Summary of Contents for Horizon Hobby Pawnee Brave Night Flyer

  • Page 1 All manuals and user guides at all-guides.com Pawnee Brave Night Flyer Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
  • Page 2: Safety Precautions And Warnings

    Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warn- ings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Box Contents Quick Start Information Transmitter Set up your transmitter using the Setup transmitter setup chart Hi Rate Low Rate =15mm =10mm =10mm =08mm =15mm =12mm Dual Rates =10mm =9mm =18mm =10mm =18mm =10mm Full Half...
  • Page 4: Prefl Ight

    All manuals and user guides at all-guides.com Prefl ight Remove and inspect contents. 10 Test the fl ap operation. Read this instruction manual thoroughly. 11 Perform the Control Direction Test with the transmitter. Charge the fl ight battery. 12 Perform the AS3X Control Direction Test with the aircraft. Setup Transmitter using transmitter setup chart.
  • Page 5: Model Assembly

    All manuals and user guides at all-guides.com Model Assembly Main Gear Installation Secure the main gear assembly to the fuselage using 4 screws (A). Tail Installation 1. Connect the light connector (Servo style) from the horizontal stab to the fuselage. 2.
  • Page 6: Wing Assembly

    All manuals and user guides at all-guides.com Model Assembly Continued Wing assembly 1. Slide the left and right wing halves together, as shown (fi gure A). 2. Ensure the internal wing lights connectors (JST type connector), aileron servo connectors and navigation light connectors are aligned with the hole (B) created by the two connected wing halves.
  • Page 7 All manuals and user guides at all-guides.com Model Assembly Continued Wing Installation 2. Guide the aileron servo connectors, wing light and navigation light connec- tors (A) from the wing through the hole in the bottom side of the fuselage. IMPORTANT: The ailerons must be connected to the receiver’s AILE (#2 chan- nel) with a Y-harness (included) for the AS3X system to function properly.
  • Page 8: Clevis Installation

    All manuals and user guides at all-guides.com Model Assembly Continued Clevis Installation • Pull the tube from the clevis to the linkage. • Carefully spread the clevis, then insert the clevis pin into the desired hole in the control horn. •...
  • Page 9: Optional Flap Installation

    All manuals and user guides at all-guides.com Model Assembly Continued Optional Flap Installation Before you begin you will need to purchase (2) (SPMA330) servos and a 6 inch Y-harness (SPMA3058) to complete the fl ap installation process. 1. Remove the main wing from the fuselage. 2.
  • Page 10: Control Horn And Servo Arm Settings

    All manuals and user guides at all-guides.com Control Horn and Servo Arm Settings The table to the right shows the factory settings for the control horns and servo Horns Arms arms. Fly the aircraft at factory settings before making changes. NOTICE: If control throws are changed from the factory settings, the AR636 gain values may need to be adjusted.
  • Page 11: Battery Installation And Esc Arming

    All manuals and user guides at all-guides.com Battery Installation and ESC Arming Battery Selection ® We recommend the E-fl ite 2200mAh 11.1V 3S 30C Li-Po battery (EFLB22003S30). Refer to the Optional Parts List for other recommended batteries. If using a battery other than those listed, the battery should be within the range of capacity, dimensions and weight of the E-fl...
  • Page 12: Center Of Gravity (Cg)

    All manuals and user guides at all-guides.com Center of Gravity (CG) The CG location is measured from the leading edge of the wing at the root. This CG location has been determined with the recommended Li-Po battery (EFLB22003S30) installed all the way forward in the battery compartment. The easiest way to achieve CG is to balance the aircraft inverted.
  • Page 13: In Flight Trimming

    All manuals and user guides at all-guides.com In Flight Trimming During your fi rst fl ight, trim the aircraft for level fl ight at 3/4 throttle. Make small trim adjustments with your transmitter’s trim switches to straighten the 3 Seconds aircraft’s fl...
  • Page 14: Post Flight

    Solution Damaged propeller or Replace propeller or spinner spinner Balance the propeller. For more information, view our propeller balancing video on Horizon Hobby’s You- Imbalanced propeller tube channel https://www.youtube.com/watch?v=OXuNnYQO2s4 Motor vibration Replace parts or correctly align all parts and tighten fasteners as needed...
  • Page 15: Troubleshooting Guide

    All manuals and user guides at all-guides.com Troubleshooting Guide Problem Possible Cause Solution Throttle not at idle and/or throttle trim too high Reset controls with throttle stick and throttle trim at lowest setting Aircraft will not re- Throttle servo travel is lower than 100% Make sure throttle servo travel is 100% or greater spond to throttle but responds to other...
  • Page 16: Ama National Model Aircraft Safety Code

    All manuals and user guides at all-guides.com AMA National Model Aircraft Safety Code Effective January 1, 2014 A. GENERAL B. RADIO CONTROL A model aircraft is a non-human-carrying aircraft capable of sustained fl ight 1. All pilots shall avoid fl ying directly over unprotected people, vessels, in the atmosphere.
  • Page 17: Limited Warranty

    Product, (iv) attempted service by copy of your original sales receipt must be included for warranty consideration. anyone other than a Horizon Hobby authorized service center, (v) Product not Be sure your name, address, and RMA number are clearly written on the purchased from an authorized Horizon dealer, or (vi) Product not compliant outside of the shipping carton.
  • Page 18: Contact Information

    Compliance Information for the European Union EFL Brave Night Flyer BNF Basic (EFL6850) EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provi- sions of the R&TTE and EMC Directive.
  • Page 19: Replacement Parts

    All manuals and user guides at all-guides.com Replacement Parts • Ersatzteile • Pièces de rechange • Pezzi di ricambio Part # | Nummer Description Beschreibung Description Descrizione Numéro | Codice EFL6901 Fuselage w/lights: Brave E-fl ite Brave: Rumpf mit Beleuchtung Brave - Fuselage avec éclairage Fusoliera con luci: Brave E-fl...
  • Page 20 All manuals and user guides at all-guides.com © 2015 Horizon Hobby, LLC. E-fl ite, AS3X, DSM, DSM2, DSMX, the DSMX logo, Bind-N-Fly, Z-Foam, ModelMatch, EC3, Celectra, Prophet and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC.
