Aries AeroTread 2051106 Installation Manual

INSTALLATION MANUAL
Parts List
1 Driver / left running board
1 Passenger / right running board
2 Mounting bracket, front
2 Mounting bracket, middle
2 Mounting bracket, rear
2 Bolt plate, 1/2", short
8 Bolt plate, 1/2", long
2 Hex bolt, 3/8"
2 Flat washer, 3/8"
2 Lock washer, 3/8"
2 Nut plate, 3/8"
10 Flat washer, 1/2"
10 Lock washer, 1/2"
10 Hex nut, 1/2"
10 Plastic bolt retainer, 12mm
Additional Hardware*
12 Hex bolt, 8mm
12 Flat washer, 8mm
12 Lock washer, 8mm
12 Hex nut, 8mm
* Running boards are supplied
with additional hardware.
Quantities listed are in addition
to the standard supplied hardware.
Tools Required
Torque wrench Socket, 1/2"
Extension Socket, 3/8"
Level Wrench, 1/2"
Level of Difficulty
Easy
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For stainless steel, polish may be used to clear small scratches
and scuffs on the finish. Mild soap may be used also to clean the product.
For black finishes, mild soap may be used to clean the product.
PAGE 1 • 2051106-INS-RB • 877.287.8634 • NEED ASSISTANCE?
Front
Rear
Front
2051106
Scan
for helpful
install tips
Rear
Middle
Rear
Front
• ARIESAUTOMOTIVE.COM
