ConvaTec inset guard User Manual page 4

Infusion Care
Reconnecting
D
Reconnecting
Remove the disconnect cover by placing a finger
on the cannula housing and gently squeezing the
sides of the cover. Pull the cover straight out of the
cannula housing.
provided in this user guide is not intended to be a substitute for professional medical advice. Always seek the advice of your healthcare professional if you have
any questions regarding your infusion set. The information provided is not a substitute for the instructions for use (IFU) that come with the infusion set, always
©2024 Convatec. ™/
Arrow guide
Pull Pull Pull
E
Reconnecting
Remove the protective cap from the site connector
by gently squeezing the sides of the site connector
and then pulling the protective cap off.
This user guide is created and owned by Convatec. When using inset™ guard for the first time, do so in the presence of a healthcare professional. The information
refer to the most recent IFU for information. Please note that the numeration in this guide does not directly correspond with the numeration in the IFU.
® refer to trademarks of the Convatec group of companies. The Convatec name, Hug icon, and strapline are trademarks of Convatec. AP-70961-GBL-ENGU.
inset
Push Push Push Point Point Point
F
Reconnecting
Hold the infusion set with the needle pointing
down. Prime the infusion set according to the pump
manufacturer's instructions for use until insulin
dispenses from the needle. Ensure there are no air
bubbles in the tubing.
Caution
Never fill the tubing while the infusion set is connected to
your body.
guard infusion set inset inset infusion set infusion set
™ ™ ™
Twist Twist Twist
Reconnecting
To connect the site connector to the cannula
housing, place a finger on the cannula housing while
pushing the site connector straight in until you hear
a "click".
User Guide User Guide User Guide
G
4
