SAFETY INSTRUCTIONS
These instructions are valid if the country symbol
appears on the appliance. If the symbol doesn't appear
on the appliance, it is necessary to refer to the technical
instructions which will provide the necessary
instructions concerning modi cation of the appliance
to the conditions of use of the country.
CAUTION: The use of the gas cooking appliance
results in the production of heat, moisture and
products of combustion in the room in which it is
installed. Ensure that the kitchen is well ventilated
especially when the appliance is in use: keep natural
ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
Prolonged intensive use of the appliance may call for
additional ventilation, such as opening a window, or
more e ective ventilation, for example increasing the
level of mechanical ventilation (if possible).
Failure to follow the information in this manual
exactly may cause a re or explosion, resulting in
property damage or personal injury.
Before using the appliance, read these safety
instructions. Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times.
The manufacturer declines any liability for failure to
observe these safety instructions, for inappropriate
use of the appliance or incorrect setting of controls.
WARNING: If the hob surface is cracked, don't use
the appliance – risk of electrical shock.
WARNING: Danger of re: Do not store items on the
cooking surfaces.
CAUTION: The cooking process has to be supervised. A
short cooking process has to be supervised continuously.
WARNING: Unattended cooking on a hob with fat
or oil can be dangerous – risk of re. NEVER try to
extinguish a re with water, but switch o
appliance and then cover ame e.g. with a lid or a re
blanket.
Do not use the hob as a work surface or support.
Keep clothes or other ammable materials away from
the appliance, until all the components have cooled
down completely – risk of re.
Very young children (0-3 years) should be kept away
from the appliance. Young children (3-8 years) should
be kept away from the appliance unless continuously
supervised. Children from 8 years old and above and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can
use this appliance only if they are supervised or have
been given instructions on safe use and understand the
hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not be
carried out by children without supervision.
CAUTION: In case of hotplate glass breakage: shut
immediately o all burners and any electrical heating
IMPORTANT TO BE READ AND OBSERVED
element and isolate the appliance from the power
supply; do not touch the appliance surface; do not use
the appliance.
The glass lid can break in if it is heated up. Turn o all
the burners and the electric plates before closing the
lid. Do not shout down lid when burner alight.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age must be kept away unless continuously supervised.
The food must not be left in or on the product for
more than one hour before or after cooking.
PERMITTED USE
CAUTION: the appliance is not intended to be
operated by means of an external switching device,
such as a timer, or separate remote controlled system.
This appliance is intended to be used in household
and similar applications such as: sta kitchen areas in
shops, o ces and other working environments; farm
houses; by clients in hotels, motels, bed & breakfast
and other residential environments.
No other use is permitted (e.g. heating rooms).
This appliance is not for professional use. Do not
use the appliance outdoors.
Use pots and pans with bottoms the same width as
that of the burners or slightly larger (see speci c table).
Make sure pots on the grates do not protrude beyond
the edge of the hob.
Improper use of the grids can result in damage to
the hob: do not position the grids upside down or slide
them across the hob.
Do not let the burner ame extend beyond the edge of the pan.
If the hob surface is in glass material, do not use the cast iron griddles, ollar
stones, terracotta pots and pans.
Do not use: heat di users such as metal mesh, or any other types; two burners
simultaneously for one receptacle (e.g. Fish kettle).
Should particular local conditions of the delivered gas make the ignition of
the
burner di cult, it is advisable to repeat the operation with the knob turned to
small ame setting.
In case of installation of a hood above the cooktop, please refer to the hood
instructions for the correct distance.
The protective rubber feet on the grids represent a choking hazard for young
children. After removing the grids, please ensure that all the feet are correctly fitted.
INSTALLATION
The appliance must be handled and installed by
two or more persons - risk of injury. Use protective
gloves to unpack and install - risk of cuts.
The electrical and gas connections must comply
with local regulation.
Installation, including water supply (if any) and
electrical connections, and repairs must be carried out by
a quali ed technician. Do not repair or replace any part of
the appliance unless speci cally stated in the user manual.
Keep children away from the installation site. After
unpacking the appliance, make sure that it has not been
damaged during transport. In the event of problems,
contact the dealer or your nearest After-sales Service.
Once installed, packaging waste (plastic, styrofoam parts
etc.) must be stored out of reach of children - risk of
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPH60PFIXUK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hotpoint PPH60PFIXUK

  • Page 1 SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED element and isolate the appliance from the power These instructions are valid if the country symbol supply; do not touch the appliance surface; do not use appears on the appliance. If the symbol doesn’t appear the appliance.
  • Page 2: Gas Connection

    su ocation. The appliance must be disconnected from installation regulations. Particular attention must be the power supply before any installation operation - risk paid to the relevant requirements regarding ventilation. of electrical shock. During installation, make sure the If the appliances is connected to liquid gas, the appliance does not damage the power cable - risk of re regulation screw must be fasted as tightly as possible.
  • Page 3: Disposal Of Packaging Materials

    the appliance must be earthed in conformity with national electrical safety standards. The power cable must be long enough to connect the appliance, once tted in its housing, to the main power supply. Do not pull the power supply cable. Do not use extension leads, multiple sockets or adapters.
  • Page 4: Burner And Nozzle Specifications

    GB IE CATEGORY II2H3+ BURNER AND NOZZLE SPECIFICATIONS Type of gas used Type of burner Injector marking Rated thermal Rated Reduced heat Gas pressure ow rate consumption capacity mbar min. rat. max. Rapid (R) 115 Y 3,00 286 l/h 0,70 NATURAL GAS Semi-rapid (SR) 95 Z...
  • Page 5: Electrical Connection

    INSTALLATION CLASS 3 TECHNICAL INFORMATION FOR THE INSTALLER • Use protective gloves for handling, preparing, and installing the product. • This product can be embedded in a worktop 20 ÷ 60 mm thick. • If there is no oven beneath the hob, insert a separator panel with a surface at least equal to the work surface’s opening This panel must be positioned at a maximum distance of 150 mm below the upper surface of the work surface but, in no case less than 20 mm from the bottom of the hob.
  • Page 6: Product Description

    THANK YOU FOR BUYING A HOTPOINT PRODUCT In order to receive a more complete assistance, please PLEASE SCAN THE QR CODE ON register your product on www.hotpoint.eu/register. YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION Before using the appliance carefully read the Safety Instruction.
  • Page 7: Cooking Table

    REPLACING THE INJECTORS see the injector table in the Safety instructions ADJUSTING MINIMUM GAS SETTING OF TAPS This operation must be performed by a quali ed technician. This operation must be performed by a quali ed technician. • Remove grids (A). The adjustment must be performed with the tap in a minimum gas setting •...
  • Page 8: Troubleshooting

    XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX Policies, standard documentation and additional product information can be found by: • Using QR code in your appliance; • Visiting our website docs.hotpoint.eu; • Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales Service, please state the codes provided on your product's identi cation plate.
