SafeWaze 024-6075 Instruction Sheet

HARNESS INSTALLATION:
Confirm that you have both 'A' and 'B' Arc Flash Trauma Straps packs.
Packs A and B can attach on either hip. Install pack A on your dominant side.
A: Place pack A with the
letter facing right side
up on the torso webbing
loop that contains the leg
strap. Open the pack to
expose three Velcro flaps.
TRAUMA RELIEF - DEPLOYMENT AND USE:
1: Pull yellow tabs up to
release pack.
MAKING THE HOOK CONNECTION:
3A: Maintain a hold of red elastic rings.
Raise the ends of the straps to identify hook
and soft loop.
225 Wilshire Avenue SW, Concord NC • (800) 230-0319 • safewaze.com
220-00132
B: On the side with two C:
flaps, insert the inside opposite side over the
flap fully in the web loop. first flap and press to
secure.
2: Place thumbs through 3:
red elastic rings and of packs and maintain
begin to pull webbing out. hold of both ends of
webbing.
below to connect the
ends.
3B: Insert hook into soft loop slot at the end
of the webbing fully. DO NOT HOOK ON
THE RED ELASTIC RING.
Note: The product will not be exactly as pictured due to its arc flash features.
INSTRUCTION SHEET
Detailed video available at safewaze.com!
Fold the flap on the D: Fold the remaining flap
over the first two flaps,
pressing firmly together.
Repeat steps A-D with
pack B on the other
side of the harness.
Pull webbing fully out 4: Place feet into webbing
straps while maintaining
hold of the webbing
See 3A-3C handle.
024-6075
E: Inspect both packs.
Tug to confirm both packs
are securely attached.
WARNING
Logo and Trauma Relief
Label must face leg
buckles of harness.
5: Pull webbing handle to
tighten the webbing strap
to relieve pressure on the
legs.
3C: Tug lightly on webbing to confirm hook
is secure. Drop end without the hook ('B')
and maintain hold of the webbing handle
('A') near the end with the hook.
