Before you begin using the device, please check the version you got and ensure that

the following items are included in the shipped box:

X933H x 1

M4x30 Screw x 2

Allen Wrench x 1

Diode x 2

MIC

Bracket Locator

Wall Bracket x 1

Plastic Wall Anchor x 3

11 Pin Cable x 1

Loudspeaker

Front View

Bottom View

Back View

X933H

M3 Set Screw x 1

ST4x20 screw x 3

10 Pin Cable x 1

MIC

HD IPS Touch Screen

Atmosphere Light

Temper-Proof Screw

11 Pin Port

10 Pin Port

Network Interface(POE)
