The following items are located on the bottom side of the board. See Figure 8.
BH1
BH2
BH3
12
Downloaded from
Elcodis.com
electronic components distributor
Battery Holder for 1.5 V AAA.
Battery Holder for 1.5 V AAA.
Battery Holder for 3 V Coin Cell (CR2032).
NEG
BH2
(AAA)
POS
Figure 8. Bottom of C8051F996 Target Board
POS
BH3
(CR2032)
BH1
NEG
(AAA)
