- Page 1 Latitude Edge 8' Cable SRL-P Manual STANDARDS Class ANSI Z359.14-2021 Anchor above or OSHA 1910.66, 1910.140 below dorsal D-ring V2. 2023 Copyright Safewaze: 220-00103...
- Page 2 • The user must read, understand, and follow all safety and usage information contained within this manual. • The user must safely and effectively use the Latitude Edge and all equipment used in conjunction with the Latitude Edge. • Failure to follow all safety and usage information can result in serious injury or death.
- Page 3 Women who are pregnant and individuals considered minors must not use any Safewaze equipment. • Do not alter or misuse equipment. Only Safewaze, or entities authorized in writing by Safewaze, may make repairs to Safewaze fall protection equipment. •...
-
Page 4: Table Of Contents
► Product Specifications ► ► Fall Clearance ► ► Compatibility of Connectors ► ► 10.0 Making Connections ► ► 11.0 Installation/Operation of Latitude Edge ► ► 12.0 Inspection/Maintenance ► ► 13.0 Labels ► ► 14.0 Annual Inspection Form ► ►... -
Page 5: Introduction
This manual must be read and understood in its entirety and used as part of an employee training program as required by OSHA or any applicable state agency. The Latitude Edge SRL-P is intended for use as part of a complete Personal Fall Arrest, Restraint, Work Positioning, or Rescue System. Safewaze SRLs are designed for a single user whose weight (including clothing, tools, equipment, etc.) is:... -
Page 6: Intended Use
Safewaze. Use of this equipment in a manner outside the scope of those covered within this manual can result in serious injury or death. The equipment covered in this manual must only be used by trained personnel in workplace applications. -
Page 7: Worker Classifications
It is the responsibility of a Qualified Person or Engineer to supervise the jobsite and ensure safety regulations are met. V2. 2023 Copyright Safewaze: 220-00103... -
Page 8: Rescue Plan
SRL to engage and lock in the event of a fall. • Free Fall: The distance a user falls before the fall arrester activates. V2. 2023 Copyright Safewaze: 220-00103... -
Page 9: Product Specifications
• Use only the applicable D-ring for intended use. ► ► 7.0 PRODUCT SPECIFICATIONS • Latitude Edge SRL-Ps are Class 2 SRLs and can be anchored above, or below, the Dorsal D-Ring. • Minimum Breaking Strength: 3,600 lbs. (1632.9 kg) • Working Temperature: -40⁰F (-40⁰C) to 130⁰F (54⁰C) •... -
Page 10: Fall Clearance
• Actual Arrest Distance (AD): Safewaze SRLs are tested in accordance with ANSI Z359.14-2021 conditioning test protocols. Table 2 reflects the Class 1 Actual Arrest Distances of the Latitude Edge 8' Cable SRL-P when subjected to Ambient, Wet, Hot, and Cold testing. These Actual Arrest Distances are typically lower than the 42”... - Page 11 Class 1 and Class 2 are calculated using the worst actual arrest distance. Note: A Qualified Person must determine if MRFCs can be adjusted based upon actual jobsite atmospheric conditions or additional factors. V2. 2023 Copyright Safewaze: 220-00103...
- Page 12 This table is calculated based on the ANSI maximum 42'' arrest distance. *For the Below D-Ring (black) Class 2 chart: The Latitude Edge series is designed and tested for use below the Dorsal D-ring. The user must account for additional clearance requirements when the anchor point is located below the D-ring.
- Page 13 (3.8m) " (3.8m) 10'0" (4.2m) 12'0" (4.7m) 14'0" (5.1m) 16'0" (X.Xm) 18'0" 20'0" 22'0" Fall Clearance Table: Below D-Ring Use for Latitude Edge 8' LE Cable WARNING! .3m) (2.4m) (2.6m) (2.9m) (3.1m) (3.5m) (3.8m) (3.0m) (3.7m) (4.3m) (4.9m) (5.5m) (6.1m) (6.7m)
- Page 14 • Swing Fall Drop Distance: The additional clearance added from excess lifeline being paid out when working at a lateral offset from your anchorage. FIGURE 2: SWING FALL V2. 2023 Copyright Safewaze: 220-00103...
- Page 15 8'4" 9'8" 9'8" 11'1" 11'1" 12'6" 12'6" 14'1" 14'1" 3'6" 4'3" 5'1" 6'0" 6'12" 8'0" 9'1" X'X" WARNING! V2. 2023 Copyright Safewaze: 220-00103 (0.8m) (0.8m) (1.1m) (1.1m) (1.4m) (1.4m) (1.8m) (1.8m) (2.1m) (2.1m) (2.5m) (2.5m) (2.9m) (2.9m) (3.4m) (3.4m) (3.8m) (3.8m)
-
Page 16: Compatibility Of Connectors
Ensure all connectors are fully closed and locked. Safewaze connectors (hooks, carabiners, and D-rings) are designed to be used only as specified in each product’s manual. See Figure 4 for examples of inappropriate connections. -
Page 17: Installation/Operation Of Latitude Edge
When used properly, the lifeline of the SRL will extend and retract freely, with no slack or hesitation, as the user moves at normal speeds. In the event of a fall, Safewaze SRLs are equipped with a speed-sensing braking system. The braking system will activate, stop the fall, and absorb much of the energy created by the fall. - Page 18 Locking Button (B) Bar assembly of bracket that inserts behind BWB in open configuration. webbing at dorsal D-ring or SRL channel. Locking Button Red indicator (should not show when fully installed, see Step 4). Elastic Strap V2. 2023 Copyright Safewaze: 220-00103...
-
Page 19: Inspection/Maintenance
• A Competent Person must determine that the installation location to be utilized will support the intended loads. Frequency: • A Competent Person, other than the user, must inspect the Latitude Edge at least once annually. • While conducting inspections, the Competent Person must consider all applications and hazards that the equipment may have been subjected to while in use. - Page 20 Do not store system if wet or damp. Allow equipment to fully dry before being stored. • Storage: Prior to installation, store the Latitude Edge in a cool, dry area where it will not be exposed to extreme light, extreme heat, excessive moisture, or possibly corrosive chemicals or materials.
- Page 21 Cable RFID Equipped Handle RFID Equipped Handle Snap Hook Rebar Hook *Energy Absorber: LOAD INDICATOR FAIL PASS 20 11 5M 20 11 5M If rivets are detached from shock pack bracket immediately remove from service. V2. 2023 Copyright Safewaze: 220-00103...
-
Page 22: Labels
Updated Class 1 FC 4/2/24 470-00047 470-00046 If rivets are detached from MODEL #: 023-5350 shock pack bracket DESCRIPTION: Latitude Edge 8' Single Cable SRL: Snap immediately remove from Hook FRONT SERIAL #: XXXXXXX MFG DATE: XX/XXXX service. SPECIFICATIONS: Materials: Steel, SS steel & aluminum hardware, 225 Wilshire Ave SW nylon &... -
Page 23: Annual Inspection Form
ANNUAL INSPECTION FORM Inspection Inspector: Pass/Fail: Comments/ Date: Corrective Action: V2. 2023 Copyright Safewaze: 220-00103... - Page 24 Address: 225 Wilshire Ave SW, Concord, NC 28025 Phone: (800) 230-0319 Fax: 704-262-9051 Email: info@safewaze.com Website: safewaze.com...
