7.6. Expansion I/O Connector (P1)
The 96-pin Expansion I/O connector P1 provides access to all signal pins of the C8051F996 device (except the C2
debug interface signals). In addition, power supply and ground pins are included. A small through-hole prototyping
area is also provided. See Table 3 for a list of pin descriptions for P1.
Row A
Pin #
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Downloaded from Elcodis.com electronic components distributor
Table 3. P1 Pin Descriptions
Description
1 +3 VD
2 nc
3 nc
4 nc
5 nc
6 nc
7 nc
8 nc
9 nc
nc
P0.5/RX
P0.2H
P2.7H
P1.4
P1.1/CP0-
nc
nc
nc
nc
nc
nc
nc
nc
nc
nc
GND
nc
nc
nc
nc
nc
nc
Row B
Description
Pin #
1 GND
2 nc
3 nc
4 nc
5 nc
6 nc
7 nc
8 nc
9 nc
10
P0.7/IREF0
11
P0.4/TX
12
P0.1/AGND
13 P1.6H
14 P1.3
15 P1.0/CP0+
16 nc
17 nc
18 nc
19 nc
20 nc
21 nc
22 nc
23 nc
24 nc
25 GND
26 nc
27 nc
28 VDD
29 nc
30 nc
31 nc
32 GND
Rev. 0.1
C8051F996-DK
Row C
Description
Pin #
1 nc
2 nc
3 nc
4 nc
5 nc
6 nc
7 nc
8 nc
9 nc
10
P0.6/CNVSTR
11 P0.3H
12
P0.0/VREF
13 P1.5
14 P1.2
15 nc
16 nc
17 nc
18 nc
19 nc
20 P1.7H
21 nc
22 nc
23 nc
24 nc
25 nc
26 nc
27 nc
28 nc
29 nc
30 nc
31 nc
32 nc
17
