Installation Manual
Use this manual for circuit board 1601-010 Revision W or higher.
WARNING pre-stressed concrete may be used in multi-level parking garages. Cutting a tensioned cable, or
tendon, can endanger the contractor and compromise the structural integrity of the floor. Contact the
building structural engineer for specific instructions and information BEFORE drilling or saw cutting into the floor.
INSTALLATION AND USE OF THE WEDGE BARRIER IN AREAS SUBJECT TO FREEZING WEATHER WITH POTENTIAL FOR
SNOW AND ICE ACCUMULATION IS NOT RECOMMENDED.
THIS PRODUCT IS TO BE INSTALLED AND SERVICED BY A TRAINED GATE/DOOR SYSTEMS TECHNICIAN ONLY.
Visit www.doorking.com/dealer-locator to find a professional installing and servicing dealer in your area.
The 1625 wedge barrier is not a stand-alone product. It must be used with
a 1602-590 Barrier Gate Operator (sold separately). The 1625 is not crash
UL 325 Compliant
rated. It is intended to provide a more formidable barrier in conjunction
with a standard barrier arm operator system. The 1625 is ideally used to
control passenger vehicles and lightduty trucks.
Surface Mount Vehicular Wedge Barrier Accessory
IMPORTANT: Installation of Traffic Light, Photocell
and Octagon Arm with LED Edge is REQUIRED.
®
