Pilot Communications Matrix 2.8m Assembly Manual

Sport jet
Hide thumbs

Advertisement

Table of Contents

Assembly Manual For
Matrix 2.8m
Sport jet
Wingspan: 88 in
Wingarea: 1479.8 sp in
Length: 78.8 in
Engine: 50CC
www.pilot-rc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix 2.8m and is the answer not in the manual?

Questions and answers

Related Manuals for Pilot Communications Matrix 2.8m

Summary of Contents for Pilot Communications Matrix 2.8m

  • Page 1 Assembly Manual For Matrix 2.8m Sport jet Wingspan: 88 in Wingarea: 1479.8 sp in Length: 78.8 in Engine: 50CC www.pilot-rc.com...
  • Page 2 INTRODUCTION Pilot-RC Matrix is an innovative approach to a new sport jet/ 3Djet. Great capabilities had to be combined between sport jet and unbeatable 3D performance. everything aerodynamic we tested and learned from Predator and develop together with one of the best pilot in the world for Matrix performance so we can say this is best ever sport jet with ultimate flying characteristics for precise aerobatics and 3D aerobatics at the same time..
  • Page 3 INTRODUCTION Thank you for purchasing our Matrix Sport Jet. we strive to achieve the real Quick Builded and ARF aircraft. It just requires the least about of assembly of any kit that almost finished in factory. To obtain the perfect performance, both the design and manufacturing have been taken care with the highest...

  • Page 4: Warranty

    WARRANTY ■ All Pilot-RC products are guaranteed against defects for 30 days of receiving your airplane. This warranty is limited to construction or productions defects in both material and workmanship , doesn't cover any component parts damaged by use or modification . ■...
  • Page 5 ATTENTION You should not regard this plane as toy! ■ To ensure safety,please read the instruction ■ manual thoroughly before assembly . ■ Building and operating model plane require diligent practicing and correct guidance. Any neglect,carelessness and missing experience can cause serious bodily harm and property damage.
  • Page 6 Landing Gear Assembly Retract Landing Gear Installation, Matrix Jet come with electric-landing gear and brakes.

  • Page 7: Nose Gear Assembly

    Nose Gear Assembly 3. Place the nose gear to the 1, Install the servo to the nose mounting and adjust to the correct landing gear. position ; then mark the 4 mounting screws hole. 2. Install the servo arm and push rod.

  • Page 8: Landing Gear Assembly

    Landing Gear Assembly 5. Carefully arrange the nose gear 7. We including Retract Gear Box retract wire lead and the steering wire as well ... 6. Install the nose retract gear to the fuselage.
  • Page 9 Landing Gear Assembly 8. this 4 in 1 MPX connector from Pilot-RC. It is come with kit For wing and back part fueslage 9. Connect all servo / landing gear 10. The multi connector in 1 out /brakes wire . from the opening hole in the fuselage...
  • Page 10 Wing servo/flaps Assembly 11. Take out the aileron / flaps plating 13. Carefully adjust the servo arm from the wing. position , should be at the center of the open slot. 12.Put servo to the hole precut slot 14. After servo and servo arm inside the wing.
  • Page 11 WING SERVO/FLAPS Assembly 15. Aileron servo / Flaps servo done 17. Just one connector for installed . aileron/flaps/landing gear/ brakes. 16. Picture below show the installed landing gear and the aileron/flap servo...

  • Page 12: Rudder Servo Assembly

    Rudder Servo Assembly 1. Put servo in the hole precut 2. This is how the rudder slot of vertical fin and servo put in slot and install screw in servo arm to be correct center position 3. Install linkage of rudder...

  • Page 13: Elevator Servo Assembly

    Elevator Servo Assembly 1. Next is the elevators 4. You may shorthen the servo wireas show in the pic. 2. Put in the servo to the precut slot in the elevator.. 5. The other side of the servo connector use connector bracket come with the kit to fix at the side of the fuselage 3.
  • Page 14 Installation Turbine 6.put Turbine inside with mounting wood and mark hole and then take off mounting wood to drill hole and install turbine with mounting wood and put inside fuselage with M4 screw 8.. Best to keep all the wire away from heat ….
  • Page 15 Vector thrust Installation assembly servo mount by CA glue for VT...
  • Page 16 Vector thrust Installation 3. install servo arm and linkage 1.Install wire and connector bracket to back of fuselage 2. install servo mount by Epoxy for VT to back of fueslage...
  • Page 17 Fuel Bag installation 3.On the rear you just Tight 1. Fuel Bag come with wood and cable tile between carbon 2pcs carbon tube and cable tiles tube and wing tude But you MUST put wing tube before tight cable tile Otherwise sleeve tube will be squeezed and then glue the wood to hold the carbon...

  • Page 18: Electronic Installation

    Electronic installation 1. Electric landing gear / brake 2. Receiver / Power System control box placement. ,Receiver installation and placement 3. Battery placement. On top of the nose gear.
  • Page 19 Cheking CG 1. The Matrix jet comes with CG measuring tools ,very handy to check CG. 4mm bolt...
  • Page 20 Center of Gravity Turbine size:160-240N Measured back from leading edge of the wing for normal sport flying 335mm 250-320N for 3D vector flight Control Throw in all surface (Avoid high speed high G flying) for Sport flight Servos: Total x10(standard size) x2 for flaps (minimum 40kg) Aileron:44mm,Rudder:50mm, x1 for rudder (minimum 40kg)

  • Page 21: Flight Preperation

    Flight Preperation Make sure you have the right model programmed into your ■ transmitter Check the direction of each surface not and also right before ■ you take off . Remember nothing wrong on the ground ever improves in ■ the air Check the air plane with the engine running and do a range ■...
