mr. steam MS90E Installation, Operation And Maintenance Manual
Steambath generator systems
Hide thumbs
Also See for MS90E:
- Installation, operation & maintenance manual (32 pages) ,
- Installation, operation and maintenance manual (28 pages) ,
- Instructions (2 pages)
Subscribe to Our Youtube Channel
Related Manuals for mr. steam MS90E
Summary of Contents for mr. steam MS90E
- Page 1 Installation, Operation and Maintenance Manual Steambath Generator Systems Residential Models: MS90E – MS400E and MSSUPER1E – 6E steam ® Feel Good Inc. ™...
-
Page 2: Important Safety Instructions
When installing and using this electrical equipment, basic safety precautions should R E A D M E F I R S T ! always be followed, including the following: WARNING As you follow these IMPORTANT SAFETY INSTRUCTIONS instructions, you will notice warning and READ AND FOLLOW ALL INSTRUCTIONS caution symbols. -
Page 3: Table Of Contents
RESIDENTIAL STEAMBATH GENERATOR SYSTEMS MODEL _______________________________ & INSTALLATION OPERATION MAINTENANCE MANUAL MODELS: MS-90E, MS-150E, MS-225E, MS-400E, MS-SUPER 1E, SERIAL NO. ___________________________ MS-SUPER 2E, MS-SUPER 3E, MS-SUPER 4E, MS-SUPER 5E, MS-SUPER 6E TABLE OF CONTENTS Important Safety Instructions ... . . Inside front cover Select Your Mr.Steam Model . -
Page 4: Select Your Mr.steam Model
‡Wire size (AWG) based on minimum 90˚C rated THHN copper conductors. Refer to the National Electrical Code for other types of conductors. See Mr. Steam® Installation and Operation Manual for complete dimensional and installation information. MS SUPER 4E includes two MS SUPER 1E steam generators, and require one iTempo/Plus Control, and two matching steamheads. -
Page 5: Before Installing
Installation consultations with an architect, designer and contractor in determin- or service by unqualified persons or failure to use Mr. Steam parts ing factors necessary in providing a suitable and safe steam room. -
Page 6: Water Quality Information
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ WATER QUALITY INFORMATION or optimum results, the water supply should be tested prior RECOMMENDED FEEDWATER QUALITY to installation. If the mineral content exceeds the following Hardness, ppm 8 – 85 (~0.5 – 5 gpg) recommended limits, various external treatment processes P-Alkalinity, ppm 85 –... -
Page 7: Typical Installation Instructions
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ TYPICAL MR.STEAM INSTALLATION CAUTION The control features an integral NOTE: Drawings for illustrative purposes only. iSteam ® , iTempo ™ temperature sensor. Locate the control in a location Consult with qualified designer, architect or or iTempo/Plus ™... -
Page 8: Installation
D R I P PA N Mr. Steam strongly recommends the use of a drip pan in the unlikely event of a plumbing leak. Check local plumbing codes for receptor, trap and vent requirements. Drip pans drain by gravity. The drip pan is equipped with an integral 3 / 4 "... - Page 9 mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ INSTALLING THE ROUND OR SQUARE 1/8" minimum clearance required ( 1 ⁄2" NPT) AROMASTEAM STEAMHEAD when Acrylic Shield is used. See installation instructions provided Use Teflon ® with the Acrylic Shield. equal sealant on NOTE: A 1 ⁄...
- Page 10 mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ GENERATOR DIAGRAM Water Inlet Control & Accessory Connections Steam Outlet Safety Valve Optional AutoFlush Manual Drain Valve 12” ” for servicing IMPORTANT NOTES: Provide a minimum of (12) inches at both ends and top of the steam generator or as required for servicing.
-
Page 11: Field Power Wiring
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ E L E C T R I C A L C H A R T ________________________________________________________________________________________________________ ELECTRICAL Max Room Wire Size Wire Size † Model No. (Cu. Ft.*) Volts Phase Amps (AWG)for 40˚... -
Page 12: Wiring Diagrams
. steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ SINGLE PHASE 208/240 VOLT WIRING DIAGRAMS POWER INPUT L E G E N D TRANSFORMER (All Diagrams) FIELD MODELS MS90E, MS150E, WIRING FACTORY MS225E, MS400E WIRING WATER FEED SOLENOID GROUND VALVE... -
Page 13: Optional Tandem Cable Diagram
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ INSTALLATION INSTRUCTIONS FOR MODELS: MS-SUPER 4E, MS-SUPER 5E AND MS-SUPER 6E 1. Install each unit as in a single installation. Install the two generators as close to each other as possible. Shock Hazard. -
Page 14: Initial Start-Up & Checkout
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ INITIAL START-UP AND CHECKOUT 1. Turn on control. Follow specific instructions provided with controls. 2. Steam will begin to appear in approximately 5 minutes (unless equipped with factory-installed Express Steam option) at the steam head. Steam will shut off when desired temperature is reached and will automatically resume when room temperature drops below set point. -
Page 15: System Status Codes
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ SYSTEM STATUS CODES The control (either iSteam ® , iTempo or iTempo/Plus ) may display a status code if the steam generator is not functioning properly. ™ ™ Code Code Meaning Probable Cause Suggested Remedy Water level is not... -
Page 16: Operation
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ ® OPTIONAL AUTOFLUSH Steam Generator Box Contents 3 Pin Connector for AutoFlush AutoFlush Valve with Cord Installation Instructions. OPERATION The optional AutoFlush System feature automatically drains the Mr.Steam generator following each use. A time delay allows the water to cool down (about two hours) before it drains by gravity for a safe and gentle operation. -
Page 17: Optional Drip Pan
Installation, Operation & Maintenance Manual __________________________________________________________________________ OPTIONAL DRIP PAN Mr. Steam strongly recommends the use of a drip pan in the unlikely event of a plumbing leak. Locate the drip pan on a solid level surface and place the steam generator inside the drip pan. -
Page 18: Parts Identification Diagrams
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ PARTS IDENTIFICATION DIAGRAMS Contactor Liquid Level Control Board MS REGULAR MODELS Transformer Water Feed Liquid Level Probe Solenoid MS65E - MS400E Power Supply (with AutoFlush ™ Knock-Out shown with cover removed Water Inlet Plug and Play Connection... -
Page 19: Replacement Parts List
mr . steam ® Installation, Operation & Maintenance Manual __________________________________________________________________________ REPLACEMENT PARTS LIST __________________________________________________________________________________________ Part No. Description Generator ___________________________________________________________________________________________ 99178MS Drain Valve All Models 99297 Safety Valve 15PSI All Models 100479 Water Feed Solenoid Valve w/filter All Models 10477-3 Transformer 24VAC All Models 103975 Liquid Level Control Board... -
Page 20: Control Installation
CAUTION To avoid unintentional steambath operation, DO NOT alter or modify any Mr. Steam product. Doing so may DO NOT locate the control where other controls, acces- result in an inoperative or hazardous installation and will void sories, shower heads, valves, body sprays or similar within the UL listing and warranty. -
Page 21: Homeowner Section
Unconsciousness. provided on the label using permanent ink. The use of alcohol, WARNING Not Actual Size For a replacement warning drugs, or medication can greatly increase label contact Mr. Steam the risk of hyperthermia. customer service at 1-800-76-STEAM or hello@mrsteam.com... -
Page 22: Safety And Operating Information
To prevent slip and fall hazards non-skip strips must be installed on the steam room floor. WARNING DO NOT alter or modify any Mr. Steam product. Doing so may result in an inoperative or hazardous installation and will void the UL listing and warranty. -
Page 23: Warranty
Tightly close bottles when storing oils. Keep bottles away from sources of ignition. All drawings are for illustrative purposes only WARRANTY To view or download the Mr. Steam Residential Generator Warranty blog.mrsteam.com/wr and register your Product go to:... - Page 24 steam ® Feel Good Inc. ™ www.mrsteam.com Products, information and specifications are subject to change without notice. Please call Sales & Support at 1.800.76.STEAM (East Coast) or 1.800.72.STEAM (West Coast) for more information. steam ® Sussman-Automatic Corporation I hello@mrsteam.com I www.mrsteam.com ®...
- Page 25 Installation, Operation & Maintenance Manual ™ ™ i T E M P O & i T E M P O P L U S C O N T R O L S steam ® Feel Good Inc. www.mrsteam.com...
-
Page 26: Important Safety Instructions
When installing and using this electrical equipment, basic safety precau- HypertHermia occurs when the tions should always be followed, including the following: internal temperature of the body IMPORTANT SAFETY INSTRUCTIONS reaches a level several degrees above the normal body temperature of 98.6° 1. - Page 27 steam ® Installation & Operating Instructions ______________________________________________________________ table of Contents: r e a D m e F i r S t ! Important Safety Instructions ......2 WarNiNG As you follow these instruc- tions, you will notice warning and caution Before Installing ..........
-
Page 28: Before Installing
Mr.Steam control’s intended use and function. Do not alter or modify any Mr. Steam ® WarNiNG product. Doing so may result in an inoperative or haz- Do not use any iTempoPlus... -
Page 29: Dimensional Information
steam ® Installation & Operating Instructions ______________________________________________________________ Dimensional information for the round and Square itempo and itempoplus ™ ™ 1” ” BOx CONteNtS: ” • iTempo ™ or iTempoPlus ™ Control • Control Cable (30 ft.) 2 ” • Steam head 5”... - Page 30 steam ® Installation & Operating Instructions ______________________________________________________________ installation instructions for round & 5 ⁄8” Square itempo and itempoplus ™ ™ Step 1 Determine the desired installation location of the control. The iTempo ™ and iTempoPlus ™ controls are designed to be installed inside or outside the steam room as a matter of personal preference.
- Page 31 steam ® Installation & Operating Instructions ______________________________________________________________ NOte: The connector is keyed with the flat facing up. The control cable is the same at both ends. impOrtaNt NOte: Be careful not to strain, staple, pinch or otherwise damage the control cable. Route cable as required to permit replacement.
- Page 32 Use silicone as required to create a moisture seal. NOte: The silicone supplied by Mr. Steam can be used to meet a variety of sealing and gasketing. It cures to silicone rubber and...
-
Page 33: Installing The Remote Temperature Probe
Probe (P/N MSTS) is for use with iTempo Clean area thoroughly. and iTempoPlus Controls only. Do not use NOte: The silicone supplied by Mr. Steam can with any other controls. Do not use any other temperature probe with the iTempo and be used to meet a variety of sealing and iTempoPlus controls. - Page 34 steam ® Installation & Operating Instructions ______________________________________________________________ Temperature DiaGram 1 Probe Connection Knock-Out Temperature Probe Cable Temperature (30 feet) Sensor Probe Mr.Steam Steam Generator (shown with cover removed and NOT installed) Drawings for Illustrative Purposes Only.
- Page 35 steam ® Installation & Operating Instructions ______________________________________________________________ s t e a m r o o m i n t e r i o r 5. Route the end of the probe cable with the temperature probe through the wall into the DiaGram 2 steam room as shown in Diagram 2.
-
Page 36: Itempo Operating Instructions
steam ® Installation & Operating Instructions ______________________________________________________________ itempo Operating instructions ™ The iTempo Control features programmable digi- tal temperature control, a fixed (60) minute dura- tion, ON/OFF and PAUSE. The control can be set at a temperature range from 80˚ up to 120˚... - Page 37 steam ® Installation & Operating Instructions ______________________________________________________________ timer FeatUre When the control is turned ON a 60 minute time duration is initiated. The control will turn off after 60 minutes unless the control is turned off manually. memOry FeatUre If the control is turned off manually before 60 minutes then the default temperature of 110˚F will be used the next time the control is turned on.
-
Page 38: Itempoplus Operating Instructions
steam ® Installation & Operating Instructions ______________________________________________________________ itempoplus Operating instructions ™ The iTempoPlus Control features programmable temperature control, programmable time duration, clock, AromaSteam, ChromaSteam , ON/OFF and ® mr.steam two personal settings. Set the steam bathing temperature ac- WarNiNG temp time cording to personal preference, however it is highly recommended to begin steam bathing at a low tem-... - Page 39 steam ® Installation & Operating Instructions ______________________________________________________________ SettiNG tHe CLOCk Diagram 3 When the display is not flashing: Press and hold the mr.steam TIME key until the display starts flashing. Use the UP/DOWN keys to select the desired time, temp DiaGram 3 at this time the AM/PM logo will be displayed.
- Page 40 steam ® Installation & Operating Instructions ______________________________________________________________ SettiNG tHe temperatUre Diagram 6: Press TEMP key to set the desired temperature or display the temperature setting. mr.steam Diagram 7: The control is preset and will display a tempera- ture setting of 110˚F (default setting). With the temperature DiaGram 6 time displayed, press the UP or DOWN keys to set the desired tem-...
- Page 41 steam ® Installation & Operating Instructions ______________________________________________________________ CHaNGiNG tHe temperatUre UNitS (˚F/˚C) When the generator is Off, Press and hold ON/OFF aroma key for 10 seconds. The temperature units will be displayed as Fahrenheit (TuF) or Celsius (TuC). Use mr.steam the UP/DOWN keys to choose between (TuF) and (TuC).
-
Page 42: Warranty
steam ® Installation & Operating Instructions ______________________________________________________________ Display mr.steam Up Key Time Display/ Time Display/ temp time Adjust Key Adjust Key Down Key ON/OFF Key Program Key aroma chroma AromaSteam ChromaSteam Care tips for all Controls and Steamheads 1. Use only mild soap and water on a soft cloth to clean the control and steamhead. 2. -
Page 43: Template For Control Installation
steam ® Installation & Operating Instructions ______________________________________________________________ template for control installation see pg 5 ⁄8” 7 ⁄8”... - Page 44 steam ® Feel Good Inc. Products, information and specifications are subject to change without notice. For more information call Sales & Support at: 1.800.76.STEAM 1.800.72.STEAM (East Coast) (West Coast) 2014 © Sussman-Automatic Corporation Mr.Steam and des., AromaFlo, AutoFlush, AutoSteam, Butler Package, ChromaSteam, Clean Steam...Every Time, Club Therapy, Digital 1, Express Steam, From Bathroom to Spa, iDream Package, iGenie, iSizing, iSteam, iSteam/Plus, MusicTherapy, Spa Package, Steam@Home, Steam Therapy, Sussman, Valet Package, Virtual Spa System, Voice Genie and Voice Wizard are registered trademarks of Sussman-Automatic Corporation.
- Page 45 mr . steam ® Optional Autoflush System ____________________________________________________________________________________________________________________________________________ INSTA LLAT ION INS TRUCTI ONS BOX CONTENTS: • AutoFlush System Valve with Cord • Installation Instructions. ASSEMBLY OF OPTIONAL AUTOFLUSH SYSTEM 3 Pin Connector for AutoFlush AutoFlush Cord Connector AutoFlush Cord AutoFlush Valve Steam Generator End "B"...
- Page 46 AutoFlush to the white wire from the circuit board using a wire nut. Repeat for the black wire. WARRANTY: To view or download the Mr. Steam IMPORTANT NOTE: Contact the Mr.Steam Technical Service Department for installation of any equipment not Controls &...
