SAFETY INSTRUCTIONS
These instructions are valid if the country symbol
appears on the appliance. If the symbol doesn't appear
on the appliance, it is necessary to refer to the technical
instructions which will provide the necessary instructions
concerning modi cation of the appliance to the
conditions of use of the country.
CAUTION: The use of the gas cooking appliance
results in the production of heat, moisture and
products of combustion in the room in which it is
installed. Ensure that the kitchen is well ventilated
especially when the appliance is in use: keep natural
ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
Prolonged intensive use of the appliance may call for
additional ventilation, such as opening a window, or
more e ective ventilation, for example increasing the
level of mechanical ventilation (if possible).
Failure to follow the information in this manual
exactly may cause a re or explosion, resulting in
property damage or personal injury.
Before using the appliance, read these safety
instructions. Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times.
The manufacturer declines any liability for failure to
observe these safety instructions, for inappropriate
use of the appliance or incorrect setting of controls.
WARNING: If the hob surface is cracked, don't use
the appliance – risk of electrical shock.
WARNING: Danger of re: Do not store items on the
cooking surfaces.
CAUTION: The cooking process has to be supervised. A
short cooking process has to be supervised continuously.
WARNING: Unattended cooking on a hob with fat or
oil can be dangerous – risk of re. NEVER try to extinguish
a re with water, but switch o the appliance and then
cover ame e.g. with a lid or a re blanket.
Do not use the hob as a work surface or support.
Keep clothes or other ammable materials away from
the appliance, until all the components have cooled
down completely – risk of re.
Very young children (0-3 years) should be kept away
from the appliance. Young children (3-8 years) should
be kept away from the appliance unless continuously
supervised. Children from 8 years old and above and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can
use this appliance only if they are supervised or have
been given instructions on safe use and understand the
hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not be
carried out by children without supervision.
CAUTION: In case of hotplate glass breakage: shut
immediately o all burners and any electrical heating
element and isolate the appliance from the power
IMPORTANT TO BE READ AND OBSERVED
supply; do not touch the appliance surface; do not use
the appliance.
The glass lid can break in if it is heated up. Turn o all
the burners and the electric plates before closing the
lid. Do not shout down lid when burner alight.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age must be kept away unless continuously supervised.
The food must not be left in or on the product for
more than one hour before or after cooking.
PERMITTED USE
CAUTION: the appliance is not intended to be
operated by means of an external switching device,
such as a timer, or separate remote controlled system.
This appliance is intended to be used in household
and similar applications such as: sta kitchen areas in
shops, o ces and other working environments; farm
houses; by clients in hotels, motels, bed & breakfast
and other residential environments.
No other use is permitted (e.g. heating rooms).
This appliance is not for professional use. Do not
use the appliance outdoors.
Use pots and pans with bottoms the same width as
that of the burners or slightly larger (see speci c table).
Make sure pots on the grates do not protrude beyond
the edge of the hob.
Improper use of the grids can result in damage to
the hob: do not position the grids upside down or slide
them across the hob.
Do not let the burner ame extend beyond the edge of the pan.
If the hob surface is in glass material, do not use the cast iron griddles, ollar
stones, terracotta pots and pans.
Do not use: heat di users such as metal mesh, or any other types; two burners
simultaneously for one receptacle (e.g. Fish kettle).
Should particular local conditions of the delivered gas make the ignition of
burner di cult, it is advisable to repeat the operation with the knob turned to
small ame setting.
In case of installation of a hood above the cooktop, please refer to the hood
instructions for the correct distance.
The protective rubber feet on the grids represent a choking hazard for young
children. After removing the grids, please ensure that all the feet are correctly fitted.
INSTALLATION
The appliance must be handled and installed by
two or more persons - risk of injury. Use protective
gloves to unpack and install - risk of cuts.
The electrical and gas connections must comply
with local regulation.
Installation, including water supply (if any) and
electrical connections, and repairs must be carried out by
a quali ed technician. Do not repair or replace any part of
the appliance unless speci cally stated in the user manual.
Keep children away from the installation site. After
unpacking the appliance, make sure that it has not been
damaged during transport. In the event of problems,
contact the dealer or your nearest After-sales Service.
Once installed, packaging waste (plastic, styrofoam parts
etc.) must be stored out of reach of children - risk of
su ocation. The appliance must be disconnected from
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAN642IX/H and is the answer not in the manual?

Questions and answers

Summary of Contents for Hotpoint PAN642IX/H

  • Page 1 SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED supply; do not touch the appliance surface; do not use These instructions are valid if the country symbol the appliance. appears on the appliance. If the symbol doesn’t appear The glass lid can break in if it is heated up. Turn o all on the appliance, it is necessary to refer to the technical the burners and the electric plates before closing the instructions which will provide the necessary instructions...
  • Page 2: Gas Connection

    the power supply before any installation operation - risk If the appliances is connected to liquid gas, the of electrical shock. During installation, make sure the regulation screw must be fasted as tightly as possible. appliance does not damage the power cable - risk of re IMPORTANT: When the gas cylinder or gas container is or electrical shock.
  • Page 3: Disposal Of Packaging Materials

    The power cable must be long enough to connect the appliance, once tted in its housing, to the main power supply. Do not pull the power supply cable. Do not use extension leads, multiple sockets or adapters. The electrical components must not be accessible to the user after installation.
  • Page 4 GB IE CATEGORY II2H3+ BURNER AND NOZZLE SPECIFICATIONS Type of gas used Type of burner Injector marking Rated thermal Rated Reduced heat Gas pressure ow rate consumption capacity mbar min. rat. max. Rapid (R) 115 Y 3,00 286 l/h 0,75 NATURAL GAS Semi-rapid (SR) 95 Z...
  • Page 5 INSTALLATION CLASS 3 TECHNICAL INFORMATION FOR THE INSTALLER • Use protective gloves for handling, preparing and installing the product. • This product can be embedded in a worktop 20 ÷ 60 mm thick. • If there is no oven beneath the hob, insert a separator panel that has a surface at least equal to the opening in the work surface. This panel must be positioned at a maximum distance of 150 mm below the upper surface of the work surface but, in no case less than 20 mm from the bottom of the hob.
  • Page 6: Product Description

    THANK YOU FOR BUYING A HOTPOINT PRODUCT In order to receive a more complete assistance, please PLEASE SCAN THE QR CODE ON register your product on www.register10.eu. YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION Before using the appliance carefully read the Safety Instruction.
  • Page 7: Cleaning And Maintenance

    REPLACING THE INJECTORS see the injector table in the Safety instructions ADJUSTING MINIMUM GAS SETTING OF TAPS This operation must be performed by a quali ed technician. This operation must be performed by a quali ed technician. • Remove grids (A). The adjustment must be performed with the tap in a minimum gas setting •...
  • Page 8: After Sales Service

    AFTER SALES SERVICE BEFORE CALLING THE AFTER SALES SERVICE: • the serial number (number after the word SN on the rating plate located under the appliance). The serial number is also indicated in the See if you can solve the problem by yourself with the help of the documentation;...
