Summary of Contents for SafeWaze Latitude HD SRL-P
- Page 1 Latitude HD SRL-P Manual STANDARDS Class ANSI Z359.14-2021 Anchor at or above OSHA 1910.66, 1910.140 dorsal D-ring V4. 2023 Copyright Safewaze: 220-00081...
- Page 2 • The user must read, understand, and follow all safety and usage information contained within this manual. • The user must safely and effectively use the Latitude HD SRL-P and all equipment used in conjunction with the SRL. • Failure to follow all safety and usage information can result in serious injury or death.
- Page 3 Women who are pregnant and individuals considered minors must not use any Safewaze equipment. • Do not alter or misuse equipment. Only Safewaze, or entities authorized in writing by Safewaze, may make repairs to Safewaze fall protection equipment. •...
-
Page 4: Table Of Contents
Fall Clearance ► ► Compatibility of Connectors ► ► 10.0 Making Connections ► ► 11.0 Installation/Operation of Latitude HD ► ► 12.0 Inspection/ Maintenance ► ► 13.0 Labels ► ► 14.0 Annual Inspection Form ► ► V4. 2023 Copyright Safewaze: 220-00081... - Page 5 1X.05 Aluminum 021-5286 UHMPE webbing 1X.05 Aluminum 021-5287 UHMPE webbing 1X.05 Aluminum FS-2011N UHMPE webbing 1X.05 Aluminum FS-FSP1411-W UHMPE webbing 1X.05 Aluminum FS-FSP1411-W-RBH UHMPE webbing 1X.05 Aluminum FS-FSP1411-W-TBH UHMPE webbing 1X.05 Aluminum Copyright Safewaze 2022 V4. 2023 Copyright Safewaze: 220-00081...
-
Page 6: Introduction
OSHA or any applicable state agency. The Latitude HD SRL-P is intended for use as part of a complete Personal Fall Arrest, Restraint, Work Positioning, or Rescue System. Safewaze SRLs are designed to safely arrest the user in a fall event, while minimizing forces on the body. -
Page 7: Applicable Safety Standards
Dorsal D-ring. The user must account for additional clearance requirements when the anchor point is located below the D-ring. When anchored below the Dorsal D-ring, Latitude HD SRL-Ps are compliant with OSHA 1910.140 and OSHA 1910.66. V4. 2023 Copyright Safewaze: 220-00081... -
Page 8: Worker Classifications
Rescue Equipment and Rescue Plan. See ANSI Z359.4-2013 for specific rescue information. Immediately seek medical attention in the event a worker suffers a fall arrest incident. Note: Special rescue measures may be required for a fall over an edge. V4. 2023 Copyright Safewaze: 220-00081... -
Page 9: Product Limitations
Areas where the user’s lifeline may cross or tangle with the lifeline of another user should be avoided. Do not allow the lifeline to pass under arms or between the legs. V4. 2023 Copyright Safewaze: 220-00081... -
Page 10: Product Specifications
• Actual Arrest Distance (AD): Safewaze SRLs are tested in accordance with ANSI Z359.14-2021 conditioning test protocols. Table 2 reflects the Actual Arrest Distances of the Latitude HD SRL-P when subjected to Ambient, Wet, Hot, and Cold testing. These Actual Arrest Distances are typically lower than the 42” maximum as specified per ANSI. - Page 11 SRL. • Safety Factor: Additional fall clearance added to ensure a safe distance from any obstruction after a fall. Safewaze uses a 2 ft. Safety Factor. • Fall Clearance: The total combined values of Free Fall, Arrest Distance, Harness Stretch, Worker Height (working surface to dorsal D-ring), Swing Fall Drop Distance, and Safety Factor.
- Page 12 10' Cable 14" (36 cm) 4' 8" (1.4 m) 11' Web 26" (66 cm) 5' 8" (1.7 m) 11' Web (Tie-Back) See Page 16 See Page 16 11' Cable 33" (84 cm) 6' 3" (1.9 m) V4. 2023 Copyright Safewaze: 220-00081...
- Page 13 3' 0" (0.9 m) 19" (48 cm) 8' 1" (2.5 m) 11' Web (Tie-Back) See Page 16 See Page 16 See Page 16 11' Cable 3' 0" (0.9 m) 15" (38 cm) 7' 9" (2.4 m) V4. 2023 Copyright Safewaze: 220-00081...
- Page 14 FALL CLEARANCE CHARTS *For the Overhead Use (white) Class 1 chart: Safewaze Latitude HD SRL-Ps meet all ANSI 130-310 lbs. (59-141 kg) and OSHA up to 420 lbs. (191 kg) requirements for a Clearance Values come from combined values Class 1 SRL when anchored overhead.
- Page 15 25'5" X'X" Axis: Lateral Offset From Anchorage 24'6" 26'5" 28'4" DEATH Use Caution (6.8m) (7.2m) (7.7m) (X.Xm) (7.5m) (8.0m) (8.6m) V4. 2023 Copyright Safewaze: 220-00081 24'6" 26'5" 28'4" X'X" 28'6" 30'6" 32'6" WARNING! (7.5m) (8.0m) (8.6m) (8.7m) (9.3m) (9.9m) (X.Xm) 28'6"...
- Page 16 Use Caution (6.8m) (7.2m) (7.7m) (X.Xm) (7.5m) (8.0m) (8.6m) 24'6" 26'5" 28'4" Fall Clearance with Latitude HD Tie-Back SRL-Ps: Safewaze Latitude HD Tie-Back X'X" 28'6" 30'6" 32'6" WARNING! (7.5m) (8.0m) (8.6m) (8.7m) (9.3m) SRLs can be connected to an anchor point from 11” to 21” in diameter. Depending on (9.9m)
- Page 17 (1.7m) (1.7m) (2.1m) (2.1m) (2.6m) (2.6m) (3.0m) (3.0m) (3.5m) (3.5m) (4.1m) (4.1m) (4.6m) (4.6m) (5.1m) (5.1m) (5.7m) (5.7m) V4. 2023 Copyright Safewaze: 220-00081 1.3m) (1.6m) (1.9m) (2.3m) (2.6m) (3.0m) (3.4m) 5'7" 5'7" 7'2" 7'2" 8'10" 8'10" 10'7" 10'7" 12'4" 12'4"...
-
Page 18: Compatibility Of Connectors
13'4" 15'0" 15'0" 16'9" 16'9" 18'6" 18'6" 4'4" 5'4" 6'4" 7'5" 8'7" 9'10" 11'1" DEATH • Safewaze equipment is designed for, and tested with, associated Safewaze (1.3m) (1.7m) (2.1m) (2.6m) (3.0m) (3.5m) (4.1m) (4.6m) (5.1m) (5.7m) (1.3m) (1.7m) (2.1m) (2.6m) (3.0m) -
Page 19: Making Connections
Ensure all connectors are fully closed and locked. Safewaze connectors (hooks, carabiners, and D-rings) are designed to be used only as specified in each product’s manual. See Figure 3 for examples of inappropriate connections. - Page 20 When used properly, the lifeline of the SRL will extend and retract freely, with no slack or hesitation, as the user moves at normal speeds. In the event of a fall, Safewaze SRLs are equipped with a speed-sensing braking system. The braking system will activate, stop the fall, and absorb much of the energy created by the fall.
- Page 21 (Steps 2 and 3). 3. With the bracket open, install dual leg retractables onto the bracket via the swivel tops of each. Swivels should be hanging on the curved portion of bracket. V4. 2023 Copyright Safewaze: 220-00081...
- Page 22 (Step 3). 3. With the bracket open, install dual leg retractables onto the bracket via the swivel tops of each. Swivels should be hanging on the curved portion of bracket. V4. 2023 Copyright Safewaze: 220-00081...
-
Page 23: Inspection/ Maintenance
Frequency: • A Competent Person, other than the user, must inspect the Latitude HD SRL-P at least once annually. While conducting inspections, the Competent Person must consider all applications and hazards that the equipment may have been subjected to while in use. - Page 24 • Prior to each use, the user must inspect and verify that each individual component (Images 5, 6, 7, and 8) of the Latitude HD SRL-P is safe for use: 1. The cable/web from the unit should pay out and retract smoothly.
- Page 25 Behind the Web Bracket Swivel Top Swivel Top Housing Housing Label Label Cable Lifeline Cable Lifeline Swivel Load Indicating Snap Energy Absorber*/Labeling Hook* Snap Hook *Swivel Load Indicating *Energy Absorber Snap Hook: (Fall Indicator): 470-00041 31 mm V4. 2023 Copyright Safewaze: 220-00081...
- Page 26 1910.66, OSHA 1926.502 OSHA 1910.66, OSHA 1926.502 If stitch pattern at the base of the housing is torn open, *Important: The Latitude HD 9' Web SRL-P series is not for tie-back use. immediately remove from service V4. 2023 Copyright Safewaze: 220-00081...
-
Page 27: Labels
OSHA, up to 420 lbs. (190.51 kg) *Including clothing, tools & equipment DO NOT ATTEMPT TO SERVICE OR REPAIR THIS UNIT! CONTACT SAFEWAZE Average arrest force: 1350 lbs. (612.35 kg) FOR SERVICE OR REPAIR INFORMATION. Device must be inspected prior to Max arrest force: 1800 lbs. -
Page 28: Annual Inspection Form
INSPECTION LOG ANNUAL FORM Inspection Inspector: Pass/Fail: Comments/ Date: Corrective Action: Address: 225 Wilshire Ave SW, Concord, NC 28025 Phone: (800) 230-0319 Fax: 704-262-9051 Email: info@safewaze.com Website: safewaze.com V4. 2023 Copyright Safewaze: 220-00081...
