Aries 2051128 Installation Manual

INSTALLATION MANUAL
Parts List
1 Driver / left running board
1 Passenger / right running board
1 Mounting bracket,
driver / left, front
1 Mounting bracket,
passenger / right, front
1 Mounting bracket,
driver / left, middle
1 Mounting bracket,
passenger / right, middle
1 Mounting bracket,
driver / left, rear
1 Mounting bracket,
passenger / right, rear
12 Hex bolt, M8
12 Flat washer, M8
12 Lock washer, M8
12 Hex nut, M8
12 Handle nut, M8
Additional Hardware*
12 Hex bolt, M8
12 Flat washer, M8
12 Lock washer, M8
12 Hex nut, M8
* Running boards are supplied
with additional hardware.
Quantities listed are in addition
to the standard supplied hardware.
Tools Required
Torque wrench Ratchet
Extension Socket, 13mm
Level
Level of Difficulty
Easy
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For stainless steel, polish may be used to clear small scratches
and scuffs on the finish. Mild soap may be used also to clean the product.
For black finishes, mild soap may be used to clean the product.
Refer to the table below when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Torque Specifications
M6 bolt
M8 bolt
M12 bolt
M12 bolt
--
Use above torque setting unless otherwise noted
PAGE 1 • 2051128-INS-RC • 877.287.8634 • NEED ASSISTANCE?
Rear
Middle
Front
3 ft.-lbs.
7 ft.-lbs.
16 ft.-lbs.
28 ft.-lbs.
--
2051128
Scan
for helpful
install tips
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.
• ARIESAUTOMOTIVE.COM
