dedicated PC is available using the Remote Account Manager software - available for free download at doorking.com. Page 24...
Page 25 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1837 Telephone Entry / Access Control System Residential, Commercial 1837 Telephone Entry / Access Control System Expansion Options 1837-080 80 Series Surface Mount 2358-010 Tracker Expansion Board 1837-084 80 Series Flush Mount 2351-080 Sgl Box (1 board max)
Page 26 This is reduced to 24 if using wireless expansion. DKS Cloud is included with connection service subscription plans. Programming with a dedicated PC is available using the Remote Account Manager software - available for free download at doorking.com. Page 26...
Page 27 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1838 Access Controller Commercial 1838 Access Controller Expansion Options 1838-081 Surface Mount 2358-010 Tracker Expansion Board 2351-080 Sgl Box (1 board max) Service Connection Options 2351-085 Sgl Box + 1470-080 900 MHz RF Module 2351-082 QUAD Box Pre-wired...
Page 28 1838 AP uses a standard RS-485 data input. Six (6) additional entry points can be controlled via RS-485 card readers, AVID tag readers, RF receivers or digital keypads. AP Programming software available for free download at doorking.com. Page 28 Specifications subject to change without notice.
Page 29 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 1838 Access Plus Controller Residential, Commercial 1838 Access Plus Controller 1838 Access Plus Expansion Options 1838-095 Surface Mount 2354-010 Conversion Board 1815-235 Conversion Board w/Enclosure Service Connection Options Converts 26-bit Wiegand to RS-485.
Page 30 Up to four (4) phone numbers per directory code. 10 directory codes are available, meaning the 2100 series can be used for up to 10 residents. Directory codes can be set for one (1) to five (5) digits in length.
Page 31 Standard Residential Package monthly subscription fee is 2 – Use with flush or surface mount units. required for 2100 series systems to operate. See Section D1. 3 – AT&T cellular service requires Minimum Build 32 (check your 2108 Subscription fee includes: / 2112 online account event log –...
Page 32 DKS Cloud is included with connection service subscription plans which allow programming from a laptop, tablet or smartphone. Programming with a dedicated PC is also available using the Remote Account Manager software - available for free download at doorking.com. TCP/IP Network Adapters...
Page 33 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 Model 2348 Elevator Control 13.25 5.00 367 mm 127 mm 13.25 5.00 367 mm 127 mm 35.25 7.90 895 mm 200 mm 21.25 540 mm 13.20 335 mm 2348-040 2348-080...
Page 34 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 Expansion Boards Tracker Expansion Boards 14.25 4.00 362 mm 102 mm 24.38 6.00 3.63 619 mm 152 mm 92 mm 4.63 5.50 118 mm 140 mm 9.00 229 mm 2358-010...
Page 35 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 Wireless Kits Tracker Expansion Board Wireless Kits 900 MHz IMPORTANT! 900 MHz wireless expansion can only be used with 2358 expansion boards, REV N or higher. 6.89 175 mm 4.75...
Page 36 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 Mounting Kits Telephone Entry System Mounting Kits Use with 1803, 1810 and 1833, 1834, 1835, 1837 - 80 Series only 13.50 3.75 14.50 3.88 12.00 2.63 343 mm 95 mm 368 mm...
Page 37 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 Model 1720 Telephone Entry System LED Light Kit LED Light Kit - Long 1720-080 • Use with surface mount 1803, 1810, 1833, 1834, 1835 and 1837 systems. LED Light Kit - Short 1720-081 •...
Page 38 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 General Purpose Utility Enclosures Telephone Entry System Accessories 14.25 362 mm 11.50 12.25 292 mm 6.63 24.38 6.00 311 mm 168 mm 619 mm 152 mm 12.25 10.25 9.88...
Page 39 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 Blank Page Specifications subject to change without notice. Page 39...
Page 40 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Page Rev 6/1/25 Accessories Handset Kits, Isolation Transformers, Miscellaneous, CCTV Camera Kits Handset Conversion Kit CCTV Camera Kit – High Resolution 1807-012 1812-145 Handset, adapter, hanger and speaker cover High resolution color camera kit (camera, mounting bracket, wire harness, power supply) Replacement Handset...
Page 41 JUNE 2025 PRODUCT REFERENCE GUIDE Telephone Entry & Access Control Systems Page Rev 6/1/25 Replacement Components Electronic Components Circuit Boards Keypads 1800-009 1895-017 Use with 1800-081 only (Access Plus Cellular) Keypad no letters 1800-010 1895-019 Use with 1800-080 only (Voice + Data Cellular) Keypad 10-pin 1862-010 1804-038...
Page 42 PRODUCT REFERENCE GUIDE JUNE 2025 Telephone Entry & Access Control Systems Blank Page Page 42 Specifications subject to change without notice.
