Operating instructions
Multi-slider GAS411/421/641/951
Gas hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multi-slider GAS411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG Multi-slider GAS411

Summary of Contents for V-ZUG Multi-slider GAS411

  • Page 1 Operating instructions Multi-slider GAS411/421/641/951 Gas hob...
  • Page 2 Validity These operating instructions apply to: Type Model number Appliance class GAS411GSBZ 31063 Class 3 DIN EN 30-1-1 GAS421GSBZ 31064 GAS641GSBZ 31071 GAS951GSBZ 31072 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2025...

  • Page 3: Table Of Contents

    Contents Safety precautions  4 Accessories and spare parts  23 Symbols used ............ 4 Technical data  24 General safety precautions ........ 4 Product information .......... 24 Appliance-specific safety precautions.... 5 EcoStandby ............ 25 Instructions for use .......... 5 Disposal  26 Warnings.............. 7 Index  28 Using for the first time  8 Notes  29...

  • Page 4: Safety Precautions

    Safety precautions Symbols used with the appliance. Cleaning and user maintenance shall Denotes important safety precau- tions. not be undertaken by children Failure to observe said precautions without supervision. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...

  • Page 5: Appliance-Specific Safety Precautions

    1 Safety precautions Appliance-specific safety ▪ Do not operate the appliance precautions using an external time switch or a separate remote control system. ▪ Under no circumstances use ▪ WARNING: If the surface is a steam cleaner to clean this cracked, switch off the appli- appliance.
  • Page 6 1 Safety precautions Correct use Caution: Risk of deflagration! ▪ NOTE: This appliance is only intended ▪ Unburned gas can accumulate in en- for cooking purposes. It may not be closed areas. Please read the warnings used for other purposes, such as heat- carefully.

  • Page 7: Warnings

    1 Safety precautions ▪ The hob is designed to be used – signs Caution: Risk of injury! of use, such as scratches or the wear ▪ Cookware that is damaged, is not the and tear from pans and cookware, are right size or is not positioned correctly normal.

  • Page 8: Using For The First Time

    Using for the first time The appliance must be installed and connected to the electricity and gas supply in accordance with the separate installation instructions. Have a certified installer carry out the necessary work. During the first few hours of use, a cooking zone can give off an unpleasant smell. This is normal for brand new appliances.

  • Page 9: Operating And Display Elements

    3 Appliance description GAS421GSAZ ▪ 1 rapid burner (top) ▪ 1 standard burner (bottom) GAS411GSAZ ▪ 1 wok burner Operating and display elements Control buttons Timer – Function as minus button in timer mode Plus button in timer mode Multi-function button – duty-cycle function selection Slider (for setting the power level) Pause cooking ON/OFF and restore function Appliance ON/OFF...

  • Page 10: Gas Burners

    3 Appliance description Displays Bridging function activated Melting activated Keep warm activated Simmering activated Duty-cycle function activated Cooking zone power level Display for timer Timer activated Corresponding cooking zone for slider 10 Pause activated / possibility for restoring saved settings 11 Wipe protection activated Gas burners The pan supports and all the parts of the burners must be positioned correctly in order...

  • Page 11: Automatic Re-Ignition

    3 Appliance description Wok burner 1 Burner cap 2 Wok extension ring 3 Flame spreader 4 Wok support 5 Retaining plate for burner 6 Wok burner Automatic re-ignition All hobs have automatic re-ignition. If a flame is extinguished, the appliance automatically attempts to reignite it. If the attempt to reignite it fails, the burner switches off.
  • Page 12 3 Appliance description Burner Base diameter Min. Max. Recommended Rapid burner 18 cm 26 cm 24 cm Standard burner 14 cm 20 cm 18 cm Economy burner 12 cm 16 cm 14 cm Wok burner without wok extension ring 14 cm 26 cm 26 cm Wok extension ring...
  • Page 13 3 Appliance description Note on use The following tips will help you to save energy and prevent damaging the cookware and the appliance: ▪ The diameter of the base of the cookware should correspond to the size of the relevant burner.

  • Page 14: Operating The Appliance

    4 Operating the appliance Operating the appliance Switching the appliance on and off ▸ To switch the appliance on: Depress the button for 1 second. – flashes in all the power level displays. – If no other entry is made, the appliance switches off again after about 10 seconds for safety reasons.

  • Page 15: Bridging Function

    4 Operating the appliance Bridging function Only applies to appliances GAS641/GAS951 The bridging function allows two standard burners lying one behind the other to be switched on together and to be regulated together. Switching the bridging function on ▸ Depress both sliders for the standard burners at the same time for 1 second. –...

  • Page 16: Simmering

    4 Operating the appliance Simmering The precision of the «Simmer» function depends on the cookware used. Water can start to boil. If this is the case, we recommend the pan lid be left off when using the «Simmer» function. For locations over 1,500 meters above sea level, it is generally recommended that the pan lid be left off when using the «Simmer»...

  • Page 17: Timer

    4 Operating the appliance 4.11 Timer The timer functions like an egg timer (1 min.–9 hrs. 59 mins.). It can be used at any time and independently of all other functions. Setting the timer ▸ Switch the appliance on. ▸ Touch the button.

  • Page 18: Pause Cooking

    4 Operating the appliance The childproof lock is reactivated within one minute of switching off the appliance. Switching the childproof lock off ▸ Switch the appliance on. Ensure all cooking zones are switched off. ▸ Touch the buttons at the same time. –...

  • Page 19: User Settings

    5 User settings User settings The following user settings can be set and saved individually: User setting Setting value Factory setting Acoustic signal loud- ness Medium High Acoustic signal at end No acoustic signal of operating time / timer Automatically off after 10 secs. Automatically off after 1 min.

  • Page 20: Care And Cleaning

    6 Care and cleaning Cancelling user settings ▸ Press the button. – Any changes to the setting values are not saved. – The «User settings» mode is ended. Care and cleaning Do not use any flammable, abrasive, chlorine- or bleach-containing cleaning agents to clean the appliance.

  • Page 21: Trouble-Shooting

    7 Trouble-shooting Trouble-shooting What to do if … … the ignition is not working? Possible cause Solution ▪ Food or cleaning product ▸ Clean the area between the ignition sparker and the residue stuck between the ig- burner. nition sparkers and the burn- ers.
  • Page 22 7 Trouble-shooting illuminates in the displays? Possible cause Solution ▪ The childproof lock is activated. ▸ For operating the appliance with the childproof lock activated, see the «Operating the appliance» section. ▸ Switch the childproof lock off..A continuous acoustic signal is emitted, flashes in a display and the appliance switches off? Possible cause...

  • Page 23: Accessories And Spare Parts

    8 Accessories and spare parts … and a number illuminate in the display? Possible cause Solution ▪ Internal error occurred. ▸ Check the gas supply. ▸ Clean the thermocouples. ▸ Acknowledge error message (confirm using the slider). ▸ Switch the hob off, allow it to cool down and then switch it back on again.

  • Page 24: Technical Data

    9 Technical data Standard burner in black or made from brass Technical data Product information In accordance with EU Regulation No. 66/2014 Brand V-ZUG Type of appliance Built-in hob Model number 31063 Type designation GAS411GSAZ Heating technology Gas burner Type of burner...

  • Page 25: Ecostandby

    9 Technical data In accordance with EU Regulation No. 66/2014 Brand V-ZUG Type of appliance Built-in hob Model number 31071 Type designation GAS641GSAZ Heating technology Gas burner Type of burner Rapid 2 × standard Economy Total Nominal heat input Natural gas, MJ/h 11.5...
  • Page 26 10 Disposal Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an envir- onmentally friendly way. Disconnection ▪ Disconnect the appliance from the electricity and gas supply. With a fixed appliance, this is to be carried out by a certified installer! Safety ▪...
  • Page 27 989 Siam Piwat Tower, 12 A Floor, London W1U 1PN TT25, GREAT BRITAIN Rama1 Road, Pathumwan Pathumwan, Bangkok 10330 THAILAND HK/MO V-ZUG Hong Kong Co. Ltd. GÜRELLER 12/F, 8 Russell Street Anchor Sit.3A/1-2 Çayyolu Causeway Bay 06690 ÇANKAYA/ANKARA HONG KONG TURKEY Frigo 2000 S.p.A...
  • Page 28 Index Addresses of the importers ......27 Operating and display elements Appliance Control buttons .......... 9 Switching on and off ........ 14 Displays ............ 10 Appliance overview ..........9 Appliance-specific safety precautions ................ 5 Packaging ............26 Automatic boost ..........16 Pause cooking..........
  • Page 29 Notes...

  • Page 31: Service And Support

    V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.

  • Page 32: Quick Instructions

    ▸ Touch the slider for the required cooking zone or swipe it to set the power level. To switch cooking zone off ▸ Touch power level 0 on the slider. To switch appliance off ▸ Touch the button. 1007523-08 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
